Riello GAS 5 P/M Guide de démarrage rapide
Installation, use and maintenance instructions
2915246 (2) - 07/2016
Forced draught gas burner
Progressive two-stage or modulating operation
CODE MODEL TYPE
3753581 GAS 5 P/M 535 T80
GB
Declaration of conformity in accordance with ISO / IEC 17050-1
Manufacturer: RIELLO S.p.A.
Address: Via Pilade Riello, 7
37045 Legnago (VR)
Product: Forced draught gas burner
Model: GAS 5 P/M
These products are in compliance with the following Technical Standards:
EN 676
EN 12100
and according to the European Directives:
MD 2006/42/EC Machine Directive
LVD 2014/35/UE Low Voltage Directive
EMC 2014/30/UE Electromagnetic Compatibility
The quality is guaranteed by a quality and management system certified in accordance with UNI EN ISO 9001.
Mr. U. Ferretti Mr. F. Comencini
1
2915246
GB
TECHNICAL DATA
ELECTRICAL DATA
BURNER DESCRIPTION
1 Servomotor controlling air and gas
2 Adjustment cam
3 Power controller (for modulating to be required sep-
arately)
4 Control box reset button
5 Servomotor connection
6 Fair leads
7 Wiring terminal block
8 Reset push-button of the motor over load relay
9 Air pressure switch
10 Gas pressure test-point
BURNER EQUIPMENT
Thermal power
Output
155 - 660 kW - 133.300 - 567.600 kcal/h
Operation - two stages progressive
- modulating (kit with controller available upon request)
Fuel natural gas Pci 8 - 10 kWh/m
3
= 7000 - 8600 kcal/m
3
Minimum gas pressure for maximum output 9.8 mbar are needed measured at the coupling
with nil pressure in the combustion chamber and gas with calorific
value of 8600 kcal/m
3
Maximum gas pressure 150 mbar
Electrical supply Three phase 220 V + 10% - 10% ~ 60 Hz without neutral
380 V + 10% - 10% ~ 60 Hz with neutral
Fan motor IE2 3.4A / 220V - 1.9A / 380V
Ignition transformer Primary: 1.8A / 220V - Secondary: 1 x 8 kV - 30 mA
Electrical power consumption 0.85 kW
Quantity Accessories
1 Flange
1 Gasket
8 Screws
1 Flange gasket
Fig. 1
2915246
2
GB
MAXIMUM DIMENSIONS
COMBUSTION CHAMBER PRESSURE - MAXIMUM OUTPUT
Min. output: 155 kW - 133.300 kcal/h.
Boiler front-plate
drilling
*
Length available with special blast tube to be separately required.
Burner
160
160
165 M12
D1785 D2192
kW
Kcal/h
mbar
D1790
3
2915246
GB
MINIMUM GAS PRESSURE - OUTPUT
Pressure: detected at the pressure test-point 10) (fig. 1) with oil mbar into the combustion chamber.
Should the combustion chamber be pressurized, the pressure necessary will be that of the graph plus the
pressurization value.
Example: to obtain 550 kW it is necessary a gas pressure of 9 mbar and the combustion head set as indicated at
page 8. If the combustion chamber is pressurized at 2 mbar, the pressure detected at the testpoint 9) is:
9 + 2 = 11 mbar.
If this value is too high, for very low gas pipework pressures, the gas gear 6) could be more open.
Do not decrease the pressure at the coupling under the values shown in the diagram.
Output: the maximum value is obtainable with gas Pci 8600 kcal/m
3
.
kW
Kcal/h
mbar
D1826
2915246
4
GB
MOUNTING TO THE BOILER
Separate the blast tube from the burner body by
loosening the screws 7) and 3), fix the blast tube to
the boiler front plate 5) using the gasket 6) provided.
Insert the burner on the holding bars 4) and fasten
the screws 7) and 3).
The combustion head adjustment should be carried
out as follows:
Loosen the screws 2) unhook the tension rod of
the air damper 1) remove the connecting lead of the
servomotor, withdraw the group A) from the group B).
After the setting, re-assemble and verify that the
tension rod of the air damper was locked.
GAS SUPPLY
1 - Gas pipe line
2 - Cock valve
3 - Filter
4 - Pressure stabilizer
5 - Pressure test-point
6 - Minimal gas pressure switch
7 - Safety valve
8 - Adjustment valve
9 - Adjusting throttle valve
10 - Burner
11 - Gas leak control device
D2179
Supplied
upon request To be carried out by the installer
5
2915246
GB
BURNER ELECTRICAL WIRING
(carried out y the factory)
Key to layout
CMV Motor contactor
LFL... Control box
MB Burner terminal strip
MV Fan motor
PA Air pressure switch
RT Thermal cut-out
SM Servomotor
SO Ionisation probe
SP Plug-socket
TA Ignition transformer
TB Burner ground
20123876
2915246
6
GB
ELECTRICAL CONNECTIONS TO THE WIRING TERMINAL BLOCK
(to be carried out by the installer)
NOTICE
- The electric wiring carried out by the installer must be in compliance with the rules in force in the Country.
- Leads minimal section 1 mm
2
.
- Adjustment for the motor thermal relay:
• at the beginning of the scale for 380 V;
• at the end of the scale for 220 V.
- Burners with non-stop operation.
For safety reasons, this type of burner must be stopped every 24 hours of operation, by means of an hours-
counter to be connected in series with the adjustment devices.
Key to layout
BP - Pressure probe
BT - Temperature probe
MB - Burner terminal strip
PC - Check pressure switch
PG - Min. gas pressure switch
RWF50 - Power controller
TR - High-low mode load remote control sys-
tem: controls operating stages 1 and 2
TL - Load limit remote control system: shuts
down the burner when the boiler temper-
ature or pressure reaches the preset
value.
TS - Safety load control system: operates
when TL is faulty
VR - Adjustment valve
VS - Safety valve
20124022
D2182
16 A
25 A
1.5 mm
2
2.5 mm
2
7
2915246
GB
FIXING OF THE ELECTRICAL WIRES
All the electrical wires, which are to be connected to the terminal block 7) (fig. 1) shall pass through the fair leads 6) (fig.
1) as per this scheme.
1- Three phase supply: fair lead Pg 21
2- Single phase supply: fair lead Pg 13.5
3- Adjustment thermostat: fair lead Pg 13.5
4- Safety thermostat: fair lead Pg 13.5
5- Gas train:fair lead Pg 13.5, sheath ø 13
6- 2nd stage thermostat:fair lead Pg 13.5
(probe for modulating version)
7- Pre-sheared hole: fair lead Pg 13.5 (for power controller - modulating version)
8- Pre-sheared holeg
Further prospective signals or controls can be connected to the burner wiring terminal board by removing the metal weld-
nuts from the pre-sheared holes and inserting a commun fair lead for the passage and the clamping of the leads.
NOTES
- Do not exchange the neutral wire with the phase (avoid the plug-pin connection).
- Carry out a safe earth connection.
- Check the stop of the burner, by opening the boiler thermostat and the burner lock-out, by disconnecting the lead from
the flame probe.
WARNING
When closing the burner on its slide-bars, pull towards the outside the high voltage cable and the cable of the flame de-
tection probe, till to little tension.
D2184
2915246
8
GB
BURNER START-UP CYCLE
Air-purge: loosen the screw placed on the minimal gas pressure switch mounted on the gas train
.
AIR PRESSURE SWITCH
The air pressure switch setting shall be carried out after having set all other
adjustments of the burner and the air pressure switch shall be at its lowest
set-point.
When the burner is operating, increase the adjustment pressure by turning
- slowly - clockwise the knob till reaching the burner lock-out.
Thereafter, turn the knob anticlockwise for 1 mbar and repeat the burner
start-up for checking the regularity: if lock-out intervenes turn the knob an-
ticlockwise for 0.5 mbar.
CAUTION:
do not turn the ionization probe, maintain the drawing position; should it be close to the ignition electrode, damage
may occur to the control box amplifier.
Screw
Plug for pressure measure
Pressure switch
S7506
1 ÷ 10
mbar
Adjustment knob
S7507
D2185
Probe position Ignition electrode position
