Ricoh PJX5140 Manuel utilisateur

PJ X5140/WX5140/WX5150

PJ X5260

LAN control function

User’s manual

Table of Contents

1. Controlling the projector via a web browser.................................2

1.1 Connecting to the projector..............................................................................2

1.2 Login................................................................................................................3

1.3 Home................................................................................................................4

1.4 Projector Control Panel....................................................................................5

1.5 Network Setting...............................................................................................7

1.7 Logout............................................................................................................12

2. Control the Projector via the Projector Management Utility.......13

2.1 Installing Projector Management Utility .......................................................13

2.2 Register projectors.........................................................................................14

2.3 Control the projector with the projector Management Utility.......................17

1. Controlling the projector via a web browser

You can control the projector by using a web browser from a PC.

<Note>

-If you want to connect an existing network system, consult the network administrator for network

settings.

-Network settings such as password will be reset when you set “Default settings 2” > “Reset All”

in the projector menu system.

-In rare cases, the network function won’t work properly due to electrostatic discharge or

something. Set “Default settings 2” > “Reset All” in such a case.

1.1 Connecting to the projector

1. Check IP address of the projector

Be sure to set “Default settings 1”>“Control Method” to “LAN” in the projector menu system

before starting to set Network setting

Check IP address in “Default settings 2” > “Network setting” in the projector menu system. (See

page 43 on the projector use’s manual)

2. Connect

Open your web browser and type in the IP address you checked. For example, type

“http://192.168.0.100” when IP address is displayed as the screen above.

<Note>

This web pages use Java Script. Please turn on Java Script in your browser.

1.2 Login

1. The web browser shows a login page.

2. Select a user.

You can use all functions (Control Panel, Network setting and Alert setting) when you select

“administrator”. And you can use only “Control Panel” when you select “user”.

3. Enter the Password

If the password setting is enabled the correct password needs to enter.

Default passwords of Administrator: “admin”.

Default passwords of User: “user”

If the password setting is disabled the “Password” item will be gray out.

Click [Login] button to login.

<Note>

-The warning message “Invalid Character” will popup if your password is incorrect.

-“B01” showed in the top in the web page picture indicates software version of this web page. It

may be different from “B01”.

4. Login

After login, control tabs will appear. It contains Home, Control Panel, Network Setting, Alert

Setting, and Logout.

Home is automatically selected after login.

1.3 Home

This is Home page which shows basic information of your projector. There is no control on this

page.

1. Projector Status:

System Status:

It shows the current system status of the projector. It includes Standby, Warm-up, Power-on,

cooling, Power-off and Unknown.

-Input:

[PJ X5140, WX5140, WX5150]

It shows the current input source of the projector. It includes Computer 1, Computer 2, S-Video,

Video, HDMI, None and Unknown.

[PJ X5260]

It shows the current input source of the projector. It includes Computer 1, Computer 2, S-Video,

Video, Component, DVI, HDMI and Unknown.

-Lamp Hours:

It shows the current lamp hours of the projector.

-FW Version:

It shows the current firmware version of the projector.

<Note>

The projector status will show “Unknown” if the projector is not set properly. Check the control

method setting in the OSD menu at this situation. Set it to “LAN” if you want to control the

projector via network.

1.4 Projector Control Panel

This page shows the control items of your projector. User can control the projector by this page.

Control Buttons

Execute a function when the button is clicked.

[Power ON]

[Power OFF]

[Auto Set]

[Input]

Power is turned on.

Power is turned off.

Automatically adjust the RGB signal from the computer.

Switch among Computer1, Computer2, Component, Video, S-Video,

DVI-D and HDMI

Setting Buttons

Setting is toggled On and Off by clicking the button.

[Auto Input Search]

[AV Mute]

[Freeze]

[Key Lock]

[3D Projection]

[DLP Link]

[L/R Reverse]

Search the next signal source automatically when the current signal is

lost. (See p.37 on the Projector User's manual)

Momentarily turn off the audio and video.

Pause the screen image

Disable the keys on the projector.

Set 3D projection mode on.

Set 3D projection mode with DLP Link on.

Change left and right frame content of 3D projection.

(See p.42 on PJ User's manual for 3D related settings.)

Input select:

Select an input source from the drop down list.

Adjusting

Image:

[Brightness]

[Contrast]

[Sharpness]

[Picture mode]

[Closed Caption]

Adjust brightness by clicking [+] or [-]. Click [Reset] to return the

default value 0

Adjust contrast by clicking [+] or [-]. Click [Reset] to return the

default value 0

Adjust sharpness by clicking [+] or [-]. Click [Reset] to return the

default value 0.

Select a picture mode from the drop down list.

Select a Closed Caption mode from the drop down list.

(See p.40 on the Projector User's manual for 3D related settings.)

Audio

[Volume] Adjust volume by clicking [+] or [-]. Click [Reset] to return the

default value 5

Management

[Background on

No Signal]

[Display Icon]

[Start-up Screen]

[Power off on

No signal]

[Aspect]

Select an image on no signal from the drop down list.

Select "Off" to hide icons when the input source or settings are

changed.

Select On/Off for startup screen which is displayed when the

projector is turned on.

Select power off timer value after no signal is detected from the drop

down list.

Select aspect ratio from the drop down list.

1.5 Network Setting

Projector Setting

Projector name which is displayed in this web page can be changed.

Enter a new projector name in the box and clock [Apply] button.

<Note>

This projector name is also used in PJLink control.

Up to 32 alphanumeric characters and symbols are accepted.

PJLink setting

Settings of PJLink password can be changed in this section.

-Change the password.

Confirm"Enable" is checked in PJLink password.

Enter the current password in current password box.

Enter a new password in both New Password box and Confirm Password box.

Click [Apply] button.

-Enable the password when disabled.

Check "Enable" in PJLink password.

Enter a new password in both New Password box and Confirm Password box.

Click [Apply] button.

-Disable the password when enabled.

Check "Disable" in PJLink password.

Enter the current password in current password box.

Click [Apply] button.

<Note>

-Up to 32 alphanumeric characters and symbols are accepted for a password.

-When entered the new password and the confirm password are not the same, an error message

will be displayed. Re-enter passwords in this case.

Network setting

Network settings such as IP address can be set in this section.

DHCP, IP address, and Default gateway can be also set OSD menu in the projector.

DNS Server address can be set only in this section. This is required when E-mail setting is set by

domain names.

-Check DHCP when network settings are provided by DHCP server in your network.

-Check Manual when you want set network settings manually.

And enter the settings to following boxes.

[IP Address], [Subnet mask], [Default gateway], [DNS server]

After settings are changed, click [Apply] button to apply new settings.

<Note>

IPv6 is not supported.

Password setting:

Passwords setting for web pages can be changed in this section.

A password for "Administrator" and "User" can be set independently.

-Change the password.

Confirm"Enable" is checked in Administrator or User.

Enter the current password in current password box.

Enter a new password in both New Password box and Confirm Password box.

Click [Apply] button.

-Enable the password when disabled.

Check "Enable" in PJLink password.

Enter a new password in both New Password box and Confirm Password box.

Click [Apply] button.

-Disable the password when enabled.

Check "Disable" in Administrator or User.

Enter the current password in current password box.

Click [Apply] button.

<Note>

-Up to 32 alphanumeric characters and symbols are accepted for a password.

-When entered the new password and the confirm password are not the same, an error message

will be displayed. Re-enter passwords in this case.

1.6 Alert Setting

Alert setting:

This projector can send E-mail when an error occurs in the projector.

<Note>

Be sure Email setting and SMTP setting are correct.

Email test is recommended after alert setting is set.

-Email setting

Enter Email settings in the boxes.

[To], [Cc] Enter an alert mail destination.

Only one destination can be entered in each destination.

[Subject] Enter subject of an alert mail.

[From] Enter a sender of an alert mail.

Click [Apply] to apply settings.

-SMTP Setting

Enter SMTP mail server address in the box.

Click [Apply] to apply setting.

-Alert Condition

Check alert mail conditions that you desire.

Fan Lock
