RICOH

RICOH FT2050/2070

FIELD SERVICE MANUAL

RICOH COMPANY LTD.

CONTENTS

SECTION 1 : INSTALLATION REQUIREMENTS

SECTION 2: UNPACKING AND INSTALLATION

SECTION 3: PREPARATIONS FOR TRANSPORTING THE COPIER

SECTION 4: SERVICE TABLES AND REMARKS

SECTION 5: REPLACEMENT AND ADJUSTMENT

SECTION 6: SORTER CS1040

SECTION 7: DOCUMENT FEEDER DF36

SECTION 8: TROUBLE SHOOTING

SECTION 9: ELECTRICAL DATA

CAUTIONS

1. Before installing the machine, make sure that there is a suitable ground (earth) available.

2. Since some parts of the copier are supplied with high voltage, make sure the main switch is off and the

power supply cord is unpluged before working on the copier.

3. When working on the fusing section, make sure that the fusing unit is cold.

4. When standing the clamshell straight up, place a block that has a height of approximately 80 mm (approx.

3") in front of the exit cover.

5. Do not turn on the safety switch when the clamshell is open.

SECTION 1

INSTALLATION

REQUIREMENTS

1-1.

Environment

Temperature Range :

Humidity Range :

Ambient Illumination :

Ventilation :

Ambient Dust :

Room Size

10°C to 30°C

(50°F to 86°F)

15%

to 90% RR

Less than 1,500 Iuxs (Do

not expose to direct

sunlight)

Room air should turn over

at least 3 times/hour.

Less than 0.1 5mg/m3

More than 10m³ (13.4 yd³)

10.

11.

If the installation place is air-conditioned or heated,

place the machine:

Where it will not be subjected to sudden

temperature changes from low to high, or vice

versa.

Where it will not be directly exposed to cool air

from an air conditioner in the summer.

Where it will not be directly exposed to reflected

heat from a space heater in winter.

Avoid placing the copier in an area filled with

corrosive gas.

Avoid any area higher than 2,000m (6,500 feet)

above sea level.

Place the copier on a strong and level base.

Avoid any area where the copier may be subjected

to frequent strong vibration.

1-1

February 1. 1986

1-2. Minimum Space Requirements More than 12 cm (4-3/4")

1. Front :70 cm (27-1/2")

2. Back :12 cm (4-3/4")

3. Right :70 cm (27-1/2")

4. Left :70 cm (27-1 /2")

1-3. Power Source

1. Input voltage level 3. Permissible extension cord:

110V/60Hz : More than 12A At least 300V, 30A capacity and less than 5m

115V/60Hz : More than 12A (16.4") long.

220V/50Hz : More than 6A

240V/50Hz : More than 6A Note: 1. Be sure to ground the machine.

(Do not connect the grounding wire to

2. Permissible voltage fluctuation: ±10%

a gas pipe.

2. Make sure the plug is firmly inserted in

the outlet.

3. Avoid multi-wiring.

4. Do not set anything on the power cord.

1-2

SECTION 2

UNPACKING

AND

INSTALLATION

August 1, 1985

2-1. Unpacking Procedure

Take out the accessory box and the machine.

2. Remove the two cushion blocks.

3. Open the vinyl bag and take out the machine.

2-1

August 1, 1985

Check that the accessories are in the quantities

according to the following list.

Cassette . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 pcs.

(One is in the machine.)

Cassette Cover . . . . . . . . . . . . . . . . . . . . . . . ..1 pc

Copy Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pc

Manual Feed Guide . . . . . . . . . . . . . . . . . . . . . . 1 pc

Master Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pc

NOTE: Keep it in the box until installing it in the

copier.

Toner . . . . . . . . . . . . . . . . . . . . . .

1 cartridge (Black)

●

Operating instructions . . . . . . . . . . . . . . . . . . . 1 pc

N.E.C.R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pc

Envelope for N.E.C.R. (115Vonly) . . . . . . . . . 1 pc

Multi-lingualDecal(220/240Vonly) . . . . . . . 1 pc

Paper Size Decal . . . . . . . . . . . . . . . . . . . . . . . . 1 pc

2-2. Installation Procedure

Remove the two strips of tape.

2. Open the front cover.

3. Move the slider to the center and push down the

release lever to open the top unit.
