D392 Ring Binder Training

Slide 1

V-C3 TECHNICAL TRAINING

OPTIONAL RING BINDER (D392)

No additional notes

D392 Ring Binder Training

Slide 2

Overview

No additional notes

D392 Ring Binder Training

Slide 3

External View

Do not use the empty

space below the output

tray as a storage area.

Left Door

Output Tray

Right Door

D392 service manual, Details, Overview, Important Parts

D392 Ring Binder Training

Slide 4

Main Units

Pre-Punch

Jogger Unit Punch Unit

Binder Unit

Output Belt Unit

Stacker Unit

D392 service manual, Details, Overview, Important Parts

The binder unit contains the pre-bind jogger unit, ring supply unit, and clamp unit.

See the service manual for the locations of these within the binder unit.

D392 Ring Binder Training

Slide 5

Inform the Customers

The next few slides contain points to tell the customers after you finish the

installation.

D392 Ring Binder Training

Slide 6

Jams

Decals attached to the machine that provide

guidance for removing paper jams. Point out the

decal locations.

Detailed instructions on removing ring jams are

provided in the operating instructions under

"Removing Jammed Ring Combs".

No additional notes

D392 Ring Binder Training

Slide 7

Pulling out/Pushing in the Binder Unit

Always grip handle Mc8 when pulling out or pushing in the binder

unit.

Never touch any other surface of the binder unit when it is

moving.

To avoid injury the fingers, never push on the top of the binder

unit to slide it back into the finisher.

No additional notes

D392 Ring Binder Training

Slide 8

Do not Store Things Below the

Output Tray

Do not use the empty

space below the output

tray as a storage area.

Left Door

Output Tray

Right Door

D392 service manual, Details, Overview, Important Parts

Obstacles in this area (circled in the illustration) will interfere with the raising and

lowering of the tray and cause an error.

D392 Ring Binder Training

Slide 9

Ring Opener

The customer can use this to add pages to a document that

is already bound.

The additional pages must be printed with punching only

(no ring binding).

The ring binder is limited to 100 pages.

If the customer needs to bind a 120-page document:

First, do a run of 100 pages with ring binding enabled.

Then, do a 20-page run for the remaining pages, with punching only (no ring

binding).

Then, use the ring opener to open the ring and add the remaining pages to the

completed document.

For details about the ring opener, see the Operating Instructions for the ring

binder. Troubleshooting, Inserting Pages into an Existing Ring Bound

Booklet

D392 Ring Binder Training

Slide 10

Machine Component Overview

No additional notes
