Richiger EA 910 Manuel utilisateur
CDDF00051A
RICHIGER
EA 910 UNLOADER
Parts list
Operator's Manual
Operator's Manual
This manual
Richiger has endeavored to provide the most accurate and clear information on this equipment.
Because of efforts to produce the best equipment possible, upgrades and improvements may
precede this or subsequent manuals' updates. Therefore, contents of this manual are based on
development in effect at the time of publication and are subject to change without notice.
Important
Before attempting machine operation, read this manual's instructions carefully.
This manual contains information and recommendations that may vary in accordance with user
experience, climate, grain type, tractor weight and other variable conditions.
CDDF00051A
EA 910 UNLOADER
This warranty is expressly in lieu of any other warranties, express or implied, including any warranty of merchantability
or fitness for a particular purpose.
Buyer's sole and exclusive remedy under this warranty shall be limited to the repair, replacement or exchange of
warranted parts at our option, F.O.B. our factory, or designated service center, agent or representative. If the agent or
representative grants any warranty greater in scope or time period or labor allowance than that detailed herein,
RICHIGER MAQUINARIAS S.A shall not be liable beyond the herein stated limitations.
Equipment and accessories not of our manufacture are not covered by this warranty. Any claim with regards to
defective aforementioned equipment and accessories shall be submitted by RICHIGER MAQUINARIAS S.A to the
original manufacturers for analysis and subsequent non-approval or approval of repair, replacement or exchange, at
their option.
No special, incidental, consequential or other damages or contingent liabilities including, but not limited to, loss of life,
personal injury, loss of crops, loss due to fire or water damage, loss of business or business income, down time costs
and trade or other commercial loss arising out of the failure of product. The term product and products as used in this
warranty designates the whole finished unit in its entirety, i.e. the complete assembled machine, and/or all and every
individual component, part, equipment and accessory that forms said complete assembled machine.
Normal wear and tear associated with use is expressly excluded from this warranty.
No products shall be returned without prior authorization from RICHIGER MAQUINARIAS S.A.
Buyers and their agents shall prepay all transportation charges for the return of such products to RICHIGER
MAQUINARIAS S.A or designated service center. There will be no acceptance of any charges for labor and/or parts .
incidental to the removal and remounting of product repaired or replaced under this warranty.
This warranty does not cover conditions over which RICHIGER MAQUINARIAS S.A has no control including, without .
limitation, contamination, pressures in excess of the recommended maximum, products damaged or subject to
accident, abuse or misuse after shipment from factory, products altered and repaired by anyone other than RICHIGER
MAQUINARIAS S.A factory personnel or representative or source approved by RICHIGER MAQUINARIAS S.A in .
writing prior to commencement of said work.
The first buyer is responsible for proof of delivery date of product for the purpose of establishing warranty time of
validity. Warranty can continue for new user should the product be resold by the first buyer during valid period of
warranty, only if this situation is reported in writing, with enclosed documentation as proof of purchase. Warranty will
not be applicable if series number or other identification markers are erased, obliterated or otherwise altered.
Warranty terms
Warranty policy
Limitations on Warranty
Unit: Hydraulic-Mechanical Grain Bag Unloader
Model: EA-910
RICHIGER MAQUINARIAS S.A, located in Avellaneda 661, Sunchales, Santa Fe province, Argentina, warrants its
product EA-910 mechanical grain unloader from defects in materials and workmanship under normal operating
conditions and proper application, in accordance with the specifications for operation as described by the
manufacturer, for the period of 365 days from date of delivery to buyer.
Limitations on Warranty
Within 15 days after delivery to or receipt by the buyer of the product, the buyer shall inform the seller in writing if
product is found defective or short in any respect. Failure to so inform the seller or any use by buyer of product shall
constitute conclusive evidence that the seller satisfactorily performed and the buyer waives any right to reject the
product thereafter
The first buyer is responsible for proof of delivery date of product for the purpose of establishing warranty time of
validity. Warranty can continue for new user should the product be resold by the first buyer during valid period of
warranty, only if this situation is reported in writing, with enclosed documentation as proof of purchase. Warranty will
not be applicable if series number or other identification markers are erased, obliterated or otherwise altered.
The following are types of failures which are not attributable to defects in materials and/or workmanship and which
are not considered by RICHIGER MAQUINARIAS S.A as part of the warranty extended hereunder. This listing is by .
way of example and is not intended to be exhaustive:
1) Product suffered damages attributable to accident, abuse, neglect or ignorance.
2) Product was not used in accordance with manufacturer's recommendations.
3) Product did not receive required maintenance.
4) Failure ensued after replacement of original parts without express consent of RICHIGER
MAQUINARIAS S.A , or modifications that in RICHIGER MAQUINARIAS S.A.’s judgment may have .
affected performance, safety and/or dependability parameters.
5) Product was used in a manner or for a purpose for which it was not designed or intended to be used.
6) Incorrect mounting of external gears, pulleys.
7) Stripped splines or keyways on drive shafts.
8) Damage due to deterioration during periods of storage by the purchaser prior to operation.
9) Damage of any kind from erosive or corrosive action of any gases or liquids handled by the machinery.
10) Lack of or incorrect type of hydraulic fluid, lubricant, oil and/or grease.
11) Contamination of hydraulic fluid.
12) Operating beyond recommended maximum speeds, pressures and temperatures.
13) Repairs or disassembly by unauthorized personnel.
14) Misalignment of drive shafts, gears, sprockets and power driven elements.
15) Damage due to voltage spikes, static discharge, electrical storms, physical abuse, externally controlled
device failure and improper fusing.
Buyer inspection and acceptance
Cut-Out Warranty Registration Card
This form must be filled out and signed by the customer at the time of delivery, and sent
to factory within 30 days of delivery.
Machine Description:
Model #:
Unit #:
Date of Purchase: Date of Delivery:
Customer Name:
Address:
City: State:
Dealer Name:
Address:
City: State:
The machine detailed above and the Operator's Manual have been received and I understand and have been thoroughly instructed
by my dealer about how to operate the machine, Operator's Manual content, equipment care, safe operation & warranty terms, and
have personally reviewed the Warranty Policy Terms.
Buyer's signature:
Richiger Maquinarias SA
Avellaneda 661,
S2322BCM Sunchales,
Province of Santa Fe,
Argentina
Cut-Out Warranty Registration Card
This form must be filled out and signed by the customer at the time of delivery, and sent
to factory within 30 days of delivery.
17. page 27
General indications for efficient operation
20. page 35
Parts list
15. page 25
Lubrication schedule
19. page 32
Hand signals
18. page 31
General indications and safety tips
16. page 26
The grain flow concept
14. page 23
Lubrication chart
02. page 03
Dimensions
03. page 04
Safety precautions
04. page 05
A word about the hydraulic controls.
05. page 06
Switching from transport to work
06. page 09
Attaching the bag
07. page 13
Grain extraction procedure
08. page 16
Ending grain extraction
09. page 16
Emptying the last section of bag
10. page 19
Detaching bag from roller
page 20
11.Back to transport position
page 21
12.Maintenance
13. page 22
Gear oil filling procedure
page 02
01. Technical specifications
Index
9
01
01
Technical specifications Materials to be extracted All kinds of dry grains (wheat, sorghum, maize, sunflower, soybeans, rice,
etc.) and pelletized materials
Capacity Up to 300 tons/tour (*)
Minimum power: 60 CV
Tractor
PTO revolutions: 540 rpm
Extraction High clearance discharge auger, mechanical drive
Drive shaft w / shear bolt protection
PowerTransmission
Mechanical central discharge auger & cross augers
Tires 11 L15 – 10 ply
Extraction system Automatic bag pickup system
Working height hydraulically controlled
Bag slasher blade
Works mechanically and hydraulically
Adjustable working width
Tire pressure: 30 lbs./sq. in.
Total weight 2000 kg. (4400 lbs.)
(*) Work capacity can vary according to grain type, moisture content and other factors
Manufacturer reserves right to change specifications at any given time without previous notification
02
02
Dimensions in millimeters
Work position
Transport position
9
03
5200
2500
6705
