Rice Lake OS-10 Manuel

RICE LAKE OS-10/OS-25/OS-45

On-Site Hanging Scale

Operators Guide

131079 Rev A

1OS-10/25/45 Hanging Scale Operator’s Manual

Safety

Failure to heed

may result in minor or moderate injury.

DO NOT operate or work on scale unless you have read and



understand this manual.

DO NOT use for purposes other than weighing.

DO NOT leave loads unattended.

DO NOT Overload - it can damage the scale and will render the warranty null and void.

Cleaning

•

Important

Always turn scale off before cleaning.

•Alcohol based wipes when cleaning the scale are recommended.

•DO NOT spray with or submerse into water when cleaning.

•Refrain from using corrosive liquids or high pressure washers.

•Improper cleaning will render the warranty null and void.

Inserting/Replacing Battery

Batteries

Battery Cover

When LO appears on display, replace batteries with

two 1.5V AA batteries.

1. Remove the battery cover located on back of scale.

2. Remove batteries and dispose of properly.

3. Install new AA batteries according to the diagram in

the battery cavity.

4. Replace battery cover securely.

Error Messages

Table 1. Error Messages

Error Action Display

Limited Warranty

All systems and components are warranted against defects in materials and workmanship

for one year. For further information see www.ricelake.com.

Low Battery Replace the batteries.

Over Load - Total load exceeds the

maximum capacity.

Remove weight from the

scale immediately.

Over Zero - Zero count is higher than the

setting range.

Scale turns off if status

continues 30 secs or longer.

Below Zero

Zero count is below the setting range.

Scale turns off if status

continues 30 secs or longer.

EEPROM error Call for service.

CAUTION

Err

ErrL

ErrE

OS-10/25/45 Hanging Scale Operator’s Manual 2

Display and Button Functions

HOLD

POWER

ZERO

UNITS

Units

Minus

Hold

Capacity: 10.00kgx0.01kg/22lbx0.02lb/22lbx1/4oz

Figure 2. Hanging Scale

Operating Scale

Suspend the scale in a secure location.

Use scale in a vertical position only.

1. Press

POWER

ZERO

to power on.

2. Press

UNITS

Units

to select units.

3. Suspend container from hook if one will be used.

4. Press

POWER

ZERO

to zero scale.

5. Place product on the scale, weight will appear in the display.

6. To turn the scale off, press and hold

POWER

ZERO

Key Item Description

1 Minus Signifies a negative weight.

2 Hold Signifies the weight is held.

3 Power/Zero Press to turn scale on.

Press to reset scale to zero.

Press and hold to turn scale off.

4 Units Select kilograms, pounds or pounds and ounces.

5 Hold Press to hold weight. Press again to release weight.

Table 2. Display and Button Function

Note

3OS-10/25/45 Hanging Scale Operator’s Manual

Hold Function

1. Press

HOLD

, when weight stabilizes display will lock and arrow will be steady.

2. Press

HOLD

to release locked weight.

Adjusting Auto-Off

1. Press

POWER

ZERO

to power on.

2. Press and hold

UNITS

Units

. When AOFF displays, release.

3. Press

HOLD

to select auto-off time (OFF, 120, 180, 240, 300 seconds).

4. Press

UNITS

Units

to return normal weighing mode.

Calibration

Calibrate using the following process:

1. Press and hold

POWER

ZERO

2. Press

UNITS

Units

three times, ZERO COUNT displays.

3. Press

POWER

ZERO

, zero displays.

4. Press

UNITS

Units

to select calibration unit.

5. Load appropriate amount of weight on scale (See Table 3). Display shows span count.

6. Press

POWER

ZERO

, CAL displays, then the weight.

7. Remove the weight, re-power the scale and calibration is complete.

Model kg lb

Table 3. Calibration Weights

OS10 10kg 20lb

OS25 20kg 40lb

OS45 20kg 40lb

Certifications and Approvals

Marked

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference that may

cause undesired operation.
