REXON rl-328cq Manuel utilisateur

RL-328CQ
INSTRUCTION MANUAL
VHF/UHF TRANSCEIVER
RoHS

Table of Contents
Packing List ������������������������������������������������������������������������������������������������1
Cautions ������������������������������������������������������������������������������������������������������1
Parts Name & Functions ������������������������������������������������������������������������2
Fitting & Removing the Battery Pack������������������������������������������������3
To install the battery pack ���������������������������������������������������������������� 3
To remove the battery pack������������������������������������������������������������� 3
Charging the Battery Pack ��������������������������������������������������������������������3
Symbols Description�������������������������������������������������������������������������������4
Basic Operation�����������������������������������������������������������������������������������������5
Turn the radio ON & OFF������������������������������������������������������������������� 5
Monitor���������������������������������������������������������������������������������������������������� 5
Transmitting ������������������������������������������������������������������������������������������ 5
Channel Selection ������������������������������������������������������������������������������� 5
Emergency Alarm�������������������������������������������������������������������������������� 6
Turbo /Call Function �������������������������������������������������������������������������� 6
Keypad Lock ������������������������������������������������������������������������������������������ 6
Setting Reverse Frequency Function ������������������������������������������� 6
Scan Function ��������������������������������������������������������������������������������������� 6
Priority Channel Function����������������������������������������������������������������� 7
Scan Type Selection���������������������������������������������������������������������������� 7
Channel /VFO Mode Selection �������������������������������������������������������8
VFO Mode With Channel Number������������������������������������������������� 8
DTMF Dial String���������������������������������������������������������������������������������� 8
BCLO & BTLO������������������������������������������������������������������������������������������ 8

Store/Delete a channel ��������������������������������������������������������������������������8
Operation������������������������������������������������������������������������������������������������� 10
Menu operation ���������������������������������������������������������������������������������10
VOX Sensitivity Level������������������������������������������������������������������������10
Transmit Power Setting�������������������������������������������������������������������10
Squelch Level��������������������������������������������������������������������������������������10
Backlight Setting �������������������������������������������������������������������������������11
Display Color Setting������������������������������������������������������������������������11
Beep Setting����������������������������������������������������������������������������������������11
ANI Setting�������������������������������������������������������������������������������������������11
+/- Potential Dierence� ������������������������������������������������������������������11
TOT (Time-Out Timer) ����������������������������������������������������������������������12
Beat Frequency Setting�������������������������������������������������������������������12
Frequency Step Setting�������������������������������������������������������������������12
CTCSS and DCS Setting �������������������������������������������������������������������12
Operation Voice Setting������������������������������������������������������������������13
Channel Spacing Selection ������������������������������������������������������������13
Quick index of menu ��������������������������������������������������������������������������� 14
Self-Programming ������������������������������������������������������������������������������� 16
CTCSS & DCS Code ������������������������������������������������������������������������������� 17
CTCSS CODE ����������������������������������������������������������������������������������������17
DCS CODE���������������������������������������������������������������������������������������������17
Technical Specications���������������������������������������������������������������������� 18

PAGE 1
Packing List
Please check following table�
ITEMS Q’TY
RL-328CQ Radio 1
Antenna (MX type) 1
Battery Pack 1
Rapid Charger 1
Belt Clip 1
Instruction Manual 1
Cautions
* NEVER transmit without antenna�
* USE DC power supply, take notice of power voltage must be
between 6V and 8V to avoid damaging the unit�
* PLEASE keep the radio dry� Rainwater or damp will corrode
electronic circuits�
* DO NOT open the unit� Non-expert handling of the unit may
damage it�
* DO NOT forget to remove the radio from the charger when
the battery is fully-charged�
* MAKE SURE the radio is turned o while charging�
* AVOID storing the radio under the sunshine or in hot areas�
High temperature can shorten the life of electronic devices, and
warp or melt certain plastics�
* AVOID storing the radio in dusty, dirty areas�
* Risk of explosion if battery is replaced by an incorrect type�
* Dispose of used batteries according to the instructions�

PAGE 2
Parts Name & Functions
Power/Volume
Knob: Rotate it to
turn on the trans-
ceiver and to adjust
the volume�
Antenna Connector:
Fit the antenna to this
MX Type connector
Loudspeaker
Microphone
LCD Display
UP & Down Button
ESCAPE Button
[ESC]
ENTER Button
[ENT]
Battery Pack
Release Buckle
PTT Button
TURBO/CALL Button
MENU Button
External Speaker
/Mic Connector
LED: Indicates radio
status
M
ESC
2PR
5SQ
8CO
0PR
4PW
7BL
LK
3VX
6SB
9BP
#TR
*
1SC
MONITOR Button
[MON]

PAGE 3
Fitting & Removing the Battery Pack
Charging the Battery Pack
To install the battery pack
To remove the battery pack
1) Connect the jack of AC adaptor into the
socket of the charging cradle�
2) Plug the AC adaptor into the power outlet�
3) Insert the radio into the cradle�
4) Charge the radio with standard charger for
10-12 hours; with rapid charger for 2 hours
1) Fit the bottom edge of the battery pack into
the holes of the transceiver cabinet bottom�
2) Push the battery pack down to the transceiver
aluminum chassis till the end click�
1) Keep pressing the release buckle of the battery pack and lift the
battery pack up from the transceiver body� Note it is normal for
this buckle to be sti�
CAUSION
Do not dispose of re
Do not short circuit
To be charged only with specied charger

PAGE 4
Symbols Description
+-
Indicates battery condition.
Indicates VOX is activated
Indicates reverse frequency
Indicates squelch is activated
Indicates the channel with scanning
Indicates bell call is activated
Indicates when the keypad has been locked
Indicates frequency scanning
Indicates Digital Coded Squelch (DCS)
Indicates VFO with channel numbers
Indicates Continuous Tone Coded Squelched System (CTCSS)
Indicates the PRIority channel (Dealer Programmable)
Displays VFO or channel numbers
Indicates the strength of TX or RX signal
Dispersion to hyper received frequency
Dispersion to under received frequency

PAGE 5
Basic Operation
Turn the radio ON & OFF
1) Rotate the PWR/VOL knob clockwise till the radio is turned on� The
radio gets started to auto test for two seconds� During auto testing, all
icons will appear on LCD�
2) After auto testing is done, LCD will show channel number and what
functions have been activated by your dealer�
3) Rotate the PWR/VOL knob clockwise to increase its volume or counter
clockwise to reduce its volume�
4) To turn the radio o, rotate the PWR/VOL knob counter clockwise
until the end click�
Monitor
Press the “MON” button on the side of the radio to open the squelch�
This allows you to override the squelch and the CTCSS or DCS tones� It is
useful to monitor the channel before you transmit and ensure there is no
one using the channel when you have CTCSS or DCS tones programmed�
Transmitting
Before transmitting, you can monitor the channel you are using to
ensure it is not busy� Keep pressing “PTT” button and start talking at ap-
proximately 2 inches from the MIC jack� During transmitting, the LED on
the top of the radio will glow red� Release “PTT” button when you have
nished talking�
Channel Selection
In channel mode, pressing the button to increase the channel num-
ber or the button to decrease it� The other way, pressing channel
number goes to desired channel by alphanumeric keypad�

PAGE 6
Emergency Alarm
Press and hold “CALL” and “MON”button assigned to make an emer-
gency alarm�
Turbo /Call Function
Turbo
Push “Turbo” button would allow you to have high power TX at 6�5W
immediately for VHF, and 5W for UHF�
HIGH POWER OR CALL FUNCTION MAY BE PROGRAMED BY YOUR
DEALER�
CALL
Push the“CALL” button for seconds to call your partner� “ “ will ap-
pear on LCD of recipient�
Keypad Lock
In Channel/Frequency mode, press and hold button for seconds,
the keypad will be locked� “ ” will appear on LCD� Press and hold
button for seconds again to unlock the keypad�
Setting Reverse Frequency Function
In Channel/Frequency mode, press and hold button for seconds
till “ ” appears on LCD� To disarm, press for seconds again� When
reverse function is activated, the transmitting frequency and receving
frequency is reversed�
Scan Function
In Channel/Frequency mode, press Mbutton and button, press
button to begin scanning, you will see the channel numbers cycling
continuously� Whenever any activity is detected, the “SCAN” mode will
stop and resume after few seconds� If your radio has scanned a channel

PAGE 7
on which there is a party you want to talk to, you can directly communi-
cate with the party by pressing the PTT button� To stop scanning, press
the button again�
Priority Channel Function
Priority scan allows you to select a channel that will be monitored more
often than the others while scanning� “ ” is ashing when priority scan
is activated�
In Frequency mode, press Mbutton and button, press but-
ton to begin scanning, you will see the frequency range cycling continu-
ously within 1MHz� Whenever any activity is detected, the “SCAN” mode
will stop and resume after few seconds unless you press “PTT” button or
button to end up scanning�
In Channel mode, press Mbutton and button, if there is “ ”
symbol showed on the LCD that means the channel has scanning func-
tion �
You will see the radio scanning like the following :
CH1-->CH2-->CH1-->CH3-->CH1-->CH5
Whenever any activity is detected, the “SCAN” mode will stop and
resume after few seconds unless you press“PTT” button or button
to end up scanning� YOUR DEALER CAN PROGRAM A PRIORITY CHANNEL
AND SCANNING CHANNEL THROUGH PC�
Scan Type Selection
In Channel/Frequency mode, press Mbutton and press Up/Down
button till “SCANS? 13” appears, press button to edit, press Up/Down
button to select TO/CO/SE�
TO: Time-Operated Scan-> After radio is locked in a busy channel for a
period, the radio will begin scanning other channels�
CO: Carrier-Operated Scan-> Radio will be locked in a busy channel till
there isn’t any carrier� Meanwhile, the radio will begin scanning other
