Tranquility Quest Plus

Service Manual

Tranquility Quest Plus CPAP System Service Manual

Tranquility Quest®Plus CPAP System is patent pending.

Tranquility Quest Plus CPAP System Service Manual

1003740

Limited Warranty

Respironics warrants that the Tranquility Quest Plus CPAP System shall be free from defects of workmanship and materials and will

perform in accordance with the product specifications for a period of two years from the date of sale by Respironics. If the product fails

to perform in accordance with the product specifications, Respironics will repair or replace—at its option—the defective material or part.

Respironics will pay customary freight charges from Respironics to the dealer location only. This warranty does not cover damage

caused by accident, misuse, abuse, alteration, and other defects not related to materials or workmanship.

Respironics disclaims all liability for economic loss, loss of profits, overhead, or consequential damages which may be claimed to arise

from any sale or use of this product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the

above limitation or exclusion may not apply to you.

This warranty is given in lieu of all other express warranties. In addition, any implied warranty, including any warranty of

merchantability or fitness for the particular purpose, is limited to two years. Some states do not allow limitations on how long an

implied warranty lasts, so the above limitation may not apply to you. This warranty gives you specific legal rights, and you may also

have other rights which vary from state to state.

The warranty for repairs is 90 days for labor and one year on the part(s) that was replaced.

To exercise your rights under this warranty, contact your local authorized Respironics dealer or contact Respironics at:

Visit Respironics Home Page on the World Wide Web at:

www.respironics.com

Table of Contents

Tranquility Quest Plus CPAP System Service Manual

1003740

Table of Contents

Chapter 1: Warnings, Cautions,

and Notes

1.1 Warnings ....................................................... 1

1.1.1 Safety ............................................................. 1

1.1.2 Operational ................................................... 1

1.1.3 Service ........................................................... 2

1.1.4 Cleaning ........................................................ 2

1.2 Cautions ........................................................ 2

1.3 Notes ............................................................. 3

Chapter 2: Specifications

2.1 Specifications................................................ 4

Chapter 3: Theory of Operation

3.1 Functional Description ............................... 5

3.2 Block Diagram.............................................. 6

Chapter 4: System Setup

Procedures

4.1 Pressure and Ramp Settings....................... 7

Chapter 5: Routine Maintenance

5.1 Cleaning the System.................................... 8

5.2 Cleaning / Replacing the

Intake Filters................................................. 8

5.3 Preventive Maintenance Schedule

(Factory Recomended)................................ 9

Chapter 6: Troubleshooting

6.3 Troubleshooting Table ................................... 10

Chapter 7: Repair & Replacement

7.1 Service Notice............................................. 16

7.2 Technical Support Statement ................... 16

7.3.1 System Exploded View ............................. 17

7.4 Repair Kits .................................................. 18

7.5 Repair Identification Photo’s ................... 22

Chapter 8: Testing

8.1 System Final Test ....................................... 27

8.2 System Final Test Data Sheet ................... 29

8.3 Clinical Remote Control Testing

(Optional).................................................... 30

8.4 Clinical Remote Control Test Data Sheet

(Optional).................................................... 31

Table of Contents

Tranquility Quest Plus CPAP System Service Manual

1003740

Appendix A: Tools and Equipment

A.1 Service Tools and Supplies....................... 32

A.2 Acceptable Test Equipment...................... 32

A.2.1 Digital Manometer .................................... 32

A.2.2 Digital Multimeter ..................................... 33

Appendix B: Schematics

B.1 Schematic Statement ................................. 34

B.2 Main Printed Circuit Assembly

(PCA)........................................................... 35

Table of Contents (Continued)

Chapter 1: Warnings, Cautions, and Notes

Tranquility Quest Plus CPAP System Service Manual 1

1003740

Chapter 1: Warnings, Cautions,

and Notes

WARNING: Indicates the possibility of injury to the patient,

operator, or technician.

CAUTION: Indicates the possibility of damage to the device.

NOTE: Places emphasis on an operating characteristic.

1.1 WARNINGS

1.1.1 Safety

• This device is intended for adult use only.

• This device is not intended for life support or life

sustaining applications.

• The instructions in this manual are not intended to

supersede established medical protocols.

1.1.2 Operational

• This warning applies to most Continuous Positive

Airway Pressure (CPAP) devices. At low CPAP

pressures, the air flow through the exhalation port

may not be enough to clear all of the exhaled gas

(CO2) from the mask. You may breathe in some of

the air that you have exhaled.

• If oxygen is used with this device, the oxygen flow

must be turned off when the device is turned off. If

the device’s air flow is turned off and the oxygen

flow is left on, oxygen may accumulate in the

Tranquility Quest Plus CPAP System enclosure and

may create a risk of fire. This warning applies to

most types of CPAP devices.

• When supplemental oxygen is used at a fixed flow

rate, inhaled oxygen concentrations will vary

depending on pressure settings, patient breathing

patterns, mask selection, and leak rate.

• Oxygen supports combustion. Do not use oxygen

in the presence of open flames, cigarette smoke,

electrical spark, or other sources of ignition.

• This device is not suitable for use in the presence of

a flammable anesthetic mixture with air or with

oxygen or nitrous oxide.

Chapter 1: Warnings, Cautions, and Notes

Tranquility Quest Plus CPAP System Service Manual 2

1003740

• In situations where risk of contamination between

the user and the device is high (e.g.: sleep lab

devices; rental devices; users with respiratory

infections), a low-resistance, main flow bacteria

filter should be placed in-line between this device

and the circuit.

• Most CPAP devices have the potential to induce

rebreathing of exhaled air. To reduce this potential,

use only Respironics circuit accessories, do not

wear the mask and headgear for more than a few

minutes while the unit is not operating, and do not

block or try to seal the vent holes in the exhalation

port.

1.1.3 Service

• Electronic components used in this device are

subject to damage from static electricity. Repairs

made to this device must be performed only in an

antistatic, Electro-Static Discharge (ESD) protected

environment.

• To assure the safety of the service technician and

the specified performance of the device,

Respironics recommends that only technicians

having prior training or experience servicing

ventilatory devices perform any repairs or adjust-

ments to the Tranquility Quest Plus.

• High voltages are present inside this device. To

avoid electrical shock, disconnect the electrical

supply before attempting any repairs on the device.

1.1.4 Cleaning

• To avoid electrical shock, disconnect the electrical

supply before cleaning the Tranquility Quest Plus.

DO NOT immerse this device into any fluids.

1.2 CAUTIONS

• Federal law (U.S.) restricts this device to sale by, or

on the order of, a physician.

• Care should be taken to avoid exposure of the

Tranquility Quest Plus to temperatures at or near

the extremes of those specified in Chapter 2. If

exposure to such temperatures has occurred, the

device should be allowed to return to room tem-

perature before being turned on.

• Always use an intake filter when the Tranquility

Quest Plus is in use.

• Never place liquids on or near the Tranquility

Quest Plus.

Warnings (Continued)

Chapter 1: Warnings, Cautions, and Notes

Tranquility Quest Plus CPAP System Service Manual 3

1003740

• Discontinue using this device if any of the parts are

damaged. Replace any damaged parts before

continuing use.

• The information in this manual is provided for

service personnel reference and is not intended for

system setup or use. System setup should be

performed by appropriate personnel using Home

Care Dealer Instructions.

1.3 NOTES

• Refer to the Tranquility Quest Plus User’s Manual

for product use, additional warnings, cautions, and

notes.

Additional WARNINGS, CAUTIONS, and NOTES are located

throughout this manual.

Cautions (Continued)

Chapter 2: Specifications

Tranquility Quest Plus CPAP System Service Manual 4

1003740

ELECTRICAL:

AC Input Voltage................................... 85 - 260VAC; 47-63Hz

AC Current Consumption .................... 1.0 A maximum

Power Consumption ............................. 75 VA maximum

Class......................................................... IIa

Type ......................................................... Type BF

RAMP:

Minimum Ramp Pressure............. 3.0 - 20.0 cm H2O

Ramp Resolution.............................. 1.0 cm H2O

Ramp Time ....................................... 0 - 30 minutes

Ramp Time Resolution ................... 5 minute increments

PRESSURE:

CPAP Pressure ....................................... 3.0 – 20.0 cm H2O

Readout Resolution ............................... 1.0 cm H20

Accuracy, Static ...................................... +1.0 cm H2O for flows between

-60 to + 120 L/min.

Accuracy, Dynamic ............................... + 1.5 cm H2O for flows between

-60 to + 120 L/min.

Chapter 2: Specifications

2.1 Specifications

ENVIRONMENTAL:

Operating Temperature ........................ 41 to 104°F (5 to 40°C)

Storage Temperature ............................. -4 to 140°F (-25 to 60°C)

Humidity ................................................ 10 to 95% non-condensing

Altitude ................................................... 0 - 10,000 ft (0 - 3048 m)

Noise Level ............................................. No specification is given

because various test instru-

ments, test procedures, and unit

operating conditions produce

varying results.

PHYSICAL:

Dimensions ............................................. 9.5” (L) x 7.75” (W) x 5.0”(H)

(24.1 x 19.7 x 5.0cm)

Weight ..................................................... 4.9 lbs (2.2 kg)

FUSE:

Fuse Type ................................................ T1A, 250v, 5 x 20 mm

(Respironics P/N 1004092)

Chapter 3: Theory of Operation

Tranquility Quest Plus CPAP System Service Manual 5

1003740

The ramp feature lets the user reduce the pressure from the unit so

that the patient can fall asleep at a lower, more comfortable pressure

at any time or as many times as needed during the night.

The patient circuit is made up of the flexible tubing, exhalation port,

and nasal mask. The unit applies CPAP to the patient’s upper

airway to keep the airway open during the sleep. Air flow gener-

ated from the unit is directed to the patient via a mask and flexible

tubing that connects to the air outlet port of the unit.

The Tranquility Quest Plus is intended to deliver CPAP therapy

only. It is not intended for life support or life sustaining applica-

tions.

Chapter 3: Theory of Operation

3.1 Functional Description

The Tranquility Quest Plus is a microprocessor-controlled Continu-

ous Positive Airway Pressure (CPAP) device that produces positive

pressure. The unit operates only in the CPAP Mode. CPAP Mode

pressure range: 3.0 – 20.0 cm H2O.

Integral to the generation of air flow is the blower assembly. Ambi-

ent air is drawn through the air intake filter by the energized blower

and is then pressurized. Ultimately, therapeutic pressure is pro-

vided to the patient via the patient circuit. The microprocessor

regulates the motor speed, which in turn adjusts and controls the

pressure.

The Tranquility Quest Plus’s control pad, which includes three push

buttons and an LCD display is the primary means by which the

patient therapy is controlled. Patients have limited access to unit

parameters.

The unit may be powered from AC voltage (100-240 VAC). AC

power enters the unit via an AC inlet and appropriate power cord.

The two system filters, the pollen and the ultra-fine, ensure opti-

mum operation for the user. An air outlet port allows for connec-

tion to the patient circuit.

Table des matières

Autres manuels Respironics Équipement médical

Respironics

Respironics Wee Sight 1017920 Manuel utilisateur

Respironics

Respironics BiPAP S Manuel utilisateur

Respironics

Respironics DreamStation Series Manuel utilisateur

Respironics

Respironics Tranquility Bilevel 1700 Manuel utilisateur

Respironics

Respironics REMstar Plus with C-Flex Manuel utilisateur

Respironics

Respironics REMstar Choice Manuel utilisateur

Respironics

Respironics Bipap Harmony S/T Manuel utilisateur

Respironics

Respironics Stardust II Manuel

Respironics

Respironics 920 Guide de dépannage

Respironics

Respironics Alice PDx Manuel d'utilisation et d'entretien

Respironics

Respironics Trilogy 100 Manuel

Respironics

Respironics HomeLOX Manuel utilisateur

Respironics

Respironics ASSESS Manuel utilisateur

Respironics

Respironics V60 Manuel utilisateur

Respironics

Respironics BiPAP Focus Manuel utilisateur

Respironics

Respironics M SeRieS Manuel utilisateur

Respironics

Respironics OptiLife Manuel utilisateur

Respironics

Respironics REMstar M Series Manuel utilisateur

Respironics

Respironics REMstar Manuel utilisateur

Respironics

Respironics System One Heated Humidifier Manuel utilisateur

Respironics

Respironics BiPAP S/T Manuel utilisateur

Respironics

Respironics M SeRieS Manuel utilisateur

Respironics

Respironics BiliTx Manuel utilisateur

Respironics

Respironics 920M PLUS Manuel utilisateur

Manuels Équipement médical populaires d'autres marques

TekTone

TekTone Tek-CARE160 Manuel utilisateur

NeuroMetrix

NeuroMetrix Quell 2.0 Manuel utilisateur

AMT

AMT XLR8 Manuel utilisateur

Medipost-Nutristoma

Medipost-Nutristoma MD300K2 Manuel utilisateur

EDAN

EDAN SONOTRAX Pro Manuel utilisateur

Restorative Therapies

Restorative Therapies RT300 Manuel utilisateur

Gendex

Gendex Expert DC Manuel utilisateur

Dexcowin

Dexcowin ADX4000W Manuel utilisateur

Libelium

Libelium MySignals Manuel utilisateur

Acelity

Acelity V.A.C.ULTA 4 Manuel utilisateur

Caputron

Caputron ActivaDose II tDCS Manuel utilisateur

FujiFilm

FujiFilm Sonart Manuel du propriétaire

Plinth 2000

Plinth 2000 93CDT Manuel utilisateur

GE SENOGRAPHE 800T Manuel utilisateur

GE Definium 5000 Manuel utilisateur

Kanmed

Kanmed GE-1380 Manuel utilisateur

Huntleigh

Huntleigh FD1 Manuel utilisateur

Stryker

Stryker SPR Plus Manuel utilisateur
