OptiLife™Patient & Clinician Fitting Guide

FITTING THE CUSHION

Finding the right size pillows cushion

If using the plastic sizing gauge, insert each size into the nostril. The bottom

rim of the gauge should not go into the nostril. Choose the size that best

seals the nostril. When choosing between sizes, choose a larger size for a

more robust seal with less insertion into the nostrils.

Select a cushion that fills the nostrils comfortably without any gaps between

the cushion and the walls of the nostrils. The bottom rim of the cushion

should not go into the nostril.

1. Look at the markings on the pillows cushion to determine the correct

placement of the cushion onto the cushion attachment hub. The arrow

on the cushion and the arrow on the interface should be on the same side,

but may not align perfectly.

2. Attach the pillows cushion to the cushion attachment hub. This should be

done one side at a time. Place the hole located on the side of the cushion

over the corresponding post located on the hub.

3. Stretch the cushion over the cushion hub

to attach the other side of the cushion.

The cushion will stretch without tearing.

4. For proper placement of the cushion into

the nostrils, rotate the cushion on the hub

at approximately a 45° angle before

inserting it into the nose.

ATTACHING THE CUSHION

45°

5. If necessary,rotate the cushion on the cushion attachment hub

for a comfortable fit.

Pull the headgear back strap and slide it forward over the head.

1. Place the nasal cushion into the nostrils. Hold the headgear back strap in

front of the face and pull it over the head. The back strap has the

Respironics logo on the blue (outer) side of the headgear.

2. The back strap should be positioned on the back of the head; the

adjustable top strap should be positioned on the top of the head; and the

side straps should be positioned above the ears.

(If side straps are resting on or below the ears see “Fitting Tips” at the

end of this guide.)

3. Adjust the side straps to help move the pillows cushion comfortably into

the nostrils. Adjust the side straps evenly on both sides.

4. Adjust the chin support band so that it rests snugly against the chin.

DO NOT over tighten. The mouth should be able to open slightly without

pulling the pillows from the nostrils.

PUTTING ON AND ADJUSTING THE INTERFACE

REMOVING INTERFACE

TOP STRAP

SIDE STRAP

BACK

STRAP

1. Side headgear straps are sitting on or covering the ears.

Tighten the top headgear strap to move the side straps off of the ears.

Correct position.

2. Back headgear strap is sliding.

Loosen the top strap and move the back strap down toward the neck.

Re-adjust the side straps and chin support band for comfort.

3. If the patient has long and silky hair, place the hair over the back

of the headgear strap.

Fitting Tips

HEADGEAR FITTING TIPS

CAUTION: U.S. federal law restricts this device to sale by or on the order of a physician.

Respironics is a registered trademark, and OptiLife is a trademark of Respironics, Inc.

and its affiliates. Velcro is a registered trademark of Velcro Industries B.V

HOECH JJ 11/22/06 MCI 4100876 PN 1040025

Customer Service: 800-345-6443 or 724-387-4000

Respironics Europe, Africa, Middle East: +33-1-47-52-30-00

Respironics Asia Pacific: +852-3194-2280

optilife.respironics.com

1.Try a different size cushion.

2. Verify chin support band is not

over tightened.

3.Move headgear side straps to front slot.

4. Rotate cushion for better placement

in nostrils.

5. Re-adjust mask fitting while lying down.

6. Review “Tube Management” section

(below) for helpful tips.

With all lightweight masks, tube

management is an important step

to assure seal and stability.

The Velcro®ring provided with

the OptiLife mask can be used to

help manage the CPAP tubing to

optimize mask stability.

CUSHION SEAL FITTING TIPS

TUBE MANAGEMENT
