ReSound Magna MG90 Manuel utilisateur

NON WIRELESS

BEHIND-THE-EAR (BTE)

RECEIVER-IN-THE-EAR (RIE)

USER GUIDE

ReSound VeaTM

ReSound MagnaTM

Introduction

Congratulations on the purchase of your new hearing instruments. ReSound’s innovative sound

technology and design, combined with the customised set-up selected by your hearing care

professional, will make hearing a more enjoyable experience. Hearing instruments will enable

you to hear sounds that you may not have heard in years because of your hearing loss. Practice

and a positive attitude are important in learning to use hearing instruments. Your ReSound instru-

ments have been adjusted according to your individual hearing loss and needs. Some people

adjust quickly to wearing hearing instruments in their ears and hearing new sounds; other

people may need more time.

Please read this manual carefully in order to wholly beneﬁt from the use of your hearing instru-

ments. With proper care, maintenance, and usage, your hearing instruments will aid you in bet-

ter communication for many years. Ask your hearing care professional if you have any questions.

ReSound is a registred trade mark of GN ReSound A/S

Intended use

Generic air-conduction hearing instruments are wearable sound-amplifying devices intended to

compensate for impaired hearing. The fundamental operating principle of hearing instruments

is to receive, amplify, and transfer sound to the ear drum of a hearing impaired person.

Hearing instrument model:

Left serial number:

Receiver tube length:

Right serial number:

Tube type: Dome size:

Model VE60 VE62 VE70 VE77 VE80 VE88 MG90

Battery size 312 312 13 13 13 13 675

SYMBOLS

WARNING points out a situation that could lead to serious injuries,

i CAUTION indicates a situation that could lead to minor and moderate injuries.

i Advice and tips on how to handle your hearing instrument better.

CONTENTS

Introduction ............................2

Description of the BTE

hearing instruments ......................6

Description of the RIE hearing instruments ....10

Getting started.........................12

SmartStart ............................12

Battery door lock .......................13

Inserting/Replacing the battery.............13

Low battery indicator ....................14

Inserting/Removing hearing instruments ......14

Removal (custom earmolds) ...............16

Removal (domes) .......................16

Operation of the hearing instrument .........17

Telephone use .........................21

Telecoil (optional) .......................21

PhoneNow............................22

Tele-loop systems ......................24

Direct audio input (optional) ...............24

Connecting/Disconnecting audio boots ......25

Care and maintenance...................26

Daily maintenance ......................27

Maintenance for BTE hearing instruments ....27

Cleaning earmoulds .....................28

Cleaning thin tubes and domes ............28

How to apply domes ....................29

Standard domes .......................29

Tulip domes ...........................29

Maintenance for the RIE hearing instruments ..30

The receiver tube .......................30

Cleaning the receiver tubes and domes ......31

Cleaning RIE or moulds ..................31

Changing wax guard for receiver tube .......32

How to apply domes ....................33

Temperature test, transport and

storage information .....................35

General precautions.....................35

General warnings.......................36

Battery warning information ...............37

Troubleshooting Guide ..................38

Troubleshooting Guide ..................40

Technical Data .........................42

Warranty and repairs ....................43

Description of the BTE

hearing instruments

VE360-DI

VE370-DVI, VE270-DVI, VE170-VI

VE380-DVI, VE280-DVI, VE180-VI

MG490-DVI, MG290-DVI

1. Programme button

2. Battery compartment & On/Off switch

3. Sound outlet

4. Front microphone inlet

5. Back microphone inlet

6. Volume control (optional)

7. Direct audio input

8. Left/Right indicator

(Left=Blue/Right=Red)

9. Battery door lock

10. Model

11. Product name

12. Serial number

13. Battery door

543

8/9

Description of the BTE

hearing instruments

VE377-DVI, VE377-DVIO,VE388-DVI

1. Programme button

2. Battery compartment & On/Off switch

3. Sound outlet

4. Front microphone inlet

5. Back microphone inlet

6. Volume control (optional)

7. Direct audio input

8. Left/Right indicator (Left=Blue/

Right=Red)

9. Battery lock (optional)

10. Model

11. Manufacturer

12. Serial number

13. Earhook

14. Earmold and tubing

15. Thin Tube

16. Domes/earmold

a. Open dome

b. Tulip-Dome

c. Custom earmold

17. Sports lock (optional)

8/9

12 15

16.a

14 13 16.c

16.b

Traditional ﬁtting

(earmold and tube)

Open ﬁtting

(Thin Tube and dome)

1211

Description of the RIE hearing instruments

VE362-DVIR

1. Receiver tube

2. Receiver Open Dome

3. Receiver Tulip Dome

4. Receiver Power Dome

5. RIE mould

6. Sports lock

7. Battery compartment

8. Receiver

9. Push button

10. Volume Control (optional)

11. NP receiver tube

12. HP receiver tube

13. Left/right indicator

14. Model, and serial number

15. Direct audio input
