Repotec RP-1716RT Manuel utilisateur

16-P 10/100Mbps NWay Switch

User's Manual

V2.0

CE Declaration of conformity

This equipment complies with the requirements relating to electromagnetic compatibility,

EN 55022 classAfor ITE, the essential protection requirement of Council Directive

89/336/EEC on the approximation of the laws of the Member States relating to

electromagnetic compatibility.

FCC Warning

This equipment has been tested and found to comply with the limits for a ClassAdigital

device, pursuant to Part 15 of the FCC Rules. These limitations are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if no installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

 Reorient or relocate the receiving antenna.

 Increase the separation between the equipment and receiver.

 Connect the equipment intoa different outlet from that the receiver is connected.

 Consult your local distributors or an experienced radio/TV technician for help.

 Shielded interface cables must be used in order to comply with emission limits.

Changes or modifications to the equipment, which are not approved by the party

responsible for compliance could affect the user’s authority to operate the equipment.

Company has an on-going policy of upgrading its products and it may be possible that

information in this document is not up-to-date. Please check with your local distributors

for the latest information. No part of this document can be copied or reproduced in any

form without written consent from the company.

Trademarks:

All trade names and trademarks are the properties of their respective companies.

Table of Contents

1. Unpacking Information

2. Introduction To 16-Port NWay Switch

2.1 General Description

2.2 Key Features

2.3 The Front Panel

2.3.1 System LEDs

2.3.1.1 Power LED

2.3.2 PortLEDs

2.3.2.1 100M LED

2.3.2.2 Link/Act LED

2.4 The Rear Panel

2.4.1 Power Connecting

3. InstallingAnd Using 16-Port NWay Switch

3.1 Installing the 16-Port NWay Switch

3.1.1 Desktop Installation

3.1.2 Rack-Mount Installation

3.1.3 Installing Network Cables

3.1.3.1 Station Connection with Twisted-Pair Cable

3.1.3.2 Switch to Switch Connections with Twisted-Pair Cable

3.1.3.3 NetworkApplication

4. Switching Operation

4.1 MAC Address Table & Learning

4.2 Filtering and Forwarding

4.3 Store and Forward

5. Product Specifications

1. Unpacking Information

Thank you for purchasing the 16-port NWay switch. Before you start, please check

all the contents of this package.

The product package should include the following:

1. One 16-port NWayswitch

2. One power cord

3. Rubber foot and screws

4. Rack-mount brackets (optional for 11-inch model)

5. User’sManual

2. Introduction To 16-Port NWay Switch

2.1 General Description

The device is a powerful, high-performance Fast Ethernet switch, with all 16 ports

capable of 10 or 100Mbps auto-negotiation operation (NWay) which means the

switch could automatically negotiate with the connected partners on the network

speed and duplex mode. It is ideal for micro-segmenting large networks into

smaller, connected subnets for improved performance, enabling the bandwidth

demanding multimedia and imaging applications. Moreover, the 10/100Mbps

auto-sensing ability provides an easy way to migrate 10Mbps to 100Mbps networks

with no pain. Compared to the shared 10Mbps or 100Mbps networks, the switch

delivers a dedicated 10/100Mbps connection to every attached client with no

bandwidth congestion issue.

Store-and-forward switching mode promises the low latency plus eliminates all the

network errors, including runt and CRC error packets. To work under full-duplex

mode, transmission and reception of the frames can occur simultaneously without

causing collisions as well as double the network bandwidth.

The switch is plug-n-play without any software to configure and also fully compliant

with all kinds of network protocols. Moreover, the rich diagnostic LEDs on the

front-panel provide the operating status of individual port and whole system.

For network connection:

The switch can use the following types of cabling:

 10BASE-T Category 3, 4 or 5 UTP/STP

 100BASE-TX Category 5 UTP/STP

Category 5 cable is preferred to use with this product in structured wiring

environments. This will ensure correct operation of all ports at 10Mbps or

100Mbps.

2.2 Key Features

The switch provides the following key features:

 Complies with 10BASE-T specifications of the IEEE802.3 standard

 Complies with 100BASE-TX specifications of the IEEE802.3u standard

 Sixteen RJ-45 ports for 100BASE-TX and 10BASE-T connectivity

 Supports NWay protocol for speed (10/100Mbps) and duplex mode (Half/Full)

auto-detection

 Supports MDI/MDI-X auto crossover

 Supports full and half duplex operation on all ports

 Wire-speed packet filtering and forwarding rate

 Store-and-forward architecture filters fragment & CRC error packets

 Supports 8K MAC address entries and 128 entries of CAM

 512KBytes buffer memory

 Supports extensive LED indicators for network diagnostics

 Internal universal switching power supply (100 ~ 240VAC)

 FCC ClassA, CE

2.3 The Front Panel

The front panel of the switch is shown as below.

11-inch model

19-inch model

The auto-negotiation feature of the switch allows each port of the device running at

one of the following four operation modes:

1. 100Mbps full-duplex

2. 100Mbps half-duplex

3. 10Mbps full-duplex

4. 10Mbps half-duplex

＊Each 10/100Mbps port supports auto MDI-X capability that is the port could

connect either the PC or switch without any cable adjustment.

2.3.1 System LEDs

System LED indicators are located on the front panel for showing the operating

status of the whole device.

2.3.1.1 Power LED

This indicator lights green when the switch is receiving power;

otherwise, it is off.

2.3.2 Port LEDs

Port LED indicators are located on the front panel for showing the operating

status of each port.

2.3.2.1 100M LED

Every port has a 100M LED. Steady green indicates that the port is

operating at 100Mbps. If the LED is off, the link speed is 10Mbps.

2.3.2.2 Link/Act LED

Every port has a Link/Activity LED. Steady green indicates that the port

has good linkage to its associated devices. Flashing green indicates

there is traffic transverses the port.

The following table is a summary of Port LEDs.

If the port is connected but the Link/Activity LED is dark, check the following

items:

1.The switch and the connected device’s power are on or not

2. The port’s cable is firmly seated in its connectors in the switch and in the

associated device.

3. The connecting cable is good and with correct type

4. The connecting device, including any network adapter is functioning.

LED Operation

100M Link speed is 100Mbps (Green)

Link speed is 10Mbps (Off)

Link/Act The port is connected (Green)

The port is transmitting/receiving data (Blinking Green)

2.4 The Rear Panel

The rear panel of the switch is shown as below

11-inch model

19-inch model

2.4.1 Power Connecting

For compatibility with electric service in most areas of the world, the switch’s

power supply automatically adjusts to line power in the range 100~240 VAC

and 50~60 Hz.

Plug the female end of the power cord firmly into the receptacle on the rear

panel of the switch. Plug the other end of the power cord into an electric

service outlet then the power will be ready.

3. InstallingAnd Using 16-Port NWay Switch

3.1 Installing The 16-Port NWay Switch

The switch does not require software configuration. Users can immediately use any

of the features of this product simply by attaching the cables and turning the power

on.

3.1.1 Desktop Installation

Locate the switch on the desktop and place the switch on a clean, flat desk or

table close to a power outlet. Plug in all network connections and the power

cord, then the system is ready.

When deciding where to put the switch, you must ensure:

 It is accessible and cables can be connected easily

 Cabling is away from:

＊Sources of electrical noise such as radios, transmitters and

broadband amplifiers

＊Power lines and fluorescent lighting fixtures.

 Water or moisture can not enter the unit

 Air flow around the unit and through the vents in the side of the case is

not restricted (company recommend that you provide a minimum of 25

mm clearance)

To prolong the operational life of your units:

 Never stack units more than eight high if freestanding.

 Do not place objects on top of any unit or stack

 Do not obstruct any vents at the sides of the case

3.1.2 Rack-Mount Installation (Rack-mount kit is optional)

The switch may standalone, or may be mounted in a standard 19-inch

equipment rack. Rack mounting produces an orderly installation when you

have a number of related network devices. The switch is supplied with optional

rack mounting brackets and screws. These are used for rack mounting the

unit.
