Reolink E1 Series Manuel utilisateur
December 2020
QSG3_B
58.03.001.0156
Reolink E1 Zoom
Quick Start Guide
@ReolinkTech https://reolink.com
EN
Contents
What’s in the Box
Camera Introduction
Set up the Camera
Mount the Camera
Troubleshooting
Specifications
Notification of Compliance
2
3
4
5
8
10
11
1 English
What’s in the Box
2English
Reset Needle
(For E1 Zoom only)
Reolink E1
Series Camera
Quick
Start Guide
Pack of Screws
Surveillance
Sign
Mounting
Hole Template
Mounting Plate Power Adapter
Speaker
Power Port
Micro SD Card Slot
Daylight Sensor
Camera Introduction
Built-in Mic
Status LED
Lens
Reset Button
*Rotate the lens to find the reset
button and the SD card slot.
4English3 English
Meaning of the Status LED:
• On Smartphone
Download and Launch the Reolink App or Client software
and follow the onscreen instructions to finish initial setup.
Scan to download the Reolink App.
Set up the Camera
• On PC
Download path of the Reolink Client: Go to
https://reolink.com > Support > App & Client.
Available on the
WiFi connection failed
Status/LED LED in Blue
WiFi is not configured
Camera is starting up
WiFi connection succeeded
On
Blinking
Mount the Camera
Step 1
Drill two holes on the
wall according to the
mounting hole
template.
Step 2
Insert the two plastic
anchors into the holes.
Step 3
Secure the base unit in
place by tightening the
screws into the plastic
anchors.
Step 4
Align the camera with
the bracket and turn the
camera unit clockwise
to lock it in position.
NOTE:
1. To remove it from the
wall, turn the camera
anticlockwise.
2. In case your camera is
mounted upside down, its
picture shall be rotated
as well. Please go to
Device Settings ->
Display on Reolink
app/Client and click
Rotation to adjust the
image.
6English
5 English
If your camera is not powering on, please try the
following solutions:
• Plug the camera into another outlet.
• Use another 5V power adapter to power up the camera.
If these won't work, please contact Reolink Support
https://support.reolink.com/.
Troubleshooting
Camera Is Not Powering on
If the camera failed to scan QR code on your phone,
please try the following solutions:
• Remove the protective film from the camera lens.
• Wipe the camera lens with a dry paper/towel/tissue.
• Vary the distance (about 30cm) between your camera
Failed to Scan QR Code on Smartphone
8English7 English
Tips for Camera Placement
• Do not face the camera towards any light sources.
• Do not point the camera towards a glass window. Or, it
may result in poor image performance because of the
window glare by infrared LEDs, ambient lights or status
lights.
• Do not place the camera in a shaded area and point it
towards a well-lit area. Or, it may result in poor image
performance. For better image quality, please make sure
that the lighting condition for both the camera and the
capture object is the same.
• For better image quality, it’s recommended to clean the
lens with a soft cloth from time to time.
• Make sure the power ports are not exposed to water or
moisture or blocked by dirt or other elements.
and the mobile phone, which enables the camera to
focus better.
• Try scanning the QR code under a brighter atmosphere.
If these won't work, please contact Reolink Support
https://support.reolink.com/.
If the camera fails to connect to WiFi, please try the
following solutions:
• Please make sure the WiFi band meets the network
requirement of the camera.
• Please ensure you have entered the correct
WiFi password.
• Put your camera close to your router to ensure a
strong WiFi signal.
• Change the encryption method of the WiFi network to
WPA2-PSK/WPA-PSK (safer encryption) on your router
interface.
• Change your WiFi SSID or password and make sure
that SSID is within 31 characters and password is within
64 characters.
• Set your password using only the characters on the
keyboard.
If these won't work, please contact Reolink Support
https://support.reolink.com/.
WiFi Connection Failed During Initial
Setup Process
10English9 English
Display Resolution:
5MP(E1 Zoom)/4MP(E1 Pro)/3MP(E1)
IR Distance: 12 meters (40ft)
Pan/Tilt Angle: Horizontal: 355°/Vertical: 50°
Power Input: DC 5V/1A
Hardware
Specifications
12English
11 English
Frame Rate: 15fps (default)
Audio: Two-way audio
IR Cut Filter: Yes
Software Features
Operating Frequency:
2.4 GHz (E1)/Dual-band (E1 Pro/E1 Zoom)
Operating Temperature: -10°C to 55°C (14°F to 131°F)
Size: Φ76 x 106 mm
Weight: 200g (E1/E1 Pro)/250g(E1 Zoom)
General
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
• this device may not cause harmful interference, and
FCC Compliance Statement
Notification of Compliance
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
• this device must accept any interference received,
including interference that may cause undesired
operation.
14English13 English
This product comes with a 2-year limited warranty that
is valid only if purchased from Reolink ocial stores or a
Reolink authorized reseller. Learn more:
https://reolink.com/warranty-and-return/.
Limited Warranty
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. This
equipment shall be installed and operated with minimum
distance 20cm between the radiator & body.
FCC RF Exposure Warning Statements
Reolink declares that this device is in compliance with
the essential requirements and other relevant provisions
of Directive 2014/53/EU.
This marking indicates that this product should not be
disposed with other household wastes throughout the
EU. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, recycle
it responsibly to promote the sustainable reuse of
material resources. To return your used device, please
use the return and collection systems or contact the
retailer where the product was purchased. They can take
this product for environment safe recycling.
Simplified EU Declaration of Conformity
Correct Disposal of This Product
NOTE: We hope that you enjoy the new purchase. But if
you are not satisfied with the product and plan to return,
receiver.
• Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
16English15 English
Use of the product is subject to your agreement to the
Terms of Service and Privacy Policy at reolink.com.
Keep out of the reach of children.
Terms and Privacy
By using the Product Software that is embedded on the
Reolink product, you agree to the terms of this End User
License Agreement (“EULA”) between you and Reolink.
Learn more: https://reolink.com/eula/.
End User License Agreement
This device contains licence-exempt transmitter(s)/
receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt RSS(s).
ISED Statements
The device has been evaluated to meet general RF
exposure requirements. The device can be used in
Radio Frequency Exposure Statement for IC
we strongly suggest that you reset the camera to
factory default settings and take out the inserted SD
card before returning.
Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including
interference that may cause undesired operation of the
device.
L’émetteur/récepteur exempt de licence contenu dans le
présent appareil est conforme aux CNR d’Innovation,
Sciences et Développement économique Canada
applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes:
(1) L' appareil ne doit pas produire de brouillage;
(2) L' appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible
d' en compromettre le fonctionnement.
18English17 English
OPERATING FREQUENCY
2412MHz-2462MHz
5180MHz-5240MHz
5745MHz-5825MHz
Technical Support
If you need any technical help, please visit our official
support site and contact our support team before
returning the products https://support.reolink.com/.
mobile exposure conditions. The min separation distance
is 20cm.
Déclaration d'exposition aux radiofréquences pour IC
L'appareil a été évalué pour répondre aux exigences
générales en matière d'exposition aux RF. L'appareil peut
être utilisé dans des conditions d'exposition mobiles. La
distance de séparation minimale est de 20cm.
Operation of this device is restricted to indoor use only.
(5180-5240MHz)
Le fonctionnement de cet appareil est limité à une
utilisation en intérieur uniquement. (5180-5240MHz)
