Reolink Argus Eco Manuel utilisateur
・ RMA Contact
Visit https://support.
reolink.com
Submit a Request with
your Order No.
Reolink After Service
will contact with you
for processing
Order
RMA
・ Technical Support
Submit a Request
Technical
support
Troubleshooting
your problem
Visit https://support.
reolink.com
QSG1_A
Reolink Argus Eco
Quick Start Guide
EN/DE/FR/IT/ES
Reset Needle
Pack of Screws
x2
Surveillance Sign
x1
Micro USB
Cable
x1
Reolink Argus Eco
x1
Antenna
x1
Outdoor Security
Mount
x1
Quick Start Guide
x1
Mounting
Hole Template
x1
What’s in the Box
Contents
English
Deutsch
French
Italian
Spanish
1
15
27
39
51
1English
General Introduction
Built-in Mic
Lens
Status LED
Daylight Sensor
Built-in PIR Sensor
Micro SD Card Slot
Battery Status LED
Speaker
Reset hole
On/o switch
Micro USB Port
Antenna
Turn on the Camera
Install the Antenna
1. Reolink Argus Eco is turned o by default, please turn it on before setting up the camera.
Note:
If the camera will not be
in use for a very long time,
it’s suggested to turn it o.
The LED in Red (Wi-Fi connection failed)
Blinking: Standby status
On: Working status
The LED in Blue (Wi-Fi connection succeeded)
Blinking: Standby status
On: Working status
Please install the Antenna to the
camera. Turn the antenna base in a
clockwize motion to connect. Leave
the antenna in a vertical position for
best reception.
3English
2 English
5. Follow the steps to finish the Wi-Fi settings.
6. After you created a password for your camera, please follow the steps to sync the time, and then
start live view or go to “Device Settings”.
4. A QR code will be generated on the phone. Please place the QR code on your phone towards Reolink
Argus Eco camera’s lens at a distance of about 20cm (8 inches) to let the camera scan the QR code.
Please make sure that you’ve ripped the protection film of the camera’s lens.
Download and install the Reolink App in App Store (for iOS) and Google Play (for Android).
Available on the Get it on
Setup Camera on Reolink App (For Smartphone)
Note:To help scanning, please click the QR code to display in full screen.
Add New Device
Device Settings
Menu
Access the Live View
Battery Status
r
Enable/Disable PIR
Motion Sensor
(In default, the PIR
sensor is enabled.)
20 cm ( 8 inches )
1. Please click the “ ”
button in the top right corner
to add the camera.
2. Scan the QR code on the
back of the camera.
3. Click “Connect to Wi-Fi” to
configure the Wi-Fi settings.
Note：
• Reolink Argus Eco Camera
only supports 2.4GHz Wi-Fi,
5GHz is not supported.
• Your family can click "Access
Camera" for live view after
the initial setup.
Please follow the prompt tone to configure the camera.
4 English 5English
• In LAN
Please download the client software from our ocial website:
https://reolink.com/software-and-manual and install it.
Note: The camera must be first set up on Reolink App before being connected to Reolink Client.
Launch the Reolink Client software and manually add the camera to the Client. Please follow the steps
below.
1. Click “Add Device” on the right-side
menu.
2. Click "Scan Device in LAN".
3. Double click on the camera you
want to add. The information will be
filled in automatically.
4. Input the password created on
Reolink App to log in.
5. Click “OK” to log in.
4. Create a name for the camera displayed on Reolink
Client.
5. Input the password created on Reolink App to log in.
6. Click “OK” to log in.
• In WAN
Note: To save power, the
camera will log out if no
operation is conducted for
about five minute. You
must login again by
clicking the “ ” btton.
Setup Camera on Reolink Client (For PC)
1. Click “Add Device” on the right-side menu.
2. Choose “UID” as the Register Mode.
3. Type in the UID of your camera.
6 English 7English
Attention for Camera Installation
• PIR Sensor Detecting Distance
The PIR senor has 3 sensitivity levels for your adjustment: Low/Mid/High.
Higher sensitivity oers longer detecting distance. The default sensitivity of the PIR sensor is at “Mid”.
Path for adjusting distance in App: Device settings-PIR settings
Note:
Sensitivity Detecting Distance
(For moving vehicles)
High
Mid
Low
Up to 10 meters (30ft)
Up to 6 meters (20ft)
Up to 4 meters (13ft)
Value
81 - 100
51 - 80
0 - 50
To reduce false alarms, please note that:
• Do not install the camera facing any objects with bright lights, including sunshine,
bright lamp lights, etc.
• Do not place the camera too close to a place where there are frequently moving
vehicles. Based on our numerous tests, the recommended distance between the
camera and the vehicle is 16 meters (52ft).
• Stay away from the outlets, including the air conditioner vents, humidifier outlets, the
heat transfer vents of projectors, etc.
• Do not install the camera where there are strong winds.
• Do not install the camera facing the mirror.
• Keep the camera at least 1 meter away from any wireless devices, including Wi-Fi
routers and phones in order to avoid wireless interference.
!Important Notes for Reducing
False Alarms
Up to 10 meters (33ft)
Up to 12 meters (40ft)
Up to 16 meters (52ft)
Detecting Distance
(For moving and living things)
8 English 9English
!
Charge the Battery
Charging indicator: Green LED: Fully charged
Please learn some useful ways to maximize the battery life in this post:
https://reolink.com/faq/extend-battery-life/
Reolink Argus Eco is not designed for 24/7 full capacity running or around-the-clock live streaming. It’s
designed to record motion events and remotely view live streaming only when you need it.
Important Safeguards on Rechargeable
Battery Use
1. Charge the battery with a
power adapter.
2. Charge the battery with the
Reolink solar panel.
Orange LED: Charging
When installing the camera, please install the camera
angularly (the angle between the sensor and the detected
object is larger than 10°) for eective motion detection. If
the moving object approaches the PIR sensor vertically,
the sensor may not detect the motion events.
The ideal viewing distance is 2-10 meters (7-33ft), which
enables you to recognize a human.
Entrance
θThe path of the
moving object
FYI:
• The PIR sensor’s detecting distance: 23ft (in default)
• The PIR sensor’s detecting angle: 100° (H)
• Camera Ideal Viewing
Distance
• PIR Sensor Installation Angle
10°
θ
2-3 meters
Ideal Viewing Distance:
2-10 meters (7-33ft)
Note:
• The battery is built-in,please do not remove it from the camera.
• Please note that the solar panel is NOT included in the package. You can buy the solar panel on Reolink ocial online store.
10 English 11English
1. Please charge the rechargeable battery with a standard and high-quality DC 5V or 9V battery charger.
2. If you want to power the battery via the solar panel, please note that the battery is ONLY compatible
with Reolink solar panel. You cannot charge the battery with other solar panel brands.
3. Please charge the battery in temperatures between 0°C and 45°C.
4. Always use the battery in temperatures between -20°C and 60°C.
5. Please make sure the battery compartment is clean.
6. Please keep the USB charging port dry, clean and free of any debris and make sure the battery
contacts are aligned.
7. Always make sure the USB charging port is clean. Please cover the USB charging port with the rubber
plug after the battery has been fully charged.
8. Never charge, use or store the battery near any ignition sources, such as fire or heaters.
9. Always store the battery in a cool, dry and ventilated environment.
10. Never store the battery with any hazardous or combustible objects.
11. Do keep the battery away from children.
12. Do not short-circuit the battery by connecting wires or other metal objects to the positive (+) and
negative (-) terminals. Do NOT transport or store the battery with necklaces, hairpins or other metal
objects.
13. Do NOT disassemble, cut, puncture, short-circuit the battery, or make it dispose of in water, fire,
microwave ovens and pressure vessels.
14. Do NOT use the battery if it gives o an odor, generates heat, becomes discolored or deformed, or
appears abnormal in any ways. If the battery is being used or charged, remove the battery from the
device or the charger immediately, and stop using it.
15. Always follow the local waste and recycle laws when throwing the used battery away.
How to Install
Security Mount
Screw the security mount into
the wall.
Step 1
Screw the antenna to the
camera.
Step 2
Loose the screw and adjust the
camera to the proper direction.
Step 4
Tighten the screw .
Step 5
Screw the camera to the security
mount.
Step 3
12 English 13English
How to Install
Tree Mount
Thread the hook & loop strap
through the slots.
Step 1
Screw the plate to the security mount.
Step 2
Fasten the warp strap to the tree.
Step 3
Screw the camera to the security
mount, adjust its direction and tighten
the knob to fix it.
Step 5
Screw the antenna to the camera.
Step 4
Kamera einschalten
Antenne anbringen
Hinweis:
Wenn Sie die Kamera längere
Zeit nicht benutzen, wird es
vorgeschlagen, die Kamera
auszuschalten.
Bringen Sie die Antenne an der Kamera
an, dann drehen Sie die Antenne im
Uhrzeigersinn, um sie zu befestigen.
Richten Sie die Antenne vertikal aus, um
besseren WLAN-Empfang zu ermöglichen.
1．Standardmäßig ist Reolink Argus Eco ausgeschaltet. Schalten Sie sie bitte vor der Kameraeinrichtung
ein.
DE
DE
15Deutsch
14 English
5. Befolgen Sie die Schritte, um die WLAN-Einstellungen zu beenden.
6. Nachdem Sie ein Passwort für Ihre Kamera erstellt haben, folgen Sie bitte den Schritten, um die
Uhrzeit zu synchronisieren. Starten Sie dann die Live-Ansicht oder gehen Sie zu „Geräteeinstellungen"
für weitere Konfiguration.
4. Auf dem Handy erscheint ein QR-Code. Bitte halten Sie den QR-Code auf Ihrem Handy in einer
Entfernung von etwa 20 cm vor die Linse der Reolink Argus Eco oder Pro Kamera, damit die Kamera
den QR-Code scannen kann. Bitte vergewissern Sie sich, dass Sie den Schutzfilm auf der Kameralinse
entfernt haben.
Suchen Sie im App Store (für iOS) oder in Google Play (für Android) nach „Reolink“, führen Sie den
Download durch und installieren Sie die App.
Available on the Get it on
Richten Sie die Kamera auf der Reolink App ein
Neues Gerät
hinzufügen
Geräteeinstellungen
Menü
Live-View
Akkustatus
r
PIR-Sensor aktivieren
/deaktivieren
20 cm ( 8 inches )
1. Klicken Sie bitte auf den
Knopf„ “ oben rechts, um
die Kamera hinzuzufügen.
2. Scannen Sie den QR-Code
auf der Rückseite der Kamera.
3. Klicken Sie auf „WLAN
Verbindung“, um fortzufahren.
Hinweis：
• Die Kamera Reolink Argus
Eco unterstützt nur 2,4GHz
WLAN, kann nicht 5GHz WLAN
unterstützen.
• Ihre Familie kann nach der
Erstkonfiguration über „Auf
Kamera zugreifen“ zur Live
Ansicht gelangen.
Befolgen Sie bitte die Ansage, um die Kamera zu konfigurieren
Hinweis:Um den Scanprozess zu vereinfachen, klicken Sie den QR-Code an, damit er in Vollbild
angezeigt wird.
16 Deutsch 17Deutsch
Autres manuels pour Argus Eco
4
Table des matières
Langues :
Autres manuels Reolink Caméra de sécurité
Reolink
Reolink B800 Guide de démarrage rapide
Reolink
Reolink Argus PT Guide de démarrage rapide
Reolink
Reolink Argus 2 Manuel utilisateur
Reolink
Reolink Lumus Manuel utilisateur
Reolink
Reolink E1 Series Manuel utilisateur
Reolink
Reolink Argus 2 Manuel utilisateur
Reolink
Reolink E1 Series Guide de démarrage rapide
Reolink
Reolink Duo 2 WiFi Manuel utilisateur
Reolink
Reolink RLC-810A Guide de démarrage rapide
Reolink
Reolink Argus 2 Manuel utilisateur
Reolink
Reolink RLC-810A Manuel utilisateur
Reolink
Reolink RLC-510WA Manuel utilisateur
Reolink
Reolink TrackMix PoE Manuel utilisateur
Reolink
Reolink Argus 3 Guide de démarrage rapide
Reolink
Reolink RLC-833A Guide de démarrage rapide
Reolink
Reolink Argus Eco Manuel utilisateur
Reolink
Reolink Argus Eco Ultra Manuel utilisateur
Reolink
Reolink B800 Manuel utilisateur
Reolink
Reolink Argus Eco Guide de démarrage rapide
Reolink
Reolink E1 Series Manuel utilisateur
