Reolink Argus 2 Guide de démarrage rapide
Reolink Argus 2/Argus Pro
Operational Instruction
EN/NO/SV
62762
July, 2019
QSG7_A
Technical Support
If you need help, please contact Reolink before returning your product. Most questions can be
answered through our online support center at https://support.reolink.com.
Technische Unterstützung
Wenn Sie Hilfe brauchen, kontaktieren Sie bitte Reolink Support Team zuerst, bevor Sie Ihre
Bestellung zurücksenden.Meiste Fragen oder Probleme können von unserem Online Support
Center beantwortet und gelöst werden: https://support.reolink.com.
Support technique
Si vous avez besoin d’aide, veuillez contacter Reolink avant de retourner votre produit. La
plupart des questions peuvent être répondues via notre centre de support en ligne à l'adresse
https://support.reolink.com.
Supporto Tecnico
Se avete bisogno di aiuto, le chiediamo gentilmente di contattare Reolink prima di restituire il
prodotto.La maggior parte delle domande può essere risolta tramite il nostro centro di
assistenza online all'indirizzo https://support.reolink.com.
Soporte técnico
Si necesita ayuda, comuníquese con Reolink antes de devolver su producto. La mayoría de las
preguntas se pueden responder a través de nuestro centro de soporte en línea en
https://support.reolink.com.
Shenzhen Reo-link Digital Technology Co, Ltd.
11th floor, Building C, Unisplendour Information Harbour, North High-Tech Zone, Nanshan
District, Shenzhen, China, 518057
https://reolink.com
https://support.reolink.com
Pettenkoferstraße 18,10247,Berlin,Germany
BellaCocool GmbH
REP
Contents
What’s in the Box
* The camera and the rechargeable battery are packed separately in the same package.
* Please dress the camera with the skin for better weatherproof performance when you install the
camera outdoors.
What’s in the Box
General Introduction
Install the Rechargeable Battery to the Camera
Set up Camera on Reolink App (For Smartphone)
Set up Camera on Reolink Client (For PC)
Attention for Camera Installation
Charge the Battery
Installation Guides
Troubleshooting
Specifications
Notification of Compliance
1
2
3
4
6
8
11
13
17
18
18
Argus 2/Argus Pro Camera x1
Wall Mount (Only for Argus 2) x1
Outdoor Security Mount x1
Rechargeable Battery * x1
Quick Start Guide x1
Skin * x1
Power Cable x1
Reset Needle x1
Surveillance Sign x1
Screws (in pack) x1 (x2 for Argus 2)
Mounting Hole Template x1 (x2 for Argus 2)
EN
1English
General Introduction
The LED in Red (WiFi connection failed)
Blinking: Standby status
On: Working status
The LED in Blue (WiFi connection succeeded)
Blinking: Standby status
On: Working status
Micro SD Card Slot
Daylight Sensor
Lens
Status LED
Built-in Mic
Built-in PIR Motion Sensor
Speaker
Wall Mount
Reset Hole
Press the reset button with a
pin to restore factory settings.
Only for Argus 2
Install the Rechargeable Battery to the Camera
!• Pleasepressthebutton(onthetopofthebackcasing),andslide thebackcasing
downwardtocloseit.Thebuttonalsoneeds to be closedfirmlyfor goodweatherproof
performance.
• For the weatherproof performance, always cover the USB charging port with the rubber
plug.
3English2 English
1. Please click the “ ” button
in the top right corner to add the
camera.
2. Scan the QR code on the back
of the camera.
3. Click “Connect to Wi-Fi” to
configure the wifi settings.
NOTICE:
• Reolink Argus 2/Argus Pro
camera only supports 2.4 GHz
Wi-Fi. 5 GHz is not supported.
• Your family can click "Access
Camera" for live view after the
initial setup.
Download and install the Reolink App on App Store (for iOS) and Google Play (for Android).
Available on the Get it on
Set up Camera on Reolink App (For Smartphone)
Please follow the prompt tones to configure the camera.
4. A QR code will be generated on the phone. Please place the QR code on your phone towards
Reolink Argus 2 or Pro camera’s lens at a distance of about 20cm (8 inches) to let the camera
scan the QR code. Please make sure that you’ve ripped the protection film of the camera’s lens.
5. Follow the steps to finish the WiFi settings.
6. After you created a password for your camera, please follow the steps to sync the time, and
then start live view or go to “Device Settings”
Add New Device
Device Settings
Menu
Access the Live View
Battery Status
Enable/Disable PIR
Motion Sensor
(In default, the PIR sensor
is enabled.)
20 cm ( 8 inches )
5English4 English
r
≈30cm(12 inch)
• In Dierent Network (In WAN)
NOTICE: To save power, the
camera will log out if no
operation is conducted for
about 5 minutes. You need to
log in the camera again by
clicking the “ ” button.
1. Click “Add Device” on the right-side menu.
2. Choose “UID” as the Register Mode.
3. Type in the UID of your camera.
4. Create a name for the camera displayed on Reolink Client.
5. Input the password created on Reolink App to log in.
6. Click “OK” to log in.
Please download the Reolink Client software from our ocial website:
https://reolink.com/software-and-manual/ and install it.
NOTICE: It’s recommended to set up the camera on Reolink App first before adding the
camera to Reolink Client.
Launch the Reolink Client software and manually add the camera to the Client. Please
follow the steps below.
1. Click “Add Device” on the
right-side menu.
2. Click "Scan Device in LAN".
3. Double click on the camera you
want to add. The information will
be filled in automatically.
4. Input the password created on
Reolink App to log in.
5. Click “OK” to log in.
• In Same Network
(In LAN)
Set up Camera on Reolink Client (For PC)
7English6 English
• PIR Sensor Detecting Distance
NOTICE:
1. Path for adjusting distance in App: Device settings-PIR settings
2. Path for adjusting distance in Client: Device settings-RF Alarm
3. Higher sensitivity oers longer detecting distance, but it would lead to more false alarms. You
are advised to set up the sensitivity level to “Low” or “Mid” when you install the camera outdoors.
Sensitivity Detecting Distance
(For moving and living things)
Detecting Distance
(For moving vehicles)
High
Mid
Low
Up to 9 meters (30ft)
Up to 6 meters (20ft)
Up to 4 meters (13ft) Up to 10 meters (33ft)
Up to 12 meters (40ft)
Up to 15 meters (50ft)
The PIR senor has 3 sensitivity levels for your adjustment: Low/Mid/High.
Higher sensitivity oers longer detecting distance. The default sensitivity of the PIR sensor is at
“Mid”.
!
To reduce false alarms, please note that:
• Do not install the camera facing any objects with bright lights, including
sunshine, bright lamp lights, etc.
• Do not place the camera too close to a place where there are frequently
moving vehicles. Based on our numerous tests, the recommended distance
between the camera and the vehicle is 15 meters (50ft).
• Stay away from the outlets, including the air conditioner vents, humidifier
outlets, the heat transfer vents of projectors, etc.
• Do not install the camera where there are strong winds.
• Do not install the camera facing the mirror.
• Keep the camera at least 1 meter away from any wireless devices,
including Wi-Fi routers and phones in order to avoid wireless interference.
Important Notes for Reducing
False Alarms
Attention for Camera Installation
9English
8 English
When installing the camera, please install the
camera angularly (the angle between the sensor
and the detected object is larger than 10°) for
eective motion detection. If the moving object
approaches the PIR sensor vertically, the sensor
may not detect the motion events.
The ideal viewing distance is 2-10 meters
(7-33ft), which enables you to recognize a
human.
Entrance
θThe path of the
moving object
FYI:
• The PIR sensor’s detecting distance: 20ft (in
default)
• The PIR sensor’s detecting angle: 120° (H)
• Camera Ideal Viewing
Distance
2-3 meters
10°
θ
Ideal Viewing Distance:
2-10 meters (7-33ft)
!
Charge the Battery
NOTICE: Please note that the solar panel is NOT included in the package. You can buy the solar
panel on Reolink ocial online store.
Reolink Argus 2 or Argus Pro is not designed for 24/7 full capacity running or around-the-clock
live streaming. It’s designed to record motion events and remotely view live streaming only when
you need it.
Please learn some useful ways to maximize the battery life in this post:
https://support.reolink.com/hc/en-us/articles/360006991893
Important Safeguards on Rechargeable Battery Use
2. Charge the battery
separately.
1. Charge the battery when it's
installed to the camera.
3. Charge the battery with the
Reolink Solar Panel.
Charging indicator: Orange LED: Charging Green LED: Fully charged
• PIR Sensor Installation Angle
11English
10 English
1. Please charge the rechargeable battery with a standard and high-quality DC 5V or 9V battery
charger.
2. If you want to power the battery via the solar panel, please note that the battery is ONLY
compatible with Reolink Solar Panel. You cannot charge the battery with other solar panel brands.
3. Please charge the battery in temperatures between 0°C and 45°C.
4. Always use the battery in temperatures between -20°C and 60°C.
5. Please make sure the battery compartment is clean.
6. Please keep the USB charging port dry, clean and free of any debris and make sure the battery
contacts are aligned.
7. Always make sure the USB charging port is clean. Please cover the USB charging port with the
rubber plug after the battery has been fully charged.
8. Never charge, use or store the battery near any ignition sources, such as fire or heaters.
9. Always store the battery in a cool, dry and ventilated environment.
10. Never store the battery with any hazardous or combustible objects.
11. Do keep the battery away from children.
12. Do not short-circuit the battery by connecting wires or other metal objects to the positive (+) and
negative (-) terminals. Do NOT transport or store the battery with necklaces, hairpins or other metal
objects.
13. Do NOT disassemble, cut, puncture, short-circuit the battery, or make it dispose of in water, fire,
microwave ovens and pressure vessels.
14. Do NOT use the battery if it gives o an odor, generates heat, becomes discolored or deformed,
or appears abnormal in any ways. If the battery is being used or charged, remove the battery from
the device or the charger immediately, and stop using it.
15. Always follow the local waste and recycle laws when throwing the used battery away.
• Skin (for Argus 2)
Installation Guides
Step 1
Please dress the Reolink
Argus 2 camera with the skin
provided in the package.
Step 2
The skin has an anti-falling
safety rope. Please fasten the
other end of the rope to the
wall mount when mounting it
to the wall.
Step 3
Stick the camera on the wall
mount and twist the camera in
any direction.
Please dress the camera with the skin for better weatherproof performance when you install the
camera outdoors.
13English
12 English
• Wall Mount
Step 1
Press the button to release the
plate from the security mount.
Step 3
Latch the security mount on
its plate. (Make sure the top
edge of the backing plate is
inserted into the mount.)
Step 4
Press the security mount
button until its plate clicks into
the mount.
Step 5
Screw the camera, adjust its
direction and tighten the knob
to fix it.
Step 2
Screw the security mount
plate into the wall.
• Tree Mount
Step 4
Latch the security mount on
its plate (make sure the top
edge of the backing plate is
inserted into the mount.)
Step 1
Press the button to release the
plate from the security mount.
Step 5
Press the security mount
button until its plate clicks into
the mount.
Step 6
Screw the camera, adjust its
direction and tighten the knob
to fix it.
Step 2
Thread the hook & loop strap
through the slots.
Step 3
Fasten the warp strap to the
tree.
15English
14 English
• Camera is not powering on
If you find your camera is out of work, please
try the following solutions:
• Make sure the battery is correctly inserted
into the compartment. If not, put the battery in.
• Charge the battery using the power adapter
of DC 5V2A and make sure the battery
indicator LED is on. When the green light is
illuminated, the battery is fully charged.
• If you have another spare battery, please
swap the battery for a double check.
• If the camera still can’t be powered on after
trying the troubleshooting steps above,
contact Reolink support team.
If the PIR sensor fails to trigger any kind of
alarm within the covered area, try the
following solutions:
• Make sure that the PIR sensor or the camera
is installed in the direction crossing the
possible intruder.
• Make sure the PIR sensor is enabled or the
time schedule is on and set properly.
• Please check the sensitivity and make sure
it’s set properly.
• Go to Device Settings -> PIR Settings and
make sure the corresponding action is
checked.
• Make sure the battery is not deployed.
• Please reset the camera and try it again.
If you fail to receive any push notification when
motion is detected, try the following solutions:
• Make sure the push notification has been
enabled.
• Make sure the PIR schedule is set properly.
• Check the Internet connection of your phone
and try again.
• Make sure the camera is connected to the
Internet. If the LED indicator under the camera
lens is solid red or flickering red, it means that
your device has disconnected from the
Internet.
• Make sure you’ve enabled notifications on
your phone. Go to the System Settings of your
phone and allow it to push notifications.
• Unable to receive push
notification
• PIR sensor fails to trigger
alarm
Troubleshooting
17English16 English
• Remove the Camera
Step 1
Press the security mount
button to pull the mount out.
Step 2
Unscrew the camera from the
wall mount.
Autres manuels pour Argus 2
8
Ce manuel convient aux modèles suivants
1
Table des matières
Langues :
Autres manuels Reolink Caméra extérieure
Reolink
Reolink Duo 2 Guide de démarrage rapide
Reolink
Reolink E1 Series Guide de démarrage rapide
Reolink
Reolink Duo 2 PoE Guide de démarrage rapide
Reolink
Reolink E1 Outdoor PoE Guide de démarrage rapide
Reolink
Reolink Go PT Manuel utilisateur
Reolink
Reolink Argus Eco Guide de démarrage rapide
Reolink
Reolink Go Manuel utilisateur
Reolink
Reolink Duo Manuel utilisateur
Reolink
Reolink Argus 2E Guide de démarrage rapide
Reolink
Reolink RLC-511WA Guide de démarrage rapide
Reolink
Reolink Argus PT Manuel utilisateur
Reolink
Reolink TrackMix LTE Manuel utilisateur
Reolink
Reolink B5M11WA Guide de démarrage rapide
Reolink
Reolink Argus PT Ultra Guide de démarrage rapide
Reolink
Reolink Argus 2 Guide de démarrage rapide
Reolink
Reolink Lumus Manuel utilisateur
Reolink
Reolink Argus 3 Manuel utilisateur
Reolink
Reolink RLC-1212A Manuel utilisateur
