SES-LOGGER
Instruction Manual
Publ.: 2022-07-01
Copyright © Relianeering AB
Relianeering AB 2 Simple – Easy – Smart
Instruction manual
The SES Logger is a compact handheld single-channel vibration
data collector. It can be used together with the app ReSES
Communicator installed on a mobile device, tablet or telephone,
with Android and iOS.
The app ReSES Communicator transfers the collected data to the
cloud based platform ReSES.net and presents information from
ReSES.net to the user.
It is important to read and understand this instruction
manual before using the SES Logger. Incorrect use
might cause personal harm and/or damage to the SES
Relianeering reserves the right to correct any errors in text or
images and to make any necessary changes to or update the
technical data without prior notice. If you have any questions
regarding technical problems, please contact our support team at
suppor@relianeering.com.
Relianeering AB 3 Simple – Easy – Smart
Safety instructions
• The SES Logger must only be used with an accelerometer
(IEPE) 100 mV/g and connected to the logger with a BNC
connector.
• The SES Logger must only be charged with a 5V DC USB
charger using a Micro USB cable.
• The SES Logger must not be disassembled.
• The SES Logger must not be used or stored in hot/humid,
explosive or ammable environments or close to strong magnetic
elds.
• The SES-logger must not be disassembled. No guarantee is
valid if the logger has been disassembled.
• Relianeering AB take no responsibility for any other use than
described in this manual.
Package content
SES Logger: HW-SES-KIT01
• 1 pc HW-SES Logger, SES Logger instrument
• 1 pc HW-SES-SEN, IEPE Accelerometer 100 mV/g
• 1 pc HW-SES-SEN-MTB, MIL to BNC cable
• 1 pc HW-SES-Z-ADP, Adapter sensor to stud
• 1 pc HW-SES-Z-USB, Micro USB cable for charging
• 1 pc HW-SES-Z-CASE, Plastic case for the kit
• 1 pc Instruction manual
Relianeering AB 4 Simple – Easy – Smart
1. SES Logger button
2. LED ring
3. Battery level indicator (10’)
4. WiFi and pending le
transfer (11’)
5. RFID Tag indicator (12’)
6. BNC connector
7. Settling indicator (1’)
8. System indicator (2’)
9. Micro USB port (for
charging only)
The SES Logger is a data recorder
that records 3 sec vibration data.
The logger is designed for IEPE
sensors (ICP®) with 100 mV/g
sensitivity. The LED-ring indicates
operations and statuses and the
logger vibrates for haptic feedback.
When measurements are stored
in the logger, it automatically
search for a mobile device every 2
minutes to transfer the les. When
all les are transferred, the logger
empty its memory.
5
4
3
2
1
6
7
8
9
Relianeering AB 5 Simple – Easy – Smart
Data Collection
Go to the machine equipped
with CM Points UID.
Open all caps of Machine CM points.
Connect the sensor to the logger BNC
connector.
Turn on the logger. Press and hold the
button for few seconds until vibration
feedback and all LEDs become white.
Attach the accelerometer sensor
with adapter to the stud.
Quarter of turn should be sufficient.
Scan the CM Point UID (RFID TAG)
The distance between logger reader and the
CM Point cap should be less 50 mm. Once
the UID is scanned successfully the user
will feel vibrations and 12’ LED (TAG) will
become green.
CM Point UID
CM Point UID
Acceleration
100mV/g
CM Point UID
Acceleration
100 mV/g
CM Point UID
Relianeering AB 6 Simple – Easy – Smart
Initiate measurement
To initiate measurement press the button.
NOTE: The 12’ LED (TAG) must be green.
If it is not, scan the cap again.
Measurement
1’ LED becomes blue for 5 seconds.
Wait another 3 seconds to complete
the measurement. The rest LEDs become
blue.
Note: If 2’ is red, check connection
between the logger and sensor. Most likely
the sensor is not connected properly
Completing the measurement
When the measurement is completed
the logger will vibrate and all LEDs will
ash in green.
Detach the sensor.
Close the cap.
Move to next CM point.
TAG
TAG
TAG
CM Point UID
reses638
Relianeering AB 7 Simple – Easy – Smart
Data transfer
TAG
Turn on the hotspot
on your mobile device.
The hotspot password MUST be «reses638»
Note: The hotspot must be congured to use
2.4 GHz (for some Android devices). The
logger does not support 5 GHz.
Start ReSES Communicator app
Note: If the app has been already
launched before to activate the hotspot,
we recommend to «kill» it and re-launch it
again.
Start SES Logger
The logger will after two minutes
automatically connect the hotspot
and the ReSES communicator
app to transfer collected data. To
immediately initiate data transfer,
press the logger button twice in
a «double click» manner. During
data transfer the 11’ LED lights in
blue
Note: 11’ LED in green-yellow
indicates that data are on the
logger memory.
Relianeering AB 8 Simple – Easy – Smart
Data transfer notes:
• The logger and phone should be close to each other to keep
a good connection.
• Yellow circle rotation on the app main screen indicates data
transfer between logger and the mobile device.
• Dark blue circle rotation on the app main screen indicates
data transfer to ReSES.net cloud.
• When the logger is empty, 11’ LED will be white.
• The green ashing dot on the app home screen will
disappear when there is no more data to be transferred to
the cloud.
• When you launch the app on the mobile device, it will
immediately initiate data transfer, if there are still not
transferred data on the mobile device.
• The app automatically checks for new data and start
transferring it on every 5th minute.
Relianeering AB 9 Simple – Easy – Smart
1. Dashboard (main window)
2. Blue progress bar (sending data, mobile device to cloud)
3. Yellow progress bar (receiving data from SES logger to mobile
device)
4. WiFi indicator for mobile device (OFF when the hotspot is ON)
5. Time indicator for sending data to ReSES.net (one segment
is one minute, 5 min total). Green ashing dot indicates
availability of data that are not transferred yet.
6. ReSES access indicator (quality of the speed to reses.net)
7. Hotspot indicator for mobile device (needs to be ON for
communication between logger and mobile device)
8. ReSES.net access (login, sites, machines, measurement
point overview etc.)
9. Communication log (data transfer log between logger, mobile
device and cloud)
6
7
8
9
5
4
3
2
1
ReSES
Communicator
Setup your mobile device
1. Download and install the app ReSES communicator (free)
on your mobile device
2. Enable the hotspot on your mobile device.
3. Setup and activate a wireless hotspot on your mobile device
as described in the device's documentation and set the mobile
hotspot network password to: reses638
The name of the network can be of your own choosing.
For some of Android devices make sure that the hotspot band is
2.4 GHz.
ReSES.net access from ReSES Communicator
The app ReSES Communicator allow the user to get information
about the measured points once the data is transferred to the cloud.
The information available in the ReSES Communicator is:
• General status of the site/s
• Measurement points in alarm and in overdue
• A mimic of the machine (Functional Location) with the drive train
• General status of the machines (Functional Locations)
• Vibration level of the CM Points
(Velocity 10–1000 Hz in mm/s rms according ISO 10816)
• Trend for each CM Point
• List of machines in overdue and recently collected number per
CM Points per machine.
