Reliable Empressa S500 Manuel utilisateur

DIGITAL STEAM PRESS

INSTRUCTION MANUAL

MODEL NO.: Empressa S500

Features of the Digital Steam Press.........................................1

Safety Reminders.....................................................................2

Part Identification.................................................................3-4

oreparation for use...........................................................5

oFilling the water tank.......................................................5

oTurning on the power.......................................................5

oSelecting the temperature.................................................6

oSteam Control Notes........................................................7

oPressing............................................................................8

oFinishing Pressing............................................................9

oCleaning.........................................................................10

Suggestion for Success...........................................................11

Use of the Pressing Cushion..................................................12

Techniques for Pressing......................................................13-14

Troubleshooting..................................................................15-16

AA a

Steam Press Operation

CONTENTS

Digital Steam Press Instruction Manual

Digital Steam Press Instruction Manual Page1

Features of the Digital Steam Press

Your Steam Press provides clean, professional results every time!

Reduces ironing time by up to 50%

Multiple dry-heat and steam settings for all types of fabric

Burst setting removes stubborn wrinkles

Variable temperature selection

Automatic shut-off safety feature while open or closed with audible alert

Over 100lbs. of even pressure ensures sharp, long lasting creases

Easy-to-use one hand operation

Protects delicate fabrics like silk

Non-stick padded ironing board cover

Non stick coating on pressing plate reduces starch build-up and eases cleaning (Optional)

Locking handle makes unit portable

Stores upright

Digital Steam Press Instruction Manual

Page2

SAFETY REMINDERS

WARNING - Read all of the instructions and then save them for future reference.

THIS UNIT IS FOR HOUSEHOLD USE ONLY.

SAVE THESE INSTRUCTIONS

To protect against the risk of electric shock, do not immerse

the appliance in water.

Do not let the cord hang over the edge of counters.

Do not allow the cord to touch hot surfaces.

Always allow the appliance to cool for at least thirty minutes

before storing.

Always put the appliance in a secure place on a table or

counter when using.

Do not move the appliance without unplugging it first.

The appliance has very hot surfaces - Do not allow

unsupervised children to use the appliance.

Always disconnect the appliance from the outlet before

filling with or removing water. Be careful to avoid spilling

water on the appliance when filling.

Use distilled water in the appliance. Do not use perfumed or

products containing alcohol in the appliance.

Always disconnect the appliance when not in use.

!This appliance IS NOT intended for use by young children

or infirm persons unless they have been adequately

supervised by a responsible person to ensure that they can

use the appliance safely.

Do not use the appliance if the cord is damaged. Return the

appliance or have the cord repaired by the manufacturer,

service agent or a similarly qualified person.

Do not operate the appliance if it has been dropped or

damaged. Do not disassemble the appliance. Incorrect

reassembly can cause a risk of electric shock. Send it to an

authorized service center for repair.

Do not operate another high wattage appliance on the same

circuit.

This appliance must be grounded. Do not alter the plug or

attempt to defeat this feature.

Be careful. Burns can occur from touching hot metal parts,

hot water or steam.

Digital Steam Press Instruction Manual Page3

PART IDENTIFICATION

The Pressing Handle raises and lowers the Pressing Plate.

By lowering the Pressing Handle until it reaches the lowest

point possible you automatically obtain maximum pressure.

The Locking Knob will lock together the Pressing Plate and

Ironing Board. Turn the Locking Knob to the locked position

to carry or store the Steam Press.

The Steam Burst Button on the handle grip produces a

burst of steam when pressed.

The Pressing plate is the temperature controlled surface that

heats and presses the fabric.

The Ironing Board is the padded surface that holds the

fabric during pressing.

The [Power] Light (Red) is illuminated when the unit is on.

The [Ready] Light (Green) goes off when the Press has

reached the selected temperature.

The [Steam] Ready Light (yellow) goes on when the unit is

ready to produce bursts of steam.

The *POWER* button turn the appliance ON/OFF.

Press the *SELECT* button arrows to set the desired

temperature for each fabric. NOTE: Steam will only be

available on the three highest settings.(wool cotton linen)

The Water Tank slides forward and is filled through holes

in the top. The Water Level can be seen through the front of

the tank. Slide the tank forward for a better view.

The Ironing Board Cover is removable and washable for

extended use.

10.

11.

12.

Digital Steam Press Instruction Manual

Page4

The multiple function safety features of this appliance turns off electric power to the heater when the Pressing plate has been left against

the Ironing Board for about 10 seconds. If the Pressing plate is left in the open (up) position without use after approximately 15 minutes,

the unit will be automatically shut-off. In both cases press the *POWER* button to restart the steam press.

13. The Pressing Cushion is a fabric covered pad used for pressing gathered or

contoured areas such as sleeves, darts, and yokes.

14. The plastic water Spray Bottle is used for dampening fabric before pressing.

15. The Water Container is used for filling the Water Tank.

The following information is provided for service by a qualified electrician only:

Rated voltage: 120V~, 60Hz, 1350W

WARNING:

This appliance must be grounded. Use only the proper type outlet when plugging in the appliance. Do not attempt to override the

ground wire feature.

100

200

300

400ml

Digital Steam Press Instruction Manual Page5

STEAM PRESS OPERATION

STEP1 - PREPARATION FOR USE

Place the appliance on a sturdy work surface. Unlock the Locking Knob.

STEP 2 - FILLING THE WATER TANK

BEFORE PLUGGING IN THE APPLIANCE, fill the water tank;

1. Always make sure the appliance is unplugged before filling the tank.

2. Fill the Water Tank with the Pressing Plate lifted to the raised (up) position.

Slide the Water Tank towards the front of the unit. It will not come

completely out so do not force it to do so. Using the Water Container,

slowly pour the distilled water into the Water Tank Fill Hole(C).

3. Be careful to avoid spilling water onto the Steam Press when filling.

4. Slide the Water Tank back into its recessed position.

STEP 3 - TURNING ON THE POWER

1. Make sure the Locking Knob (D) is in the open position allowing free

movement of the Pressing Plate before plugging in the appliance.

2. Lift the Pressing plate to the fully raised (up) position.

3. Plug the appliance into an electric outlet.

4. Press the *POWER* button and the Red Power light will illuminate.

Digital Steam Press Instruction Manual

Page6

STEP 4 SELECTING THE TEMPERATURE

Press the *SELECT* arrow buttons to choose the kind of fabric you wish to press. Press to move selection to higher setting and

press to move selection to lower setting.

1. Examine the garment label if unsure and look up the type on the chart.

IMPORTANT NOTE: If you can not determine the type of fabric, begin with the lowest setting and increase the temperature as

desired until you obtain the proper results.

2. When the Green [Ready] Light goes off, the Pressing Plate has reached the correct temperature for the desired setting.

3. When changing the setting from a higher selection to a lower setting allow several minutes for the Pressing Plate to cool

sufficiently after making the change.

IMPORTANT NOTE: You may find it more efficient to arrange your fabrics from those requiring the lowest setting to those

requiring the highest setting and proceed accordingly. This will avoid any unnecessary delays as you wait

for the Pressing Plate to cool.

Digital Steam Press Instruction Manual Page7

STEP 5 - STEAM CONTROL

IMPORTANT NOTE: Steam is produced only when the Yellow [Steam]

Ready light is on.

The Green [Ready] Light goes off when the unit has reached the desired

temperature. The Yellow [Steam] Ready Light will come on when the unit is

ready to produce steam.

IMPORTANT NOTE: If this is the first time you are using the Steam Press

or you have been storing it for some time, lift the

Pressing plate into the raised position and press the

Steam Burst Button several times until the steam

begins to flow.

IMPORTANT NOTE: The Steam Burst function can only be used when the

[Steam] Ready Light is on AND the steam press is

in a slightly opened position. Do not use the Steam

Burst function when the steam press is closed, or

you may damage the unit.

IMPORTANT NOTE: Do not press the Steam Burst Button for more than 5

seconds or water may drip on to your garment.

Digital Steam Press Instruction Manual

Page8

IMPORTANT NOTE: If you forget to raise the Pressing Plate or become distracted, the machine will give a warning beep and

automatically shut-off heating after approximately 10 seconds. The steam press will be completely shut-off after

15 minutes of no activity with the press in the open position.

STEP 6 - PRESSING

1. Lift the Pressing Handle (A). The Pressing Plate (B) moves to the up

position.

2. Carefully arrange the garment to be pressed onto the Ironing Board (C).

3. Grab the handle of the Pressing Plate(A) and lower it onto the Ironing

Board (C), capturing the garment between the two halves of the Steam

Press. For light duty Pressing, simply lowering the handle and allowing the

Pressing Plate to rest on the Ironing Board will be sufficient. Return to the

open position. For heavier duty pressing, continue to grab the handle and

press downward until the Pressing Plate is pushed to its lowest position,

then open the press.

4. If the temperature is set high enough you may give the fabric a burst of

steam by pressing the Steam Burst Button (D) to remove stubborn wrinkles.

Lower the pressing plate until it is about two inches from the garment.

Press the Steam Burst Button for about 3-5 seconds. After releasing the

Steam Burst Button you may fully lower the pressing plate.

NOTE: Do not press the Steam Burst Button when the pressure plate is

in its lowest (closed) position.

5. After a few seconds, lift the handle and raise the Pressing Plate back to the

raised position.

Autres manuels pour Empressa S500

Table des matières

Autres manuels Reliable Fer

Reliable

Reliable MAVEN 100IS Manuel utilisateur

Reliable

Reliable i500 Manuel utilisateur

Reliable

Reliable THE BOARD 100IB Manuel utilisateur

Reliable

Reliable 2150IR Manuel utilisateur

Reliable

Reliable THE BOARD 120IB Manuel utilisateur

Reliable

Reliable Velocity V95 Manuel utilisateur

Reliable

Reliable 2300IR Manuel utilisateur

Reliable

Reliable I500A Manuel utilisateur

Reliable

Reliable Empressa S330 Manuel utilisateur

Reliable

Reliable Digital Steam Press Manuel utilisateur

Reliable

Reliable Pantman F1 Manuel utilisateur

Reliable

Reliable Velocity 200IR Manuel utilisateur

Reliable

Reliable Sensor Velocity v200 Manuel utilisateur

Reliable

Reliable The Board C60 Manuel utilisateur

Reliable

Reliable Empressa S330 Manuel utilisateur

Reliable

Reliable 4100IS Manuel utilisateur

Reliable

Reliable MAVEN 120IS Manuel utilisateur

Reliable

Reliable 624HA Manuel utilisateur

Reliable

Reliable The IronMaven J420 Manuel utilisateur

Reliable

Reliable MAVEN 140IS Manuel utilisateur

Reliable

Reliable Velocity V50 Manuel utilisateur

Reliable

Reliable Velocity V50 Manuel utilisateur

Reliable

Reliable VELOCITY 230IR Manuel utilisateur

Reliable

Reliable THE DIGITAL VELOCITY V100 Manuel utilisateur

Manuels Fer populaires d'autres marques

Clatronic

Clatronic DB 3703 Manuel utilisateur

TEFAL

TEFAL FV4093Z0 Manuel utilisateur

Gorenje

Gorenje SIH 2200 BS Manuel utilisateur

Philips

Philips GC6012 Manuel utilisateur

Bosch

Bosch 2 Series Manuel utilisateur

Riffel

Riffel Catena KB-819 Manuel utilisateur

Texi

Texi Hestia Manuel utilisateur

Maxwell

Maxwell MW-3010 Manuel utilisateur

TREVIDEA

TREVIDEA Girmi ST60 Manuel utilisateur

Philips

Philips HI5914/30 Manuel utilisateur

Primula

Primula Vapormat Manuel utilisateur

Magio

Magio MG-541 Manuel utilisateur

Scarlett

Scarlett SC-1334S Manuel utilisateur

Bosch

Bosch Sensixx B22L Manuel utilisateur

Philips

Philips GC651 Manuel utilisateur

Vitek

Vitek VT-1247 VT Manuel utilisateur

Cleanmaxx

Cleanmaxx 3397 Manuel utilisateur

Philips

Philips GC800 Manuel utilisateur
