REID LIFTING Tuffbuilt Pro Series Instructions d'installation

REIDLIFTING.COM

Assembly & Operation Guide

Tuffbuilt Pro Series 2 Bracket

Contents

Fitting device into Bracket 4

500 6

1000 8

Small & Medium 10

Fitting device into Bracket 12

Column 18

Backstay 20

500 22

Lightweight.

Portable. Safe.

Please read the following instructions and

guidance notes carefully. These have been

designed to aid users in carrying out the

correct assembly of the bracket for each of our

compatible lifting systems. Systems compatible

with this product are:

General Speciﬁcation

Maximum rated capacity for personnel lifting - 150kg

Ensure the rating of the Winch is always checked before use

For use with REID lifting products only

Standards

EN1496:2017

EN795:2012 Type B

EN13157:2004+A1:2009

For further information please refer to the technical data sheet

for this product.

Tuffbuilt Pro Series 2 Bracket

The following instructions detail the assembly of the Tuffbuilt Pro Series 2 device into the universal bracket.

Appropriate PPE should be worn: Gloves Protective Footwear

Assembly Instructions: Fitting the Device

The following instructions detail the assembly of the Tuffbuilt Pro Series 2 device into the universal bracket.

Remove the pin from the bracket. Present the device to the bracket. Adjust the position, placing the device attachment

arm into the bracket as shown and secure with the

pin.

The device is now ready to use.

Assembling the Tuffbuilt Pro Series 2 Winch onto the bracket for trap plate attachments.

Tuffbuilt Pro Series 2 Bracket

12 3

Now install the product

onto the trap plate.

The following instructions detail the assembly of the Tuffbuilt Pro Series 2 bracket [RAWB009320] for the 500kg.

Appropriate PPE should be worn: Gloves Protective Footwear

Assembly Instructions: 500

Assembling the Tuffbuilt Pro Series 2 Bracket on 500

The following instructions detail the assembly of the Tuffbuilt Pro Series 2 bracket [RAWB009320] for the 500kg.

Present the bracket to the trap plate using the centre

holes, securing with the M12 bolts.

The bracket is ready to receive the device.

The bracket comes with the pins and M12 bolts

supplied, as shown above.

Remove the bottom bolt from the trap plate.

Tuffbuilt Pro Series 2 Bracket - [RAWB009320]

12 3

The following instructions detail the assembly of the Tuffbuilt Pro Series 2 bracket [RAWB009320] for the 1000kg.

Appropriate PPE should be worn: Gloves Protective Footwear

Assembly Instructions: 1000

The following instructions detail the assembly of the Tuffbuilt Pro Series 2 bracket [RAWB009320] for the 1000kg.

Assembling the Tuffbuilt Pro Series 2 Bracket on 1000

The bracket comes with the pins and M12 bolts

supplied, as shown above.

Present the bracket to the trap plate using the centre

holes, securing with the M12 bolts.

The bracket is ready to receive the device.

Remove the bottom bolt from the trap plate.

Tuffbuilt Pro Series 2 Bracket - [RAWB009320]

12 3

The following instructions detail the assembly of the Tuffbuilt Pro Series 2 bracket [RAWB009325] for the Small and Medium frame sizes.

Appropriate PPE should be worn: Gloves Protective Footwear

Assembly Instructions: S & M
