Redx RX- 0050 Manuel utilisateur
Lithium Iron Phosphate
Battery System
User Manual
Document Version: 1.1
Issued Date: 2023-03-29
RX- 0050
About This Document
Purpose
Intended Audience
Symbol Conventions
This document describes the RX-0050 Lithium iron phosphate battery system in terms of its
features, performance, working principles, appearance as well as instructions for installation, and
operation and maintenance (O&M).
This document is intended for:
Sales engineers
Technical support engineers
System engineers
Hardware installation engineers
Commissioning engineers
Maintenance engineers
The symbols that may be found in this document are defined as follows.
Indicates a hazard with a high level of risk which, if not avoided, will result in
death or serious injury.
Indicates a hazard with a medium level of risk which, if not avoided, could
result in death or serious injury.
Indicates a hazard with a low level of risk which, if not avoided, could result
in minor or moderate injury.
Indicates a potentially hazardous situation which, if not avoided, could result
in equipment damage, data loss, performance deterioration, or unanticipated
results.
NOTICE is used to address practices not related to personal injury.
Supplements the important information in the main text. NOTE is used to
address information not related to personal injury, equipment damage, and
environment deterioration.
Symbol Description
DANGER
WARNING
CAUTION
NOTICE
NOTICE
Document Version: 1.1
Issued Date: 2023-03-29
REVISION LOG
Version Num. Date Purpose of Revision
2020/12/14 This issue is the first official release.V1.0
Document Version: V1.1
Issued Date: 2023-03-29
2023/03/29 Clarified packaging and cable connections.V1.1
Contents
1 Safety Information....................................................................................1
1.1 General Safety...................................................................................1
1.2 Personnel Requirements...................................................................4
1.3 Electrical Safety.................................................................................5
1.4 Installation Environment Requirements.............................................6
1.5 Mechanical Safety..............................................................................6
1.6 Battery Safety....................................................................................8
1.7 Others................................................................................................11
2 Overview....................................................................................................12
2.1 Product Introduction..........................................................................12
2.1.1 Appearance....................................................................................12
2.1.2 Product Structure........................................................................... 13
2.2 Battery System Specification.............................................................14
2.2.1 Cell Parameters..............................................................................14
2.2.2 Battery Module Parameters............................................................14
2.2.3 Protection Parameters....................................................................15
3 Operations.................................................................................................16
3.2Communication..................................................................................17
3.3Installation..........................................................................................17
4 Routine maintenance...............................................................................19
4.1 Monthly Maintenance........................................................................19
5 Terms.........................................................................................................21
Document Version: V1.1
Issued Date: 2023-03-29
3.1 Storage..............................................................................................16
3.4Powering on.......................................................................................19
1.1 General Safety
Statement
Before installing, operating, and maintaining the equipment, read this document and observe all the
safety instructions on the equipment and in this document.
The "NOTICE", "WARNING", and "DANGER" statements in this document do not cover all the safety
instructions. They are only supplements to the safety instructions. Redx will not be liable for any
consequence caused by the violation of general safety requirements or design, production, and usage
safety standards.
Ensure that the equipment is used in environments that meet its design specifications. Otherwise,
the equipment may become faulty, and the resulting equipment malfunction, component damage,
personal injuries, or property damage are not covered under the warranty.
Follow local laws and regulations when installing, operating, or maintaining the equipment. The
safety instructions in this document are only supplements to local laws and regulations.
1 Safety Information
RX-0050
Lithium iron phosphate battery system User Manual
Document Version: V1.1
Issued Date: 2023-03-29 1
Redx will not be liable for any consequences of the following circumstances:
Operation beyond the conditions specified in this document
Installation or use in environments which are not specified in relevant international or national
standards
Unauthorized modifications to the product or software code or removal of the product
Failure to follow the operation instructions and safety precautions on the product and in this
document
Equipment damage due to force majeure, such as earthquakes, fire, and storms
Damage caused during transportation by the customer
Storage conditions that do not meet the requirements specified in this document
General Requirements
Do not install, use, or operate outdoor equipment and cables (including but not limited to moving
equipment, operating equipment and cables, inserting connectors to or removing connectors from
signal ports connected to outdoor facilities, working at heights, and performing outdoor installation)
in harsh weather conditions such as lightning, rain, snow, and level 6 or stronger wind.
Before installing, operating, or maintaining the equipment, remove any conductive objects such as
watches or metal jewelry like bracelets, bangles, and rings to avoid electric shock.
When installing, operating, or maintaining the equipment, wear dedicated protective gear such as
insulation gloves, goggles, and safety clothing, helmet, and shoes, as shown in the following figure.
Follow the specified procedures for installation, operation, and maintenance.
Before handling a conductor surface or terminal, measure the contact point voltage and ensure
that there is no risk of electric shock.
RX-0050
Lithium iron phosphate battery system User Manual
Document Version: V1.1
Issued Date: 2023-03-29 2
RX-0050
Lithium iron phosphate battery system User Manual
Document Version: V1.1
Issued Date: 2023-03-29 3
After installing the equipment, remove idle packing materials such as cartons, foam, plastics, and cable
ties from the equipment area.
In the case of a fire, immediately leave the building or the equipment area, and turn on the fire alarm bell
or make an emergency call. Do not enter the building on fire in any case.
Do not stop using protective devices. Pay attention to the warnings, cautions, and related precautionary
measures in this document and on the equipment. Promptly replace warning labels that have worn out.
Keep irrelevant people away from the equipment. Only operators are allowed to access the equipment.
Use insulated tools or tools with insulated handles, as shown in the following figure.
Do not scratch, damage, or block any warning label on the equipment.
Tighten the screws using tools when installing the equipment.
Do not work with power on during installation.
Repaint any paint scratches caused during equipment transportation or installation in a timely manner.
Equipment with scratches cannot be exposed to an outdoor environment for a long period of time.
Before operations, ensure that the equipment is firmly secured to the floor or other solid objects, such
as a wall or an installation rack.
Do not use water to clean electrical components inside or outside of a cabinet.
Do not change the structure or installation sequence of equipment without permission.
RX-0050
Lithium iron phosphate battery system User Manual
Document Version: V1.1
Issued Date: 2023-03-29 4
1.2 Personnel Requirements
Personal Safety
If there is a probability of personal injury or equipment damage during operations on the equipment,
immediately stop the operations, report the case to the supervisor, and take feasible protective measures.
To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to telecommunication
network voltage (TNV) circuits.
Do not power on the equipment before it is installed or confirmed by professionals.
Personnel who plan to install or maintain Redx equipment must receive thorough training,
understand all necessary safety precautions, and be able to correctly perform all operations.
Only qualified professionals or trained personnel are allowed to install, operate, and maintain the
equipment.
Only qualified professionals are allowed to remove safety facilities and inspect the equipment.
Personnel who will operate the equipment, including operators, trained personnel, and professionals,
should possess the local national required qualifications in special operations such as high-voltage
operations, working at heights, and operations of special equipment.
Professionals: personnel who are trained or experienced in equipment operations and are clear of
the sources and degree of various potential hazards in equipment installation, operation, maintenance
Trained personnel: personnel who are technically trained, have required experience, are aware of
possible hazards on themselves in certain operations, and are able to take protective measures to
minimize the hazards on themselves and other people.
Operators: operation personnel who may come in contact with the equipment, except trained
personnel and professionals.
Only professionals or authorized personnel are allowed to replace the equipment or components
(including software).
RX-0050
Lithium iron phosphate battery system User Manual
Document Version: V1.1
Issued Date: 2023-03-29 5
1.3 Electrical Safety
Grounding
AC and DC Power
ESD
For the equipment that needs to be grounded, install the ground cable first when installing the
equipment and remove the ground cable last when removing the equipment.
Do not damage the ground conductor.
Do not operate the equipment in the absence of a properly installed ground conductor.
Ensure that the equipment is connected permanently to the protective ground. Before operating the
equipment, check its electrical connection to ensure that it is securely grounded.
DANGER
Do not connect or disconnect power cables with the power on. Transient contact between the
core of the power cable and the conductor will generate electric arcs or sparks, which may
cause fire or personal injury.
Before installing or removing a power cable, turn off the power switch.
Before connecting a power cable, check that the label on the power cable is correct.
If the equipment has multiple inputs, disconnect all the inputs before working with the
equipment.
A damaged power cable must be replaced by the manufacturer, service agent, or professionals
to avoid risks.
High voltage operations and installation of AC-powered facilities must be performed by qualified
personnel.
Wear ESD gloves or a well-grounded ESD wrist strap when touching the device or handling boards
or application-specific integrated circuits (ASICs).
When holding a board, hold its edge without touching any components. Do not touch the components
with your bare hands.
Package boards with ESD packaging materials before storing or transporting them.
NOTICE
The static electricity generated by human bodies may damage the electrostatic-sensitive
components on boards, for example, the large-scale integrated (LSI) circuits.
