The lower 3 are ‘Shower Control Feature Setting Options’ and can be set to suit the requirements of
the user. The function and options for each ‘DIP Switch’ are shown below:-
PLEASE NOTE! The Selectronic Premier is
factory set with the ‘DIP Switch’ set as follows:-
4 at ‘0’ (Fixed Flow)
5 at ‘0’ (Preset Start-Up)
6 at ‘0’ (Flow Limited to 6 l/m Max).
DIP 4:- This is used to select “Eco Power
Save”.
Fixed Flow =
With the ‘DIP Switch’ pushed to the
left the shower will save power. As the
temperature is reduced, the shower
will use less power (Eco Power ON).
Maximise Flow =
When the ‘DIP Switch’ is pushed to the
right the shower will use maximum
power at all temperature settings (Eco
Power OFF).
DIP 5:- Preset Start-up =
With the ‘DIP Switch’ pushed to the
left the shower will start up at a preset
temperature every time it is used.
The start up temperature depends on
The setting of the ‘Temp Lock Switch’.
a) When set to 1the start up = 40°C Nominal (Digit 5 on front cover display)
b) When set to 2the start up = 41°C Nominal (Digit 6 on front cover display)
c) When set to 3the start up = 43°C Nominal (Digit 8 on front cover display)
d) When set to 4the start up = 41°C Nominal (Digit 6 on front cover display)
Previous Setting =
With the ‘DIP Switch’ is pushed to the right the shower will start up at the same temperature
as the last time the shower was used. E.g. If the shower was set to Digit 4 (39°C) when it was
switched off, then it will start up at Digit 4 the next time it is used.
DIP 6:- This is used to select “Eco Water Save”
Flow Limited to 6 l/m (Litres / Minute) max =
When the ‘DIP Switch’ is pushed to the left the shower will prevent high water flow rates.
The shower will not supply water at a flow rate greater than 6 l/m (Eco Water Save ON)
Temperature unaffected. This selection meets the ‘Sustainable Home’ water consumption
requirement per person for showering.
Flow Limited to 9 l/m (Litres / Minute) max =
When the ‘DIP Switch’ is pushed to the right the shower does not restrict the flow rate.
The shower is capable of supplying water at a flow rate greater than 6 l/m ‘DIP Switch’ (Eco
Water Save OFF).
I
I
I
Position ‘0’
(Switch to the Left)
Position ‘1’
(Switch to the Right)
DIP 4: Flow Optimiser Switch
DIP 5: Start-Up Temperature Setting
DIP 6: Maximum Flow Limiter Flow Limited to 6 l/m max Flow Limited to 9 l/m max
Fixed Flow
Preset Start-Up
Maximise Flow
Previous Setting
Diagram 9
ON
456
123
X
