Reconyx HYPERFIRE 2 HS2X Manuel utilisateur

Cellular Security

4G LTE Camera Manual

HS2X –General Surveillance

HL2X –License Plate Capture

1 ©RECONYX, Inc.

Table of Contents
I. Cellular Camera Overview ..................................................... 2
II. HyperFire 2TM Specifications ................................................. 3
III. Get Started .............................................................................. 4
IV. App Install and Setup.............................................................5
V. RECONYX®Cellular Plan ....................................................... 6
VI. Controls & Parts Diagram......................................................8
VII. Batteries & Memory Cards.....................................................9
VIII. Battery and Power Specifications....................................... 10
IX. Camera - Setup & Programming .........................................14
X. ConnectTM App Options ....................................................... 15
XI. Camera Programming Menu................................................18
XII. Programming Menu Map –HF2 Cell Security .................... 21
XIII. Mounting Your Camera ........................................................ 27
XIV. Locking & Securing Your Camera ......................................28
XV. Aiming Your Camera............................................................ 29
XVI. Image Data Information........................................................ 34
XVII. Additional Camera Options .................................................35
XVIII. Troubleshooting ................................................................... 36
XIX. Warranty, FCC, CE, IC, RoHS and Safety Information ......40
XX. Your Information and Camera Warranty Registration ...... 43
XXI. Copyright & Trademark Information...................................43


www.reconyx.com 2

Cellular Camera Overview

Congratulations on purchasing a RECONYX®camera. RECONYX®has been the

leader in digital security cameras since 2002. Your HyperFire 2™ camera is a state-

of-the-art digital camera with a Passive Infrared (PIR) motion detector and a night-

time infrared illuminator; all contained in a secure, rugged and weather-resistant case.

The simplest and best way to use the RECONYX®HyperFire2TM Series Cellular

Camera is to sign up with the RECONYX®Cell Plan. Download and install the

RECONYX®ConnectTM app from Google Play or the Apple App Store.

You can setup and manage your account, view your photos, change settings, see

your camera status, & request a photo, all from the ConnectTM app.

If for some reason you cannot use the ConnectTM app, you can send photos via email

direct from the camera. This setup requires you install your own SIM card and run

separate software on a Windows PC to configure your camera. Images sent in this

manner are not stored in your RECONYX®cloud account and are not accessible from

the ConnectTM app.

Other things you will need before using your camera:

•Secure Digital®(SD, SDHC or SDXC) Memory Card (up to 512GB)

•12 AA Batteries (Or SC10 Solar Charger)

NOTE: RECONYX®cameras should only be powered with either Energizer®AA

Ultimate Lithium batteries or NiMH rechargeable batteries. There is also an

External Power Jack installed. This can be used with our SC10 Solar Charger

(available at www.reconyx.com) or other 12v external power source.

•Android or iOS device to run the RECONYX®ConnectTM app to setup your

account, view your photos, and program your cellular camera.

•Activating your camera is done through the RECONYX®ConnectTM app.

Contents of this package:

•HyperFire 2™ Camera

•Antenna Subassembly

•Adjustable Webbing Strap for mounting camera

•Power Cable

•This instruction manual

3 ©RECONYX, Inc.

HyperFire 2TM Specifications

HS2XC

HL2XC

Purpose

General Surveillance

License Plate Capture

Illumination Range

at night

No-glow

Covert Infrared up to 150 feet

No-glow

Covert Infrared up to 70 feet

for License Plates

Images

3 MP or 1080p HD color

images by day; monochrome

images by night

720p widescreen or standard

color images by day;

monochrome by night

InstaOn™

Trigger Speed

1/5 second

RapidFireTM

NearVideoTM

Up to 2 frames per second

Up to 3 frames per second

Video with Audio

720p 20 fps

720p wide or std 5 fps

Loop Recording

Available option: Continuous recording.

Older pictures/videos overwritten by new ones.

SD Card Capacity

Up to 512GB: (4GB = approx

10,000 pictures)

Up to 512GB: (4GB = approx

20,000 pictures)

Software Included

RECONYX®ConnectTM

Moisture Absorbing

Desiccant System

Available for purchase

Time-Lapse

Surveillance

5, 15 or 30 seconds or

1, 5, 15, 30, or 60 minute intervals

Time-Lapse and

Motion Sensor

Scheduling

Clock based (Fixed) and Solar schedules available. Schedules

can also be assigned to different days of the week.

(i.e. different weekday schedule from weekend schedule).

Power Options

12v External Power Jack,

SC10 Solar Charger, AC/DC Power Supply

Warranty

5 years

www.reconyx.com 4

Get Started

1) Attach the antenna subassembly onto the front of the camera by hand.

Do not over-tighten!

2) Install (12) AA Batteries –or plug in your SC10 Solar Charger or other external

power source.

(We recommend Energizer Ultimate Lithium or Tenergy NiMH).

3) Install the SD Card. (We recommend SanDisk).

4) Download the “RECONYX CONNECT” App from your App Store.

5) Follow the directions in the RECONYX CONNECT App to…

•Setup your account

•“Add” your camera(s)

•Enter billing information

•Receive photos

•Program your camera

NOTE: If you have any questions or concerns relating to the operation or

functionality of your camera, please contact our Technical Service

Department by email at [email protected] or by calling toll free

866-493-6064.

5 ©RECONYX, Inc.

App Install and Setup

Initial Setup

Before you power your camera on for the first time, it is helpful to have the Reconyx

Connect App installed on your mobile device. On the mobile device, you will touch

“Add Camera”. Then you should follow the on-screen instructions for adding a

camera. It will tell you to go through the setup wizard on your camera. To do this,

you will want to power up the camera with an SD card inserted.

If this is the first time you’ve used your

camera, it will take you through a setup

wizard to help you with initial setup. It will

start by asking you to set the date.

Use the up and down buttons to change numbers and the right and left buttons to

scroll through settings for year, month and date. The OK button will take you to the

Set Time screen. Proceed through the setup wizard until setup is complete. At the

end of the setup wizard, you will be able to “Pair” the camera with your App.

Install the RECONYX®ConnectTM app from Google Play

for Android or the Apple App Store for iOS.

Once the App is installed you will be prompted to:

1. Setup your account

2. Add/Pair your camera(s) with your device

3. Add your billing information

4. Setup optional Image or Data Cost caps

5. Decide what other optional services you would like

to include, e.g. Real-Time Access.

Once you have gone through these steps your camera is

ready to be deployed and start sending you images.

www.reconyx.com 6

RECONYX®Cellular Plan

RECONYX®is your one-stop shop for your camera and cell plan.

There is no need to contact a cell carrier for activation or billing and no need to guess

which plan option is best for you. Everything is handled directly through the

RECONYX®ConnectTM app. Just open the app and tap the Add Camera button to get

started. Within minutes you'll be up and running. From there you can manage your

cameras, view your images and monitor your bill all from the same place!

NOTE: For the most current pricing and options go to www.reconyx.com .

Cellular Access Plan

Monthly access is per camera and includes 200 mobile optimized images. Additional

images are billed to your Shared Image plan.

The Cellular Access Plan includes: Cloud Storage, Remote Access and Hibernate

Cloud Storage

Images are stored in your secure cloud account and accessed with the

RECONYX® ConnectTM app. 1 GB of storage included (approximately 20,000

mobile optimized images).

NOTE: Additional storage is available for purchase.

Remote Access

Manage your camera remotely from the RECONYX®app:

•View and manage images

•Check camera status*

•Change camera settings*

•Fetch Full Resolution images*

NOTE:* Remote Access functions will be performed the next time the camera connects

to the network, which could be up to a day from when you make the request.

Our REAL-TIME ACCESS feature allows for these functions to be performed

immediately.

7 ©RECONYX, Inc.

Hibernate

You do not have to pay for cellular access when your camera is not in use.

With the RECONYX®plan, you can hibernate each camera for up to 6 months

per year with no cancellation or re-activation fees.

Your saved images are still accessible in the RECONYX®app.

NOTE: When you wish to reactivate your camera, you will need to have your camera in

hand and follow the onscreen instructions.

NOTE: Go to www.reconyx.com for current pricing and options.

Additional Data

Additional image data is sold in Blocks of 2,000 mobile optimized images per month.

Image blocks are shared across all RECONYX® cameras on your account.

NOTE: Each Full Resolution image counts as 10 mobile optimized images.

Real-Time Access

Optional upgrade for immediate 2-way communication with your camera from the

RECONYX Connect app. Enhances standard remote camera access to include:

•Request camera to take and send an image right now

•Live Aim Mode: aids in mounting and positioning your camera

•Check camera status at any time

•Change camera settings without delay

•Fetch Full Resolution images immediately

NOTE: Purchased on a per camera basis (for up to 100 requests per month).

www.reconyx.com 8

Controls & Parts Diagram

Batteries & Memory Cards

Accessing Batteries, Memory Card & Camera Controls

To install the batteries and memory card, open the latch on the right side of the

camera by grasping behind the latch and flipping it toward the front. The camera will

open like a book, allowing access to the batteries, memory card and settings.

Step 1

Step 2

Step 3

TIP: Each time you open your camera it’s a good practice to:

•Make sure the main gasket is seated properly and is clear of debris.

•Be sure that the windows on the front of your camera are clean.

•Also be sure the latch is fully seated when closing your camera to ensure a

weather-tight seal.
