RCA F27250 Manuel utilisateur

USER'S

GUIDE

__ 73Jo

Important Information

WARNING

To reduce the risk of fire or

shock hazard, do not expose

this TV to rain or moisture.

RISK OF ELECTRIC SHOCK

DO NOTOPEN

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO

NOT REMOVE COVER (OR BACK). NO USER

SERVICEABLE PARTS INSIDE. REFER SERVICING

TO QUALIFIED SERVICE PERSONNEL.

This symbol indicates

"dangerous voltage" inside

the product that presents a.

risk of electric shock or

personal injury.

This symbol indicates

important instructions

accompanying the

product.

Cautions CAUTION:

To prevent electric shock, match wide blade of plug to wide

slot, fully insert.

ATTENTION:

Pour _viterles chocs 41ectriques, introduire la lame la plus

large de la fiche dans la borne correspondante de la prise et

pousser jusqti au fond.

Operate TV orayon 120 volts, 60 Hz AC power (normal house power).

FCC Regulations state that unauthorized changes Ormodifications to this

equipment may void the user's authority to operate it.

Note To Cable TV Installer This reminder is provided to call your attention to Article 82040 of the

National ElectricalCode (Section 54 of the Canadian Electrical Code,

Part 1) which provides guidelines for proper grounding and, in particular,

specifies that the cable ground shall be connected to the grounding system

of the building as close to the point of cabl e entry as practical.

Product

Registration

Please fill out the product registration card and return it immediately.

Returning this card allows us to contact you if needed.

Keep your sales receipt to obtain warranty parts and service and for proof

of purchase. Attach it here and record the serial and model numbers in

case you ever need them. The numbers are located on the back of the TV.

Model No.

Serial No.

Purchase Date"

Dealer/Address/Phone:

j-..

Table of Contents

Important Information Warning, Product Registration

_ . :,.,;

Quick Guide to Your TV Startup 2-3

Hook up your TV, Plug in the TV, Put Batteries in the Remote,

Turnon the TV,Place Channels in Memory, Set the Time

Basic Tour of the Remote

Power, Volume, Channel, Special and Menu Buttons

Menu Basics

Colors, Menu Buttons, Moving through the Menus

Using Your Remote With Remote Buttons 6-7

Adjusting Your TV Overall Picture

Picture Settings

Color, Tint, Brightness, Sharpness, Autocolor, Picture Reset

Sound Settings

Stereo, Tone

Using Advanced Features Placing Channels in Memory/Autoprogram

Naming the Channels

Setting the Sleep Timer

Setting the Alarm Clock

Watching Closed Captioning

Selecting a Language

Setting YourTV for Antenna or Cable

References Front Panel Buttons

Displays on the Screen

Trouble Checks

Order Form for Parts

Limited Warranty

Glossary

Index .

19-20

21-22

Quick Guide to Your TV

Startup

The steps below will get your TV connected and ready for watching. For

more details, see the page numbers listed. •

1. Hook up your TV

Details are in the Connections

Guide. CONNECTIONS

,GUIDE

Hook up any antennas, cables or

other equipment to your TV before

you foUow the ste _s below.

2. Plug in the TV Plug the •cord into the outlet,

matching the wide and the small

end of the plug with the outlet.

3. Put Batteries in the Remote p

A. Pull off the cover of thebattery

compartment.

B. Place two AAA batteries as

shown, matching the 4- and -

•end of each battery in the

.compartment.

C. Replace the cover.

Quick Guide to Your TV

Startup

4. Turn on the TV •_? I

_'_1

_'9 I

),J.

Press POWER on the remote.

Press POWER on the TV.

5. Place all available

channels in memory

(Autoprogram)

Detailsfor addinganddeleting

channelsareon page11. Controls Alarm

13 A. Press MENU until the Setup menu

is selected. This menu is white.

B. Press VOLUME + to place

channels in the TV's memory

(Autoprogram).

C. Wait until TV has cycled through

all the channels and rettu-ns to

original channel.

6. Set the Time 2:21 AM 13

ust Setup

A. Press MENU until the Alarm

menu is selected. This menu

is green.

B. The Clock is automatically

highlighted the first time you

set-it. If it is not, press

CHANN EL down to highlight it.

- C. Press VOLUME -- to set the

hour.

D. Press VOLUME +to set the

minutes.

F. The menus will automatically

disappear from the screen, after

a brief period of time.

QuickGuide to Your TV

Basic Tour of the Remote

Basic information about your remote is shown below_ This will give you a

general idea of holy your remote works. For more details, see page 6.

Power Button

Volume, Channel and Special

Buttons

Details are on page 6.

MUTE PREV CH

0 0

VOL '_'VO_.

CHAN

CLEAR MENU RESET

'_5

Turns the TV on and off.

Operate the TV.

Scan up and down through

channels in the TV's memory.

Raise and lower the sound.

Menu Buttons

Details areon page5.

POWER

°_ 0

MUTE PREV CH

CLEAR MENU RESET

4b4b4b

p2 3

PPP

opo

Change the menus and features on

the screen. "

Quick Guide to.Your TV

Menu Basics

General information about using the on-screen menu system is shown

below. Details on using the remote buttons are on page 6. Many menu items

are explained in detail in Adjusting Your TV starting on page 8 and Using the

.Advanced Features starting on page 11.

Colors

Yellow Green Light White

Controls Alarm

Press MENU repeatedly to see

each of the four menu colors.

Each menu has a (iifferent color

background as shown at the left.

Menu Buttons

These buttons are used with the

TV's menus to adjust the features.

You can use the menu buttons on

the remote or the front of the TV.

Moving through the Menus

;ontrols Alarm

• 1.

)•!

Press MENU to move from

menu to menu.

Press CHANNEL up and down

to move through the features in

the menu.

Press VOLUME-I- and -- to

move left and right on the

menu lines.

Using Your Remote

With Remote Buttons

÷ .

POWER

MUTE PREVCH

VOL CHAN VOL

CHAN

CLEAR MENU RESET

INPUT

©SKIP

DISPLAY

Shows displays on the screen.

Clears menus from the screen.

POWER

Turns the TV on and off.

MUTE

Switches the TVsound on or off.

PREV CH (Previous Channel)

Changes back and forth between

two channels:

Select a channel and then select

another. Press PREV CH to switch

between the two channels.

CHAN -^ and v

(Channel up and down)

Scansup and down through

channels in the TV's memory.

Moves up and down menus. See

Menu Basics on page 5.

VOL + and --

(Volume up and down)

Raises and lowers sound.

Moves left and right on a menu

line. See Menu Basics on page 5.

Changes a feature setting.

Using Your Remote

With Remote Buttons

. , ..-...

POWER

MUTE I_REVCH

VOL CHAN VOL

CHAN

CLEAR MENU, RESET-

neA

CLEAR

Clears menus and displays from

the screen.

Shows menus ,on the screen and

moves from menu to menu.

RESET

Returns the picture adjustments to

the original settings.

Number Buttons

Selects any channel number.

Two numbers must be t_ressed for

each channel. Press 0 and 6 for

channel 6.

For three digit channels, press and

hold I until 1- appears on the

screen. Then press the other two

numbers.

INPUT

Switches between the TV channels

and Video 00 if another component

is connected.

SKIP (Commercial Skip)

Allowsyou to look at other

channels during commercials.

Each press adds 30 seconds. Use

the CHANNEL or number buttons

to scan the other channels. TV

switches back to original channel

when time runs out. Press CLEAR

to cancel SKIP.

Adjusting Your TV

Overall Picture.

Follow the steps below to lighten or darken the overall picture without

changing the color levels.

1. Select the Controls Menu

Alarm Ad

Press MENU repeatedly to select

the Controls menu. This menu is

•yellow.

2. Highlight Picture

Alarm Ad

Press CHANNEL down to

highlight Picture.

3. Use VOLUME + and - to

adjust the Picture Press VOLUME + to lighten the

picture.

Press VOLUME -- to darken the

picture.
