RBH Access Technologies UNC100 Manuel utilisateur

UNC100

HARDWARE MANUAL

Revision 1.4

WWW. RBH-ACCESS.COM

new generation

building security

UNC100 Hardware Manual V1.4 RBH Access Technologies Inc.

Page 2of 36

an agreement containing restrictions on its use. No part of this book may be copied or distributed,

transmitted, stored in a retrieval system, or translated into any human or computer language, in any

form or by any means, electronic, mechanical, magnetic, manual, or otherwise, or disclosed to third

parties without the express written consent of RBH Access Technologies Inc., Brampton, Ontario,

Canada.

Trademark

Axiom™ is the trademark of RBH Access Technologies Inc. Windows is a trademark of Microsoft

Corporation. All other product names mentioned herein are the property of their respective owners.

Use of a term in this book should not be regarded as affecting the validity of any trademark or

service mark.

Disclaimer

This book is provided as is, without warranty of any kind, either express or implied, including but

not limited to performance, merchantability, or fitness for any particular purpose. Neither RBH

Access Technologies Inc. nor its dealers or distributors shall be liable to any person or entity with

respect to any liability, loss, nor damage, caused, or alleged to have been caused directly or

indirectly by this information. Further RBH Access Technologies Inc. reserves the right to revise

this publication, and to make changes to the content hereof from time to time, without the obligation

of RBH Access Technologies Inc. to notify any person or organization of such revision or changes.

RBH ACCESS TECHNOLOGIES INC.

2 Automatic Road, Suite 108

Brampton, Ontario

CANADA

L6S 6K8

Tel: (905) 790-1515

Fax: (905) 790-3680

Email: info@rbh-access.com

WWW: www.rbh-access.com

UNC100 Hardware Manual V1.4 RBH Access Technologies Inc.

Page 3of 36

Contents

R e v i s i o n H i s t o r y .......................................................................................... 5

I n t r o d u c t i o n ......................................................................................................... 6

C e r t i f i c a t i o n s ................................................................................................... 7

U N C 1 0 0 C o n t r o l l e r D e s c r i p t i o n .......................................... 8

Battery Protection....................................................................................................................8

P C C o n n e c t i o n .................................................................................................. 9

UNC100 TCP/IP Connection ...................................................................................................9

IP Device Discovery.........................................................................................................................10

Battery Charger .....................................................................................................................11

Reverse Battery Protection....................................................................................................11

Battery Test...........................................................................................................................11

Fuse Monitoring.....................................................................................................................11

Diagnostic LED’s ...................................................................................................................11

Tamper Detection..................................................................................................................11

RAM Memory ........................................................................................................................11

Power Input / Output..............................................................................................................11

UNC- 1 0 0 C o m m u n i c a t i o n .................................................................12

Networks ...............................................................................................................................12

RS485 Applications ...............................................................................................................12

DIP Switch Settings...............................................................................................................13

Controller Addressing ............................................................................................................13

Master Controller.............................................................................................................................. 14

Slave Controller ................................................................................................................................ 14

Ethernet Secure Mode.....................................................................................................................14

RS485 (HOST) Port Baud Rate Selection (Master Only) ..........................................................14

UNC- N E T ( C o n t r o l l e r N e t w o r k ) ...........................................15

UNC-NET Cable ............................................................................................................................... 16

UNC-NET Maximum Cable Length ............................................................................................... 16

E - N E T ( E t h e r n e t N e t w o r k ) ..........................................................17

E-Net Encryption ...................................................................................................................17

Steps to enable E-net Encryption .................................................................................................. 18

D - N E T D e v i c e N e t w o r k .......................................................................20

D-NET Maximum Cable Length .....................................................................................................23

D-NET Cable.....................................................................................................................................23

Reader Interface....................................................................................................................24

Reader Connection ..........................................................................................................................24

Cable Specification ..........................................................................................................................24

Maximum Cable Length .................................................................................................................. 24

Access Point/Reader Operating Modes.................................................................................25

Two Person .......................................................................................................................................25

High Security.....................................................................................................................................25

Unlocked............................................................................................................................................25

Tamper...............................................................................................................................................25

Lockout Alarm................................................................................................................................... 25

UNC100 Hardware Manual V1.4 RBH Access Technologies Inc.

Page 4of 36

Door Held Open Warning................................................................................................................25

Door Held Open Alarm ....................................................................................................................25

Keypad / Reader Combination .......................................................................................................25

Access Granted ................................................................................................................................25

Access Denied..................................................................................................................................25

OSDP....................................................................................................................................26

OSDP Reader connection .....................................................................................................26

Enabling the OSDP Feature in UNC-100...............................................................................28

Unencrypted OSDP settings...........................................................................................................28

Encrypted OSDP settings ...............................................................................................................28

Extended use of OSDP Channel ...................................................................................................29

Configuration.....................................................................................................................................29

Inputs ....................................................................................................................................30

Input Circuit Types ...........................................................................................................................30

Outputs..................................................................................................................................33

Default Output Operation.......................................................................................................33

Lock Output.......................................................................................................................................33

Forced / Tamper............................................................................................................................... 33

Switching Inductive Devices (Locks, Bells) ..................................................................................33

U N C 1 0 0 S p e c i f i c a t i o n ........................................................................35

C a b l e S p e c i f i c a t i o n ...............................................................................36

UNC100 Hardware Manual V1.4 RBH Access Technologies Inc.

Page 5of 36

R e v i s i o n H i s t o r y

Editor

Revision

Comment

Date mm/dd/yyyy

1.0

First Release

08/13/2013

1.1

Removed reference to fire input

Removed partial firmware upgrade (formats)

Added dip-switch 5

Added Revision History

Updated copyright

Eliminated reference to rack mount type

Clarified the use of the Power Input/ Output

Moved all cable specs to one location.

Moved all input specs to one location.

Moved all output specs to one location.

Reduced the number of pages.

03/19/2014

1.1

Minor editing of text.

03/24/2014

1.2

Changing output voltage from

12V to 12v –14v

Changing battery charger spec

07/21/2014

1.2

Minor editing.

07/31/2014

1.2

ULC text added.

08/06/2014

1.3

Added OSDP /OSDP-S Reader options

Added E-NET communication

Added AES option for Encrypted communication between

PC and master UNC-500 and between slave UNC-500s

08/10/2020

1.4

Updated copyright year

Rearranged text and Images

01/14/2021

1.4

Added UL 294 Declaration Table

02/03/2021

UNC100 Hardware Manual V1.4 RBH Access Technologies Inc.

Page 6of 36

I n t r o d u c t i o n

The RBH-UNC100 series is a welcome addition to the new

generation of powerful and reliable Axiom hardware. The two

door native TCP/IP controllers come equipped with onboard

battery backup chargers and accommodate up to 16 individual

IOC-16 input/output controllers or 254-SafeSuite keypads. The

units are expandable to 8 doors, using 3 additional RC-2 or

NIRC/NURC controllers.

The UNC-100 also features a 32-bit processor with encryption

and expanded memory.

The UNC100-132 models come equipped with IEEE 802.3at

compliant PoE capability, further increasing this UNC series’

award-winning efficiency.

POE Features are:

IEEE 802.3at Compliant

30 Watt power rating

Built-in battery backup with charger

Operates with non-compliant PoE+PSEs

Available auxiliary power output

UNC-100 unit fits into existing enclosures and if ordered with metal

protective shell can be mounted directly on back boards or inside of 3rd party

cabinets.

UNC-100 uses AES-256 bit encryption for secure communication over Ethernet. This communication

can be either between the host computer & master panel or amongst the master & slave panels. Both panel

& the host computer needs to be provided with a Customer Key and need to enable AES option both in

Axiom and UNC-100.

UNC100 Hardware Manual V1.4 RBH Access Technologies Inc.

Page 7of 36

C e r t i f i c a t i o n s

FCC, CE, UL-1076, ULC-S319-05 III, UL-294, UL-294B compliance, all wiring into the chassis

mount panel’s cabinet must enter through metal conduit. Also be sure to mount the panel in a

protected area.

Declaration Performance level Definitions of UNC-100 under evaluations in the

table below according to UL 294 Ed7 section 8 Performance level Definitions for

Access Control in table 8.

Declaration Levels for UNC-100

Feature

Levels

Destruction Attack Level

Level III

Line Security

Level II

Endurance Level

Level IV

Standby Power

Level IV

Single Point Locking device with key Locks

Level I

UNC100 Hardware Manual V1.4 RBH Access Technologies Inc.

Page 8of 36

UNC100 C o n t r o l l e r D e s c r i p t i o n

The Axiom™access control system consists of one or more network controllers (UNC100). All information

required by the controller is downloaded from the PC and stored locally non-volatile flash memory. This

information includes configuration data, cardholder records, access levels, schedules, and all other records

necessary for the operation of the system. The controller operates independent of the PC and all decision-

making is performed locally, even in the event of total power loss.

Battery Protection

To protect the battery from being drained during shipping/storage of the UNC100, there is a small paper

between the battery and the panel. This must be removed before powering up the panel.

UNC100 Hardware Manual V1.4 RBH Access Technologies Inc.

Page 9of 36

P C C o n n e c t i o n

The Master UNC-100 is connected through the local Ethernet via a static IP address. The means of

communication is configured in the Axiom™software under Network Configuration/Port Type.

UNC100 TCP/IP Connection

The master controller in installations is linked by the local Ethernet. The system supports a static IP address

only [default address is 192.168.168.125] and Port 3002.

UNC-100 uses AES-256 bit encryption for secure communication over Ethernet. This encrypted

communication can be either between the host computer & master panel or amongst the master &

slave panels. Both UNC-100 & the host computer needs to be provided with a Customer Key and need to

enable AES option both in Axiom and UNC-100.

To change the IP address of the unit or enable/disable AES option, users can use IP Device Discovery [a

utility program provided by RBH]

PC to UNC100 Connection - LAN

UNC100 Hardware Manual V1.4 RBH Access Technologies Inc.

Page 10 of 36

IP Device Discovery

When the IP Device Discovery program finds an Ethernet connected panel with the correct requirements it

will display under “Edit Mode” an edit button.

When pressed, the software will allow the editing of the following items; Location Text, IP data, LIF/LAN

application parameters, Channel Application and Encryption (AES) and other options.

Make changes to the various items displayed. After entering the data

and clicking on “OK” the unit will re-boot. Please note that only

Channel 1 is available for UNC100 RS485 Applications..

Autres manuels pour UNC100

Table des matières

Autres manuels RBH Access Technologies Contrôleurs d'accès IP

RBH Access Technologies

RBH Access Technologies Integra 32 UNC100 Manuel utilisateur

Manuels Contrôleurs d'accès IP populaires d'autres marques

ZKTeco

ZKTeco SpeedFace-V5L Manuel utilisateur

Jantar

Jantar REX A-1-9 Manuel utilisateur

2N Access Unit Feuille d'instructions

Kedacom

Kedacom KSCA120 Series Manuel utilisateur

H3C

H3C WX2880X Manuel utilisateur

G4S

G4S S870-EX Mode d’emploi

PRASTEL

PRASTEL M2000PE Manuel utilisateur

Allegion

Allegion interflex IF-281 Cylinder Manuel utilisateur

TECOM

TECOM TS1067E Manuel utilisateur

Fermax

Fermax Memokey 100C Guide de l'utilisateur

Fermax

Fermax CITYLINE MEMOKEY Mode d’emploi

Software House

Software House iSTAR Pro 2U RM Mode d’emploi

AKCP

AKCP SP+ Manuel utilisateur

Bpt

Bpt HNA/102 Manuel utilisateur

Civintec

Civintec CV9601T-T-1F Manuel utilisateur

BioMax

BioMax N-X90W Manuel utilisateur

ZKTeco

ZKTeco OP-200 Manuel utilisateur

FingerTec

FingerTec s-Kadex Manuel utilisateur
