Razor ScreamMachine Mode d’emploi

Owner’s Manual

NOTE: This manual contains many “Warnings” and “Cautions”

concerning the consequences of failing to maintain or inspect your

Razor Electric Scream Machine. Because any incident can result in

serious injury or even death, we do not repeat the warning of possible

serious injury or death each time such a warning is mentioned.

WARNING: Riding the Razor Electric Scream Machine can be

hazardous. Proper inspection and maintenance of the product is your

responsibility and can reduce the risk of injury.

WARNING: The Electric Scream Machine has been built to

Razor’s design specifications. All the original equipment supplied at the

Razor Electric Scream Machine Owner’s Manual

+ Safety Handbook

Table of Contents

1. Parts of the Scream Machine . . . . . . . . . . . . . . . . . . . . . . . . .3

2. Proper fit and size adjustments . . . . . . . . . . . . . . . . . . . . . . . .4

3. Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

4. Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

5. Safety Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

6. Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

6A. Unbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

6B. Install the Fork . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

6C. Install the Rear Wheels . . . . . . . . . . . . . . . . . . . . . .9

6D. Connect the Motor . . . . . . . . . . . . . . . . . . . . . . . . .12

6E. Attach seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

6F. Install Cranks and Pedals . . . . . . . . . . . . . . . . . . . .13

6G. Charging Prior to Use . . . . . . . . . . . . . . . . . . . . . . .14

6H. Main Switch and Reset . . . . . . . . . . . . . . . . . . . . . .14

7. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

8. Razor Safety Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

9. Limited Warranty and Owner Registration . . . . . . . . . . . . . .19

1. Parts of the Electric Scream Machine

4, 5 and 6 mm hex (Allen) keys

17mm open end wrench

Bicycle-style pump (to inflate the tire)

Razor recommends assembly by an adult with

experience in bicycle mechanics. Some tools

may be supplied, however we recommend the

use of mechanic’s grade tools and use the

supplied tools only as a last resort.

A. Front wheel

B. Pedal

C. Crank arm

D. Wheel cover

E. Fork

F. Brake

G. Fork crown

H. Brake lever

I. Handlebar grip

J. Handlebar

K. Headset

L. Head tube

M. Main frame

N. Seat/battery pack

O. Rear wheels

P. Rear axle

Q. Motor cover

Additional components not

shown in this view will be

detailed in the assembly

section.

TOOLS REQUIRED FOR ASSEMBLY ONLY

time of sale were selected on the basis of their compatibility with the

frame, fork and all other parts. Certain after-market products may or

may not be compatible with your Razor Electric Scream Machine.

Consult your retailer or call Razor prior to modifying or replacing any

component with a non-factory specified product.

NOTE: For safety reasons, the Electric Scream Machine must be

moving at least 3mph before the motor will start. Pedal or push to

3mph, then pull the trigger to start the motor!

2. Proper Fit and Size Adjustments

2. Fit. When properly adjusted, the rider should be able to pedal

comfortably and steer with both feet remaining on the pedals at all

times. If the rider has to stretch to reach the pedals or is too cramped,

the seat should be adjusted fore or aft accordingly.

WARNING: The age recommendation is only an estimate. If you

are too small or too large to comfortably reach the pedals or

handlebars, do not ride the Electric Scream Machine.

WARNING: Failing to properly adjust and tighten the screws, bolts

and clamps that affix the handlebars, seat and rear wheels can cause

you to lose control and fall. When properly tightened, you cannot twist

the front wheel out of line with the handlebars or move the saddle out of

adjustment. If you can twist or force these components to move or

come off by hand, readjust and properly retighten the screws and bolts.

3. Brake

Your Razor Electric Scream Machine is fitted with a hand-operated

brake. The brake lever may be positioned on the handlebar where it is

most comfortable for the rider. To change the position, loosen the

clamping screw and slide the brake lever to the new position and

retighten securely.

Figure 1. Brake lever adjustment.

WARNING: The brake, when properly adjusted, is capable of

skidding the tire and throwing an unsuspecting rider. Practice in an

open area free from obstacles until you are familiar with the brake

function.

WARNING: Cable operated brakes are very effective but must be

adjusted and maintained on a regular basis. Check or have them

checked and adjusted by a qualified mechanic. Worn brake parts,

stretched or frayed inner wires or a kinked housing indicate brake

service or parts replacement may be necessary for proper function.

4. Safety

4A. Helmets. Although not every state or municipality requires the user

to wear a helmet, Razor strongly recommends you wear a properly

approved helmet, such as ANSI or SNELL, even if the law does not

mandate the use of a helmet.

Suitable helmets are available in a variety of styles. The most popular

for kids is the skateboard-style “stunt” helmet. There are many brands

available and they come in various sizes to fit any child or adult.

WARNING: Helmets must be properly fitted and the straps

adjusted properly to be effective. Ask your dealer to help you with the

selection, fit and adjustment of your helmet.

4B. Night riding and low-light conditions. Razor strongly

recommends against riding at night or when lighting or visibility

conditions are less than optimal (such as dawn and dusk).

WARNING: Lighting for night riding or low light conditions are not

required and are not standard equipment on the Electric Scream

Machine. We do not recommend riding at night or in low-light

conditions.

4C. Bare feet. Do not ride with bare feet. Wear enclosed shoes when

riding.

Keep feet on the pedals at all times while riding in the seated position.

Do not ride more than one person at a time.

Never use near steps or

swimming pools.

4D. Wet weather riding. Do not ride in wet conditions.

WARNING: Wet weather impairs traction, braking, control and

visibility. The risk of accident is increased dramatically in wet weather.

WARNING: Keep your fingers and other body parts away from the

crank, steering system, wheels, motor, belt and all other moving

components. Riders with longer hair may risk entanglement in the rear

wheels or drive system. Do not allow long hair to get near the wheels or

drive system.

5. Safety Check (before each ride)

5A. Loose parts. While straddling the Electric Scream Machine, lift the

front wheel off the ground two or three inches and let go so it can

bounce on the ground. Does everything sound tight? There should not

be any unusual rattles or sounds from loose parts or broken

components. If you are not sure, ask an experienced mechanic to

check.

5B. Brake. Check the brake for proper function. When you pull the lever

the brake should act against the rim and provide positive braking action.

The cable should have the proper slack so the brakes do not drag, yet

the lever should not touch the handlebars when pulled except under the

hardest braking action.

5C. Frame, fork and handlebars. Check for cracks or broken

connections. Although broken frames are unlikely and rare, it is possible

for an aggressive rider to bash into a curb or wall and wreck and bend

or break a frame, fork or handlebar. Get in the habit of inspecting yours

regularly.

5D. Bar ends. Your Razor is equipped with plugs in the end of the

handlebars designed to provide protection from exposed handlebar

ends, which can act like a cookie-cutter. If your bar plugs are worn out

or missing and the handlebar end is exposed, replace them or cover the

exposed end(s) with after-market bar-end protectors.

5F. Tire inflation. The front tire on the Electric Scream Machine

requires 35~45 psi inflation pressure. Periodically and regularly check

the tire pressure and reinflate as necessary. If you get a flat tire the

inner tube is available at any retailer that sells bicycle parts and

accessories. The correct size is embossed on the side of the tire (16 x

1.75).

NOTE: For safety reasons, the Electric Scream Machine must be

moving at least 3mph before the motor will start. Pedal or push to

3mph, then pull the trigger to start the motor!

6. Assembly

NOTE: The color of the product in certain photos may appear to

be different than the color of the product you purchased. The colors

were altered to make the assembly photos easier to follow.

WARNING: Razor highly recommends that you have your Electric

Scream Machine assembled by an experienced, adult mechanic. Many

retailers provide assembly but some charge extra. If your retailer can’t

do the assembly, you can have your Electric Scream Machine

assembled at a bicycle shop for a fee. Although you may have to pay

up to $30 or even more for assembly, it will assure the Electric Scream

Machine is properly put together and adjusted.

ASSEMBLY NOTE: Refer to the list of tools required for assembly

on page three of this manual. If you do not have the proper tools or

understanding of the instructions in this manual, take your bike to a

qualified mechanic for assembly, service or adjustments.

6A. Unbox. Remove contents from box. Remove the foam, bubble-

wrap, cardboard and/or plastic separators that protect the various

components from damage during shipping. Inspect the contents of the

box for scratches in the paint, dents or kinked cables that may have

occurred during shipping. Your Electric Scream Machine was partially

assembled and packed at the factory to prevent shipping damage and

there should not be any problems, even if the box has a few scars or

dents. But if there are, contact Razor at 866-467-2967 to resolve any of

these issues.

6B. Install the fork.

Insert the steering tube into the frame as shown in 2a and 2b. The

steering bushings are preinstalled.

Figure 2a. Figure 2b.

Carefully unwind the handlebar/upper crown assembly so the wires are

not tangled or twisted and so the brake cable and trigger wire are

routed as shown in 2c.

Insert the handlebar and upper fork crown assembly into the fork legs

as shown in Figure 2d. Press both the spring buttons (arrows, 2d)

and continue to slide the handlebar assembly into the fork until the

spring buttons engage the holes (A) as shown in Figure 2e, and the

steering tube extends through the upper fork crown (B). The fork stop

must be positioned in the slot in the upper crown. The fit between the

tubes is a close tolerance and may require a firm hand or taps with a

rubber mallet to nudge the handlebar all the way into the fork.

Figure 2c. Figure 2d.

Figure 2e.

Install the tensioning cap and adjusting screw as shown in Figure 2f.

Using an Allen key, snug the adjusting screw as shown in Figure 2g

until the fork crown is firmly seated against the steering bushings. This

is called “preloading.”

Figure 2f. Figure 2g.

Once the fork crown is firmly seated, loosen the adjusting screw

approximately 1/4 to 1/2 turn. This relaxes the preloading and allows the

steering to rotate without binding. Test by turning the handlebars to full

lock left and right. It should steer with slight friction and no binding or

tight spots.

NOTE: The steering bushings are designed for long life and

should require no maintenance. They do not require oil or any type of

“wet” lubrication. If the steering becomes rough, disassemble, inspect

and clean the bearing surfaces (soap and water is fine). Dry thoroughly

and reassemble. Although the bushings and thrust washers are self-

lubricating, a light application of a dry-lube can be used to facilitate the

anti-friction properties of the steering head bushings.

WARNING: Failure to properly install the handlebar to the fork

legs can result in the handlebars falling off and causing risk of injury.

Periodically check to make certain the adjusting screw is properly

tensioned and that the handlebars are securely attached to the forks.

Refer to the safety information in chapter 5 for additional details.

6C. Install the rear wheels. Flip the Electric Scream Machine upside

down. Locate both rear wheels and examine the protruding axle

threads. Notice there are two styles of wheels:

Figure 3a. The wheel on the right is the wheel with the power coupler.

Notice the blue residue on the axle threads. This is a non-hardening

thread-locking “glue” designed to prevent the axle from vibrating loose.

You will install the wheel with the power coupler on to the drive-side of

the Electric Scream Machine. The coupler is shown in Figure 3b.

Figure 3b. The power coupler.

Using a 6mm Allen key, thread the axle into the frame and tighten until

the power coupling is about to engage with the mating part of the wheel

(Figure 3c).

Figure 3c. Figure 3d.

Align the power coupling Make sure the coupling is full engaged

and tighten until the axle is tight as shown.

against the frame.

Carefully align the coupling as shown and, while holding the wheel to

maintain this alignment, tighten completely and firmly until the axle is

tight against the frame and so the coupling is completely engaged as

shown in Figure 3d.

Flip the Electric Scream Machine right-side up to prepare to install the

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Razor Scooter

Razor

Razor FLASHBACK Manuel utilisateur

Razor

Razor A5 CARBON LUX Manuel utilisateur

Razor

Razor W13113290048 Manuel utilisateur

Razor

Razor Sonic Glow Manuel utilisateur

Razor

Razor Pro Series Manuel utilisateur

Razor

Razor Kuties Manuel utilisateur

Razor

Razor Carvr Manuel utilisateur

Razor

Razor Kobalt Manuel utilisateur

Razor

Razor LIGHTSHOW POWERWING Manuel utilisateur

Razor

Razor R Tec Manuel utilisateur

Razor

Razor TEKNO Manuel utilisateur

Razor

Razor E300 Series Manuel utilisateur

Razor

Razor E100 series Manuel utilisateur

Razor

Razor Ground Force Manuel utilisateur

Razor

Razor E90 Series Manuel utilisateur

Razor

Razor deltawing Manuel utilisateur

Razor

Razor Power Core 90 Manuel utilisateur

Razor

Razor Jr Mode d’emploi

Razor

Razor EcoSmart Metro HD Manuel utilisateur

Razor

Razor FLASHRIDER 360 Manuel utilisateur

Razor

Razor Pocket Mod Motor Scooter Manuel utilisateur

Razor

Razor CARBON LUX Manuel utilisateur

Razor

Razor SPORTMOD 15130412 Manuel utilisateur

Razor

Razor A 5 Lux Manuel utilisateur

Manuels Scooter populaires d'autres marques

TEKTRO

TEKTRO CHEETAH Manuel utilisateur

Douglas

Douglas Vespa Sprint Guide d'installation

PLAYTIVE

PLAYTIVE AS-2448 Manuel utilisateur

Ebinger

Ebinger DONKEY XL Manuel utilisateur

Flyer

Flyer Mountain Guide de l'utilisateur

BackCountry eBikes

BackCountry eBikes Storm Manuel utilisateur

equipmed

equipmed FreeRoam II Manuel utilisateur

Yoto

Yoto Lion Manuel utilisateur

WESTHILL BIKES

WESTHILL BIKES LINK Manuel utilisateur

BAnff

BAnff eProdigy series Manuel utilisateur

Winther

Winther 475 Manuel utilisateur

Jetson

Jetson JBZL17 Manuel utilisateur

First Choice Mobility

First Choice Mobility Roma Medical Corella S741 Manuel utilisateur

Carrera

Carrera impel Manuel utilisateur

Afikim

Afikim Superlight SL-3 Manuel utilisateur

CareCo

CareCo ZOOM Manuel utilisateur

Douglas

Douglas Vespa G.S. Manuel utilisateur

Gazelle

Gazelle with BOSCH System Manuel utilisateur
