SmarTrax™ Installation Manual

Case MX 180-270 Series Wheel Tractors

While every effort has been made to ensure the accuracy of this document,

Raven Industries assumes no responsibility for omissions and errors. Nor is any

liability assumed for damages resulting from the use of information contained

herein.

Raven Industries shall not be held responsible or liable for the effects of

atmospheric conditions and sunspot activity on the performance of our products.

Raven Industries cannot guarantee the accuracy, integrity, continuity, or

availability of the GPS signal from the U.S. Department of Defense/NAVSTAR

GPS satellites, the OmniSTAR correction service or the WAAS correction

service.

Raven Industries accepts no responsibility for the use of the signal for other than

the stated purpose. Raven Industries shall not be responsible or liable for

incidental or consequential damages or a loss of anticipated benefits or profits,

work stoppage or loss or impairment of data arising out of the use, or inability to

use, the SmarTrax or any of its components.

Disclaimer

Manual # 016-0190-006

C H A P T E R

INTRODUCTION

Congratulations on your purchase of the Raven SmarTrax system! This system is designed

to provide cutting-edge, hands-free steering of your machine via GPS coordinates.

The instructions in this document are to be ussed to install the Smartrax Steering Kit for the

following models of CASE Wheel Tractors:

MX180,MX200,MX220,MX240,andMX270

Case MX 180-270 Series Wheel Tractors SmarTrax Installation Manual

Basic Kit

Contents

Below you will see the kit contents that you should have received with this SmarTrax

kit.

Case MX 180-270 Series Wheel Tractors SmarTrax Kit Contents

ytitnauQnoitpircseDmetIrebmuNtraP

1SPS,tiK100-1810-360

1072XMesaC,dlofinaM,.dyH,tekcarB,tnemdleW015-9510-611

1edirrevO/dioneloS,ciluardyH,elbaC664-1710-511

1sgtF/WjdAraB001-51,DH,orciM,erusserP,hctiwS470-0000-224

1feileR/WSLretneCdesolC,.dyH,evlaV660-3000-433

4daeHxeH"8/7x81-61/5,tloB401-2500-113

1gnoLmm52xmm61cirteMxeH,tloB900-0700-113

4"61/5,kcoL,rehsaW910-0001-313

1noitallatsnI,launaM600-0910-610

1xartramS,noitallatsnI,launaM120-1009-610

1petStoNoD,gninraW,lebaL886-9510-140

1gnirepmaT,gninraW,lebaL986-9510-140

3F/MCIJ6-,leviwS°54,woblE,.gtF720-2100-333

4F/M/MSFRO8-,eeTnuRleviwS,retpadA,.gtF820-2100-333

4F/MCIJ6-,leviwS°09,woblE,.gtF240-2100-333

4FJ6"386-S09FF8,dyH,esoH920-0001-412

1FJ6"084-S09FF6,.dyH,esoH030-0001-412

1FJ6"086-MF6,.dyH,esoH130-0001-412

Manual # 016-0190-006

C H A P T E R

SAFETY

Important: Hydraulics are under pressure. Never attempt to

open or work on a hydraulic system with the equipment running.

Care should always be taken when first opening a system that

was previously pressurized.

When disconnecting the hydraulic hoses or when purging is required, be aware

that the hydraulic oil within the machine system may be extremely hot and under

high pressure. Caution must be exercised. Any work carried out on the hydraulic

system must be performed in accordance with the machine manufacturerer’s

approved maintenance instructions. Raven Industries recommends that appropri-

ate protective equipment be worn when working on the hydraulic system. Ob-

jects or materials that are able to bypass the machine’s hydraulic filtration system

will adversely reduce performance and possibly damage the hydraulic valves.

Do not reverse the power leads. Doing so will cause severe damage to the

equipement. Always check to make sure that the power leads are connected to

the right polarity as marked. Ensure that the power cable is the last cable to be

connected.

Hydraulic

Safety

Requirements

Electical

Safety

Requirements

Case MX 180-270 Series Wheel Tractors SmarTrax Installation Manual

We welcome your feedback about this manual. If you have any comments or

suggestions for improvement, please let us know by contacting our Customer

Support Center by any of the following methods:



Via phone: 1-800-243-5435



Viamail:

Raven Industries

FlowControlDivision

205 E. 6th St.

Sioux Falls, SD 57104



Via email: [email protected]

Contacting

Raven

Industries

Manual # 016-0190-006

C H A P T E R

MOUNTING THE BRACKET AND VALVE

1. The Smartrax Valve and Pressure Switch are both mounted on the

supplied mounting bracket.

2. The Steering Override Pressure Switch is connected directly to the PS

Port on the Smartrax Valve.

3. The mounting point for the Steering Assist Valve Bank and Steering

Override Pressure Switch is located on the front of the transmission

housing, above and in front of the RHS rear axle in the wheel arch, and

behind the hydraulic pump.

SteeringAssist Valve Bank mounting location

Installing

Steering Assist

Valve Bank &

Steering

Override

Pressure

Switch

Case MX 180-270 Series Wheel Tractors SmarTrax Installation Manual

Steering Assist Valve Bank & Pressure Switch

(NOTE: Valve in picture differs from one currently used.)

4. Mount the Smartrax Valve w/Pressure Switch attached on the mounting

bracket using the supplied bolts.

Bracket mounting area

Steering Assist Valve Bank mounted

Manual # 016-0190-006

C H A P T E R

HYDRAULICS

Steering Assist

Valve Bank

Hose Routing

Location of tractor SCU - Close-up View

Case MX 180-270 Series Wheel Tractors SmarTrax Installation Manual

2. Attach the tee connectors supplied to the L, R, P, and Tports of the

SCU.

The figure below shows the tractor SCU ports before installation.

Important: Take precautions to prevent any contaminates

being introduced into the tractors hydraulic system.

Helpful Hint: The L& Rtee connectors should be

positioned towards the LHS of the tractor while the P& T

connectors should be positioned to the RHS of the tractor to

provide easy installation of the hydraulic hoses.

Ports T, P, A, and B connections on SCU before install

T, P, A, and B tee connections on SCU after install
