AccuBoom™ Installation Manual

CaseIH SPX3310

Notes:

Manual # 016-0171-004

1

CHAPTER

I

NTRODUCTION

Congratulations on your purchase of the Raven AccuBoom system! This

system is designed to provide worry free turn-on and turn-off of your

booms with respect to the as-applied coverage map. The following

instructions are designed to assist you in the proper installation of the

AccuBoom system. See the Viper Installation and Operators Manual for

instructions on setting up the software and using the AccuBoom system.

You will also need a valid AccuBoom Control Activation Key for your

Viper system in order to activate the AccuBoom system.

Components

Needed

• Previously installed CASE SPX3310 AccuBoom System

• AccuBoom SPX3310 AIM Extension Cable – P/N 063-0171-577

Important! All boom switches must remain in

the ON position while AccuBoom control is in

operation!

Case IH SPX3310 AccuBoom AIM Control Extension Cable Installation and Operators Manual

2

Notes:

Manual # 016-0171-004

3

CHAPTER

AIM E

XTENSION

C

ABLE

I

NSTALLATION

1. Install the CAN AccuBoom node and SPX3310 CAN AccuBoom cable

(P/N 115-0171-553) according to the instructions provided with the

CAN AccuBoom cable.

2. Connect the Raven AIM Command cable to the AccuBoom cable:

a. Remove the cap from the 6 pin Deutsch AIM Command connector

on the CAN AccuBoom cable (P/N 115-0171-553).

b. Attach the optional Raven SPX3310 AIM Command cable

(P/N 115-0171-577) to the 6 pin Deutsch connector on the CAN

AccuBoom cable.

Right Boom Connector

Mount CAN Accuboom Node Here

AIM Extension

Connector

Case IH SPX3310 AccuBoom AIM Control Extension Cable Installation and Operators Manual

4

3. Route the Raven AIM Command cable (P/N 115-0171-577) up to and

into the cab.

4. Remove the side panel cover to gain access to the wiring.

Manual # 016-0171-004

5

5. Disconnect the AIM Command cable from the control system:

a. Locate the Case AIM Command Tee cable in the side access

panel. These will be 6 pin Weatherpack connectors.

b. Disconnect the Case AIM Command Tee cable from the boom

shutoff sense connectors.

c. Connect the two ends of the system harness back together.

6. Connect AccuBoom to the AIM Command:

a. Connect the optional SPX3310 Raven AIM Command cable

(P/N 115-0171-577) to the AIM Command Tee cable.

b. Connect the supplied tee cap to the other end of the Case AIM

Command cable.

7. Replace the side panel cover.

8. The AIM Command module will now be controlled by the Raven CAN

AccuBoom system.

AIM Command Tee
