Welcome
Overview
Raritan's keyboard/video/mouse (KVM) switches are engineered to pro-
vide reliable, cost-effective, central control of multiple computers. This
eliminates the cost and clutter of unnecessary equipment, reclaims
space, and improves productivity for a host of applications.
MasterConsole II enables control of any mix of 2 to 256 computers
from a single keyboard, monitor, and mouse. MasterConsole II user
interface provides simple on-screen control and system management.
Raritan's unique emulation technology dedicates a keyboard/mouse
emulator for each computer to ensure that each computer always 'sees'
its own keyboard and mouse. This means smooth, flawless switching
and operation, even when computers are running the most demanding
operating systems.
Features
·Models for 4, 8, or 16 computers
·Mix any brand PCs, Macs, Suns, Alphas, RS/6000s, HP9000s, SGIs
·“Keep-alive” emulation ensures non-stop computer operation in the
event of power loss to the switch
·High resolution video-1600x1280
·Tangle-proof, double-shielded coaxial cable from 6.5, to 30 feet
·On-screen user interface for simple control and system management
·Assign meaningful names to computers for quick identification and
selection
·Operate with front panel buttons or hot-keys with on-screen menus
·AutoSkip function to bypass inactive channels
·AutoScan computers at variable rates
·Password Security to ensure authorized access to computers
·Optional Dual Remote access capability with Cat5 Reach
·Compatible with MasterView ready MasterConsole P Models (MCPn)
·Cascade from a multi-user MasterConsole MX4
·One year warranty for parts and labor
1
One-Tier and Two-Tier Configurations
MasterConsole II can be configured in one or two tiers, depending on the
number of computers you want to control. In a one-tier configuration,
only computers are connected to a single MasterConsole II unit. See
Figure 1. In a two-tier configuration, either a computer or another
MasterConsole unit is connected to each channel of the base
MasterConsole II unit. See Figure 2.
2
Figure 1. One-Tier Configuration
Figure 2. Two-Tier Configuration (With optional Remote Access)
Getting Started
MasterConsole II is designed for quick, easy installation and operation.
Follow the steps for either one-tier or two-tier configuration to be up and
running within minutes:
1. Install MasterConsole II (connect computers).
2. Configure MasterConsole II.
3. Assign computer names and set channel-specific Scan
Rates for attached computers.
4. Turn ON security and change passwords if you want to
restrict access to computers connected to MasterConsole II.
5. Operate using On-Screen User Interface or front panel buttons.
6. Install optional Cat5 Reach for remote console or satellite unit.
3
Quick-Start Operation
After you connect computers to your MasterConsole II
you may wish to explore MasterConsole II operation
with the default names and parameters.
You may operate using the front panel buttons and/or
the On-Screen User Interface. To activate On-Screen
User Interface, press the <ScrollLock>> key twice
rapidly. The Selection Menu will appear. To select a
computer, use the <Ï>/<Ð>keys to highlight the
desired channel (computer) and press <Enter>or
press the desired computer's Key number (located in
the left-hand column). To select another computer,
use front panel buttons or re-activate the On-Screen
User Interface.
One-Tier Configuration
Installing MasterConsole II (One-Tier)
1. Shut down and power off all computers to be connected to
MasterConsole II.
2. Plug a keyboard, monitor, and mouse into the keyboard, moni-
tor, and mouse ports on the MasterConsole II back panel. See
Figure 3 and Figure 4.
3. Power ON the MasterConsole II unit.
4. Using a universal cable kit (CCPnnU), plug the 25-pin connector
into one of the numbered channels on the MasterConsole II back
panel.
5. Plug the cable's other connectors into the computer's keyboard,
monitor, and mouse ports. Use supplied adapters for AT style
PCs. See Figure 5.
6. Power ON the connected computer.
7. Select the connected computer by pressing the corresponding
front panel button. Verify that the monitor attached to
MasterConsole II displays the video for the connected computer.
Use the keyboard and mouse attached to MasterConsole II to
verify that they operate the connected computer.
8. Repeat Steps 4through 7to connect the remaining computers to
MasterConsole II.
4
Figure 3. MasterConsole II Back Panel
Note: An amber channel light above a numbered channel button on
the MasterConsole II front panel indicates that the channel is
active; that is, a computer is connected and powered on. A
green light above a numbered channel button indicates the cur
rently displayed channel. See Figure 6 and Figure 7.
