Rand McNally RVND 7720 Manuel utilisateur
Quick Start Guide 1
Guide de Démarrage Rapide 17
1
Important Information About Your RVND™7720
Wi-Fi®:Some features of this device require wireless connectivity, which requires a supporting feature and data plan from your
wireless service provider. As the user, you are responsible for all data charges. Please contact your wireless service provider to
make sure you do not exceed the limits of your data plan.
Rand McNally Dock: Keep your device up to date by downloading the Rand McNally Dock for your home computer
at www.randmcnally.com/dock and connecting your device with the USB cable provided.
Learn More: Access Tutorial & Tips under Preferences > General on your device for more information, or visit
www.randmcnally.com/support to download the user manual.
Power Button: Press and hold the orange power button to turn the device on or off. The power button can also
be used for quick access to certain features while the device is running. See Preferences > General > Quick Power Press
for options. A red light indicates the battery is charging; a green light indicates the battery is fully charged.
Reset: Use the reset button on the back of the device to restart. This will cancel the current route, but preferences,
address book, and other personal data will be saved.
Install the Mount
Note: Follow all local regulations governing the placement of the mount.
1. Select an area with a line of sight to the sky and GPS satellites to ensure reliable GPS information.
2. Clean and dry the mounting area.
3. Remove the suction cup protective film.
4. Adjust the angle of the mount using the thumbscrew.
5. Pull the suction cup lever up to release suction.
6. Plug the power cord into the device and the vehicle’s 12-volt power source.
7. Slide the device onto the mount.
8. Place and hold the mount suction cup against the mounting surface.
9. Press the suction cup lever down until it snaps into place.
10. Adjust the device so that it can be easily seen and does not block the driver’s line of sight.
2
3
1Enter RV information and access RV-specific tools.
2Show location on the map and view navigation instructions.
3Choose a destination.
4Select general, route, and map preferences.
5Mute/unmute the speaker.
6Adjust speaker volume.
7Battery status indicator.
Main Menu
1 2 3
4 5 6
7
4
1. Tap RV Tools > RV Info or Warnings.
2. Tap and to view options.
3. Tap the option button to be changed.
4. Enter new settings.
5. Tap to save changes.
1. Tap Preferences.
2. Tap the General, Route or Map tab.
3. Tap and to view options.
4. Tap the option button to be changed.
5. Enter new settings.
6. Tap to save changes.
On the left,
tap on an
option
On the right,
enter settings
for the option
Enter RV Information and Set Warnings
Set Routing and Device Options
On the left,
tap on an
option
On the right,
enter settings
for the option
5
Route to a Destination
1. Tap Choose Destination > New Location.
2. Tap Address.
3. Enter the name of the city. (Note: As you type, the keyboard displays
only the next possible letter.)
4. Prompts appear in the top bar. Tap the city to select. Or, tap List to
view cities beginning with the letter(s) you entered.
5. Enter the street name. (Note: If the letters you need do not appear,
tap Expand Search.)
6. Enter the house number.
See Confirm Destination Window (page 6).
Tips
s You can also route to a new location by City Center, Intersection,
or Latitude/Longitude, or choose Address > Zip Code Search.
s View recent destinations by tapping Choose Destination > History.
View recent cities by tapping Choose Destination > New Location
> Address > History.
s View saved locations by tapping Choose Destination >
Address Book.
6
Confirm Destination Window
1Destination address.
2Begin route to destination.
3Add the location as a via point on the way to
a previously entered destination.*
4Save the location to the Address Book.
5Cross reference to printed Rand McNally Road Atlas.
6View the map.
7Change the starting location for a route to the
location displayed here.
8Return to Main Menu.
9Return to previous window.
*To manage via points, Tap Choose Destination >
Multi-Stop Trips. You can add up to 50 destinations in a
multi-stop trip, and optimize routing for trips of up to 10 stops.
NOTE: This window may include
additional buttons based on the
type of destination selected.
1
34
5 6
8
7
9
2
7
1Repeat spoken next-maneuver instructions.
2Name of street you will turn onto next.
3Show arrival time, remaining time, or other options.
4Slide out to show upcoming exit information.
5Directions list slideout. Tap Route Display Options
to select turn-by-turn, highway, or map view.
6Zoom in/zoom out.
7Access weather data and maps. (Wi-Fi required.)
8Return to Main Menu.
9Select a map display option (Heading Up, North Up,
or 3D View). Also displays Wi-Fi status.
10 View current road name, upcoming cross road name, or city, county and state.
11 View and save current location, detour, or cancel a route.
12 Tap on the current speed to display the Virtual Dashboard.
(Note: Turns red for speed warnings; set in RV Tools > Warnings.)
13 Current speed limit. Tap to open a “Tell Rand” about speed limits.
14 View the Traffic Window (enabled with traffic receiver accessory).
15 Mute the speaker.
Route Map Window
13
4
5
6
8
7
9
2
10
11
12 15
14
13
8
7
6
8
1
3
45
2
Find a Point of Interest (POI)
Tap Choose Destination > Points of Interest.
1Find popular RV-friendly POIs near your current location.
Search for a POI:
2Near your RV
3In a particular city
4Along your route
5Near your destination
POI Categories:
6Select a category.
7Find restaurants, hotels, and other subcategories.
8View custom POIs that have been uploaded through
the Rand McNally Dock.
9
When on a route, Junction View displays when you have an upcoming maneuver.
Once past the maneuver, Junction View closes and the previous window displays.
1Signs to follow for the next maneuver.
2Number and direction of lanes for the next maneuver.
3Distance to the upcoming maneuver. Distance decreases as you
approach the ramp.
4Lane assist arrow.
5Mute the speaker.
6Return to previous window.
1
3
2
4
56
9Tap location to select.
10 View and edit ratings and comments.
11 Tap to search by available services.
12 Apply or remove services filter for search results.
910
11 12
Find a Point of Interest (POI) -
continued
Junction View
