Complete Personal Navigation System
GPS NAVIGATOR
Quick Start Guide
Rand McNally GPS Navigator Quick Start GuideHelp (866) 627-3526
Overview
Battery Charge Indicator
The indicator will shine orange during the
charging process. It will shine green when
the battery is completely charged.
Touch Screen
Hardware buttons
On-/Off button
Navigation Menu
Increases the volume
Reduces the volume
3
2
1
1
23
This Quick Start Guide provides a brief overview of
the Rand McNally GPS Navigator and its functions.
For more detailed information, see the User Guide.
The User Guide can be found on the supplied CD
or at www.randmcnally.com/gps.
Rand McNally GPS Navigator Quick Start Guide 1Help (866) 627-3526
On-/Off button
Navigation Menu
Increases the volume
Reduces the volume
Stylus
Memory Card Slot
External GPS antenna jack
Headphone jack
Speaker
Mount connector
Reset button
Mini-USB- Connector
Main POWER switch
Always leave the main switch
ON, unless you want to reinstall
software.
9
10
11
8
4
5
6
7
5
4
9
7
8
6
GPS antenna
12
11
12
This Quick Start Guide provides a brief overview of
the Rand McNally GPS Navigator and its functions.
For more detailed information, see the User Guide.
The User Guide can be found on the supplied CD
or at www.randmcnally.com/gps.
10
Rand McNally GPS Navigator Quick Start Guide2 Help (866) 627-3526
Powering On for the First Time
Insert the included memeory card in the top slot.•
NOTE: This process needs to be done only once,
prior to the initial use. After initial start, use
the power button on the top right hand side
of the GPS Navigator.
Using the device stylus (stored in the lower left corner of
the back side of the device), or a ballpoint pen, move the
switch on the bottom of the device to the “on” position
•
5
see page 1
12
see page 1
Rand McNally GPS Navigator Quick Start Guide 3Help (866) 627-3526
Attaching the GPS Navigator to the Windshield
Insert 12v cable into USB port
Attach the device to the cradle of the
mounting holder
Place the suction cup firmly on the windshield
Switch lever to hold in place
Plug the 12v car charger into cigarette lighter
3
2
1
5
1
3
2
5
4
4
Rand McNally GPS Navigator Quick Start Guide4 Help (866) 627-3526
Getting Started
To turn the Rand McNally GPS Navigator on
push the button on top right side of unit.
Use touch-screen for all menu/screen selections.
Read and accept the safety message.
The first use of the Rand McNally GPS Navigator
requires a few additional steps:
1After turning on your unit, you will be prompted to
select your language.
2Several startup screens will flash. When asked
“Do you want to select the navigation map now?” tap .
3You will be taken to a screen that asks you to select a
geographic map area. Highlight the map that corresponds
to your current geographic region (this can be changed
later from the Settings screen).
•
•
•
NOTE: When the unit has been off for a few days
or more, it may take up to 10 minutes to
receive the GPS signal. With regular usage
it will acquire a signal in under 2 minutes.
For best results, keep unit standing still and
in a clear outdoor area during initial startup.
Rand McNally GPS Navigator Quick Start Guide 5Help (866) 627-3526
Selecting a Destination
Main menu
Navigation menu
Address screen
Keyboard screen
1
2
3
4
1
2
3
4
From the initial Main menu
tap to access the Navigation
menu .
At any time, press the button on
the right side of your GPS Navigator to
return to the navigation menu.
Tap to access the address
entry screen .
Enter destination information by
tapping on the address fields and
typing the information using the
on-screen keyboard .
Enter ZIP code (if known) or City
first, then Street name, then
Address Number.
After entering three or more letters,
the GPS Navigator will provide you
with a list of possibilities. Continue
entering or scroll through the list to
select the name you want.
Tap to enter a space.
Tap to enter numbers.
Tap to delete or go back a space.
Tap to confirm the entered data.
Once the address information is
completely entered, tap
The GPS Navigator will calculate
your route and then the navigation
map will appear and voice prompts
will begin.
•
•
•
•
•
•
•
•
•
•
•
•
Rand McNally GPS Navigator Quick Start Guide6 Help (866) 627-3526
Selecting a Destination continued
Navigation screen
Options screen
1
2
1
2
Follow the turn-by-turn voice prompts
and visual directions on the map.
The navigation arrow
shown on the Navigation screen
will show you your progress as you
move down the street.
The GPS Navigator will automatically
re-route you if you miss a turn.
At any time, you can tap the green
menu bar icon in the upper right
corner for more options to control
the map.
At any time, you can tap on the map
itself to be shown options for
detours, night mode, quit
navigation, etc.
•
•
•
•
•
Zoom out to view
entire route.
Zoom in/out
Main menu
Hide
menu bar
Switch between panning
and manual zoom modes
Freeze / unfreeze map while navigating
Repeat the
voice directions
Rand McNally GPS Navigator Quick Start Guide 7Help (866) 627-3526
Enter a Point of Interest
Main menu
Navigation menu
Point of Interest screen
From the Main menu tap
to access the Navigation menu .
Tap on the Navigation
menu to access the Point of
Interest entry screen .
On the Point of Interest screen ,
chose a point of interest near current
location or in a different city.
Enter City, Category, Subcategory
information on the Category screen .
Tap the Point of Interest field to display
the list of choices.
Once the point of interest is selected,
tap , then tap
•
•
•
•
•
•
1
2
3
4
1
2
3
4
3
Category screen
2
Rand McNally GPS Navigator Quick Start Guide8 Help (866) 627-3526
Recent destinations are automatically
stored and can be permanently saved
in My Favorites.
To save any address to My Favorites:
After inputting an address or
selecting a Recent Destination,
tap .
A new screen will open. Type in a
name of your destination.
Any time you save a destination,
it will be stored in your My Favorites
folder as seen on the Navigation
menu .
To navigate to a recent or
favorite destination:
Tap Recent Destinations or
My Favorites on the
Navigation Menu .
Find destination by scrolling through
list .
Select destination by tapping .
Once the address information is
selected, tap
on the destination address screen .
•
•
•
•
•
•
•
Recent Destinations & My Favorites
Destination address screen
1
2
3
1
2
3
Navigation menu
1
