ISCOM 1024E User Manual
Legal Notices
Raisecom Technology Co., Ltd makes no warranty of any kind with regard to this manual,
including, but not limited to, the implied warranties of merchantability and fitness for a particular
purpose. Raisecom Technology Co., Ltd shall not be held liable for errors contained herein or direct,
indirect, special, incidental or consequential damages in connection with the furnishing, performance,
or use of this material.
Warranty.
A copy of the specific warranty terms applicable to your Raisecom product and replacement parts
can be obtained from Service Office.
Restricted Rights Legend.
All rights are reserved. No part of this document may be photocopied, reproduced, or translated to
another language without the prior written consent of Raisecom Technology Co., Ltd. The
information contained in this document is subject to change without notice.
Copyright Notices.
Copyright ©2006 Raisecom. All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any
means, electronic or mechanical, including photocopying and microfilm, without permission in
Writing from Raisecom Technology Co., Ltd.
Trademark Notices
is the trademark of Raisecom Technology Co., Ltd.
Java™ is a U.S. trademark of Sun Microsystems, Inc.
Microsoft® is a U.S. registered trademark of Microsoft Corporation.
Windows NT® is a U.S. registered trademark of Microsoft Corporation.
Windows® 2000 is a U.S. registered trademark of Microsoft Corporation.
Windows® XP is a U.S. registered trademark of Microsoft Corporation.
Windows® and MS Windows® are U.S. registered trademarks of
Microsoft Corporation.
Contact Information
Technical Assistance Center
The Raisecom TAC is available to all customers who need technical assistance with a Raisecom
product, technology, or, solution. You can communicate with us through the following methods:
Address: 2nd Floor, South Building of Rainbow Plaza, No.11 Shangdi Information Road,
Haidian District, Beijing 100085
Tel: +86-10-82883305
Fax: +86-10-82883056
World Wide Web
You can access the most current Raisecom product information on the World Wide Web at the
following URL:
http://www.raisecom.com
Feedback
Comments and questions about how the RCMS2811 series devices work are welcomed. Please
review the FAQ in the related manual, and if your question is not covered, send email by using the
following web page:
http://www.raisecom.com/en/xcontactus/contactus.htm.
If you have comments on the device specification, instead of the web page above, please send
comments to:
We hope to hear from you!
CONTENTS
Chapter 1 ISCOM 1024E Overview---------------------------------------------------------------- 1
1.1Package --------------------------------------------------------------------------------------------------------------------------1
Chapter 2 Parameters ---------------------------------------------------------------------------------- 2
2.1 Features: ------------------------------------------------------------------------------------------------------------------------2
2.2 Specifications:------------------------------------------------------------------------------------------------------------------2
2.3 Environment and power:-----------------------------------------------------------------------------------------------------2
Chapter 3 Mechanical structure and indicators---------------------------------------------- 3
Chapter 4 configuration and management ------------------------------------------------------ 5
4.1 Manual overview---------------------------------------------------------------------------------------------------------------5
4.2 Configure ISCOM1024E through console ------------------------------------------------------------------------------5
Chapter 5 Network Connection -------------------------------------------------------------------15
5.1 Connect ISCOM 1024E----------------------------------------------------------------------------------------------------15
5.2 Connect ISCOM1024E with other Ethernet switch or HUB ------------------------------------------------------15
5.3 Application---------------------------------------------------------------------------------------------------------------------15
Chapter 6 Placed ISCOM1024E -------------------------------------------------------------------16
Chapter 7 Trouble shooting------------------------------------------------------------------------17
7.1 How to resolve link LED off-----------------------------------------------------------------------------------------------17
7.2 Q & A ---------------------------------------------------------------------------------------------------------------------------17
Chapter 8 Cable----------------------------------------------------------------------------------------18
Preface
About This Manual
This manual introduces primary functions of the configuration management software for RC series
products.
Who Should Read This Manual
Sales and marketing engineers, after service staff and telecommunication network design engineers
could use this manual as a valuable reference. If you want to get an overview on features,
applications, architectures and specifications of Raisecom RC series integrated access devices, you
could find useful information in this manual as well.
Compliance
The RC series products developed by Raisecom are strictly complied with the following standards as
well as ITU-T, IEEE, IETF and related standards from other international telecommunication
standard organizations:
YD/T900-1997 SDH Equipment Technical Requirements - Clock
YD/T973-1998 SDH 155Mb/s and 622Mb/s Technical conditions of optical transmitter module and
receiver module
YD/T1017-1999 Network node interface for the Synchronous Digital Hierarchy (SDH)
YD/T1022-1999 Requirement of synchronous digital hierarchy (SDH) equipment function
YD/T1078-2000 SDH Transmission Network Technique Requirements-Interworking of Network
Protection Architectures
YD/T1111.1-2001 Technical Requirements of SDH Optical Transmitter/Optical Receiver
Modules——2.488320 Gb/s Optical Receiver Modules
YD/T1111.2- 2001 Technical Requirements of SHD Optical Transmitter/Optical Receiver
Modules——2.488320 Gb/s Optical Transmitter Modules
YD/T1179- 2002 Technical Specification of Ethernet over SDH
G.703 Physical/electrical characteristics of hierarchical digital interfaces
G.704 Synchronous frame structures used at 1544, 6312, 2048, 8448 and 44 736 kbit/s hierarchical
levels
G.707 Network node interface for the synchronous digital hierarchy (SDH)
G.774 Synchronous digital hierarchy (SDH) - Management information model for the network
element view
G.781 Synchronization layer functions
G.783 Characteristics of synchronous digital hierarchy (SDH) equipment functional blocks
G.784 Synchronous digital hierarchy (SDH) management
G.803 Architecture of transport networks based on the synchronous digital hierarchy (SDH)
G.813 Timing characteristics of SDH equipment slave clocks (SEC)
G.823 The control of jitter and wander within digital networks which are based on the 2048 kbit/s
hierarchy
G.825 The control of jitter and wander within digital networks which are based on the synchronous
digital hierarchy (SDH)
G.826 End-to-end error performance parameters and objectives for international, constant bit-rate
digital paths and connections
G.828 Error performance parameters and objectives for international, constant bit-rate synchronous
digital paths
G.829 Error performance events for SDH multiplex and regenerator sections
G.831 Management capabilities of transport networks based on the synchronous digital hierarchy
(SDH)
G.841 Types and characteristics of SDH network protection architectures
G.842 Interworking of SDH network protection architectures
G.957 Optical interfaces for equipments and systems relating to the synchronous digital hierarchy
G.691 Optical interfaces for single channel STM-64 and other SDH systems with optical amplifiers
G.664 Optical safety procedures and requirements for optical transport systems
I.731 ATM Types and general characteristics of ATM equipment
I.732 ATM Functional characteristics ofATM equipment
IEEE 802.1Q Virtual Local Area Networks (LANs)
IEEE 802.1p Traffic Class Expediting and Dynamic Multicast Filtering
IEEE 802.3 CSMA/CDAccess Method and Physical Layer Instruction
www.raisecom.com User Manual
1
Chapter 1 ISCOM 1024E Overview
ISCOM 1024E is an Ethernet switch with VLAN and QOS. It can provide 24X10/100Mbps RJ45 interfaces and support
Local craft terminal management through Console, Port-Based VLAN and 802.1q VLAN, Port-Based QOS, Tag-Based
QOS and TOS-Based QOS, support abundant port managed and loop back detection function.
ISCOM 1024E is a good choice for residents and enterprise sites.
1.1Package
z1 unit ISCOM 1024E
z1 AC power supply cable
z1 RS232 connectivity cable
z2 screw for bracket used on cabinet
www.raisecom.com User Manual
2
Chapter 2 Parameters
2.1 Features:
z24x10/100Mbps RJ45 interface
zIt supports MDI or MDI-X
zIt supports CONSOLE local management
zBi-directional Nx32Kbps bandwidth management
zPort rate limiting, Based on ingress and egress of each port, 8 levels
zQoS: Support IEEE802.1p and DSCP classification, Port-based CoS
zIt supports flow control
zIt supports PORT VLAN and TAG VLAN
zIt supports broadcast filtering
2.2 Specifications:
Protocols : IEEE802.3 10Base-T,IEEE 802.3u 100Base-TX IEEE802.3x
Cables: 10Mbps:3,4,5 CAT twisted pairs. 100Mbps:CAT5 Twisted pair;
Number: 24xRJ45
VLAN: supports port-VLAN and TAG VLAN
QOS: Support IEEE802.1p and DSCP classification, Port-based CoS
Security: lock port (static MAC address residents in filter table)
Port loop back detection
Panel: PWR, SYS, LNK/ACT,100M,FDX
Dimension: 440Wmm x 120Dmm x 43.6Hmm
Store and forward: full wire speed
MAC table: 8K
Buffer: 160K
2.3 Environment and power:
Environment Temp:０~５０ centigrade
Humidity: 5% ~ 95%
Power consumption: く15W
Power: 100-240VAC，50-60Hz
www.raisecom.com User Manual
3
Chapter 3 Mechanical structure and indicators
The front panel of ISCOM1024E contains 24 10/100Mbps RJ45 interface, 1 console port and LED.
zSwitch logo and type: ISCOM1024E
zConsole management
z24 10/100Mbps RJ45 interface
z2 LED SYS and PWR
LED color state indication
flashing normalSYS Green
off Software fault or just finished power on and
the system is starting
flashing Power onPWR Green
off Power off
zLEDs provide all of information and status of interface of Ethernet switch.
LED
State Condition
Green 100Mbps
Yellow
10Mbps。
Fixed
on
There is a effected link
LNK/
ACT
Flashin
g
Sending and receiving
packet
