RaidSonic IB-2226StS Manuel utilisateur
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany
Telefon: +49-(0)4102 – 468 900 (Vertrieb) • Fax: +49-(0)4102 – 468 901 • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted. RaidSonic
STORAGE SOLUTIONS WITHOUT LIMITS
Key features
• 2x 2.5" SATA HDD or SSD in 1x 3.5" bay
• Easy Swap®- tool less HDD or SSD installation
and exchange
• Hard disk capacity not limited
• Support HDD height up to 9.5 mm
• SATA host interface 3.0 Gbit/s
• Low noise, fanless design
• LED for power and HDD access
• Supports Hot Swap
• Supports all operating systems
IB-2226StS
2x 2.5" SATA Mobile Rack
Technical data
Model IB-2226StS
Article No. 20904
EAN code 4250078184553
Brand ICY BOX
Article text 2x 2.5" SATA Mobile Rack
Colour Black
Material Aluminium/Plastic
HDD size 2.5"
HDD height Up to 9.5 mm
HDD interface 2x SATA I/II
HDD capacity No limit
Required space 1x 3.5"
Hot Swap Yes
Plug & Play No
Host interface 2x SATA Power Connector 15Pin/
2x SATA Data Connector 7Pin
Transfer rate Up to 3 Gbit/s
Operating system OS independent
LED Power/HDD Access
Alarm No
Lock No
Power switch No
Fan No
Power connector 2 x 15Pin SATA
Double-decker
This is the way how two 2.5 SATA HDDs or SSDs fit into a 3.5" bay. Each has its own
front-flap and an LED for power and access indication. Easy Swap allows for quick
mounting and demounting without any tool.
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany
Telefon: +49-(0)4102 – 468 900 (Vertrieb) • Fax: +49-(0)4102 – 468 901 • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted. RaidSonic
STORAGE SOLUTIONS WITHOUT LIMITS
Packing content: 1x IB-2226StS, 2x SATA cable, 2x power and LED cable, 4x screw, 1x HDD protection film, 1x manual
Front view
Unlocking
HDD 1 and HDD 2
LED Power/Access
HDD 1 and HDD 2
LED Connector 4Pin
SATA Power
Connector 15Pin
SATA Data
Connector 7Pin
Rear view
Logistical data
Packing unit: 32 pcs./carton Dimension / carton: 475x372x269 mm Import tax: 84733080
Total weight: 16.0 kg/carton Dimension (incl. packing): 175x52x126 mm
Gross weight (inc. packing): 0.45 kg Dimension from article: 102x25x133 mm
Net weight: 0.217 kg Country of origin: China
