Raidon iR8023 Manuel utilisateur
InTANK
iR8023
User Manual
» InTANK iR8023 User Manual ............................. 1
1. Package Contents and Product Views ..............................1
2. Operation Information........................................................2
3. Hardware Requirements and Precautions ........................3
4. Hardware Installation Procedure .......................................3
5. RAID Mode Setting............................................................4
6. Computer Setup ................................................................5
7. Hard Disk Status on LCD Screen......................................6
8. Data Rebuilding Operation ................................................7
9. GUI Monitoring Software and Firmware Update ...............8
10. Questions & Answers ......................................................10
» InTANK iR8023 䔉⒨ὦ䔏媑㗵 ........................... 12
1. 䔉⒨⣽妧⎱⋬壄ⅎ⮠ ..........................................................12
2. 䒗⡪曧㰩 ............................................................................13
3. 䡓檻曧㰩凮㳏ヶṲ柬 ..........................................................14
4. 䡓檻⭰壄 ............................................................................14
5. 娔⮁ RAID ⱋ䴁..................................................................15
6. 曢免娔⮁ ............................................................................16
7. 姱ざ桖䤡 ............................................................................17
8. 岮㖀憴⻡⊆僤媑㗵..............................................................18
9. GUI ⊆僤媑㗵凮枳檻㛛㖗...................................................19
10. ⸟奲┶栳 ..........................................................................21
iR8023 User Manual
V1.0
iR8023 User Manual
1
1. Package Contents and Product Views
Introduction
Thank you for purchasing RAIDON products. This User Manual will introduce you the InTANK iR8023
storage product. Before using your iR8023, please read it thoroughly. Although all information
to the product or its relevant information may be listed on www.raidon.com.tw . Product is subjected
If you have any question regarding to the product you purchased, or you would like to know the
latest product information, User Manual’s update, please contact to your local supplier or visit to
www.raidon.com.tw for further information.
Copyright © Raidon Technology, Inc. – All right is reserved.
iR8023
iR8023 x1 ( with removable drive tray enclosed x3)
SATA Cable x1
Screws & Keys
Quick Installation Guide x1
• Please check the product and accessories for any defect or missing parts. If you have any questions,
please contact your product supplier.
•
iR8023 User Manual
2
Product View, Front and Back
LED IndicatorsƝ
10
1. LCD Display
2. UP/DOWN Buttons
3. ESC Button
4. Enter Button
5. Mute Button
6. Power Failure Indicator
1. Cooling Fan
2. 3-pin Fan Connector
3. RS232 Connector
4. 7-pin SATA Connector (Standalone HDD)
5. 15-pin Power Connector
6. 7-pin SATA Connector (RAID HDD)
Status Standalone HDD RAID HDD System Indication Buzzer
No HDD N/A Red light always on Purple light always on ON
HDD Idle Blue light always on Blue light always on Blue light always on N/A
Access Blue light always on N/A
Rebuilding-Source Blue light always on Blue light always on Blue light always on N/A
Rebuilding-Target Blue light always on Blue light always on N/A
Fan Failure Blue light always on Blue light always on Purple light always on ON
7. HDD Tray Handle
8. HDD Tray Ejection
9. HDD tray key lock
10. HDD Access Indicator
2. Operation Information
0ǡ40 濎(32 ǡ104 ʲ)
ooF)
Standalone HDD
Pri HDD
Sec HDD
iR8023 User Manual
3
3. Hardware Requirements and Precautions
1. Computers or servers must be with SATA I, SATA II, or SATA III interface.
2. Only support 2242/2260/2280 M.2 SATA SSD dimension.
3. The independent drive at the top cannot be set into RAID mode with primary or secondary drive.
It is an independent drive.
4. You are strongly advised to set the storage mode before using your iR8023. (The default setting is
the RAID 1.)
5.
drives to set the drive mode will result in complete data loss. If you must change the drive mode,
make sure to backup all data prior to the mode change.
6. A reboot is required after adding or changing RAID mode to ensure that the update is completed
to the new RAID mode.
7.
to use the two hard drives from the same manufacturer.
8. Please make sure that the two hard drives are free from bad blocks or defects prior to installation
in order to avoid system crashes or data loss.
9.
stated on the hard drives combined once the drives have been formatted.
10.It is highly recommended for user to back up important data contained within the iR8023 unit on
a regular basis or whenever the user feels necessary to a remote or a separate storage device.
RAIDON will not be responsible for any lost of data caused during the use of the unit or the
recovery of the data lost.
4. Hardware Installation Procedure
Please follow the instructions below to complete the hardware installation.
Step1.
Step2.
Step3.
Step4.
Step5.
Step6.
Step7.
Step8.
Step9.
Step10.
Unlock the M.2 SATA Bridge Tray Key Lock and push the HDD tray ejection to the right .
Pull out the M.2 SATA Bridge Tray.
Remove the screws of the upper cover of the M.2 SATA Bridge.
Open the upper cover .
Remove the paper from the heat sink in the upper cover and put the upper cover back.
Fix the screws.
Install the M.2 SATA Bridge tray back into the iR8023
Install device into one of the CD-ROM bays with screws from the accessory kit.
Then properly connect SATA cable and SATA power cable from your system to device.
Power on your system after hardware installation is completed, and your operating
system will automatically detect the hard drives from booting. Then follow the steps from
your operating system to partition and format the drives when necessary, device will be
ready to use once the format is completed.
iR8023 User Manual
4
5. RAID Mode Setting
After placing your two hard disks, turn on power and press UP Button, you are with the RAID Setting
mode. (Since the default setting is RAID 1 mode by factory, you do not have to reset RAID if you
want to use your iR8023 with RAID 1 mode.)
1. RAID 1 mode
1). Place two new hard drives into iR8023.
We would strongly suggest you to use two identical hard drives to get the maximum memory
the memory capacity at the small capacity hard drive.
2). Under RAID 1 mode, two hard drives will have the identical information as one from its mirroring
feature, therefore, even though one and only one of the two hard drives failed, iR8023 will
automatically do rebuilding the data from the good one to the new hard disk.
1234
5678
2
3
7
Lock Unlock
4
8
※
1.
2. We do not recommend users to disassemble the device without proper instructions and authorization. The manufacture warranty
will not cover the damages caused by unauthorized disassembling.
3. To prevent the device from malfunction, please make sure the device is connected with a direct and dedicated power connection of
a stable power input.
4.
W
e do not recommend users to disassemble the device without proper instructions and authorization. The manu
f
acture warrant
y
will not cover the dama
g
es caused b
y
unauthorized disassemblin
g
.
4"5"
4"5"
SATA Cable
SATA Power Cable
*OUFSOBMIPTUTIFMMTDIFNBUJD
1
2
iR8023
iR8023
iR8023 User Manual
5
6. Computer Setup
When the hardware setup for iR8023 is complete, you are now ready to turn the machine on.
After the hardware installation is complete, the iR8023 will be treated as one single hard drive. When
the computer is turned on, the system will retrieve the following information.
1. Device Manager Utility of Window OS will automatically detect the hard drive(s).
2. You can choose to format the hard drive by using the Disk Management tool of the operating
system before using the iR8023.
data to iR8023 just like retrieving and saving data to a regular hard drive. If the user has any problem
during the operation, please refer to the Question & Answer (Q&A) section in Appendix.
2. RAID 0 mode
1). Place two new hard drives into iR8023.
We would strongly suggest you to use two identical hard drives to get the maximum memory
the memory capacity at the small capacity hard drive.
2). Under RAID 0 mode, the total memory capacity of iR8023 would be double from the small capacity
hard drive. And also, RAID 0 mode will perform an excellent efficiency from its high data
transfer rate for user to read & write data.
iR8023 User Manual
6
7. Hard Disk Status on LCD Screen
C)
3. Fan Failure
4. RAID 1 DegradedƝPrimary hard drive is failure, but secondary hard drive is normal.
RAID-1 degraded
5. RAID 1 FailureƝPrimary and secondary hard drives are failure.
RAID-1 failure
6. RAID 1 FailureƝDouble Source
RAID-1 failure
Double Source
7. RAID 0 FailureƝPrimary hard drive is missing, but secondary hard drive is normal.
RAID-0 failure
8. Rebuilding
Rebuilding
Sec ʿPri 32%
1. Booting and Normal status.
RAIDON RAIDbox2
RAID-1 vxxxxxx.x
iR8023 User Manual
7
The Hot Swappable hard drive and Auto Rebuilding features are available.
ƝWhen the data is stored in iR8023, user can remove one of the hard drives as
backup to protect the system from being hit by computer virus or to avoid the risk of having both hard
drives failing at the same time.
When one of the two hard drives fails in iR8023, it will issue an alert of a hard drive failure message
in both LCD display and the monitoring software. User can remove the failed hard drive from the
system while the system is still in operation without shutting down the machine. If the failed hard
drive is replaced shortly, the system will automatically execute the Auto Rebuilding function without
When the iR8023 detects one hard drive missing or failure, the Buzzer starts BEEPING and the LCD
displays the following messagesƝ
After few seconds from your inserting a new hard drive, LCD displays the data rebuilding progressƝ
When iR8023 completes its rebuilding, LCD again displays the following messagesƝ
8. Data Rebuilding Operation
RAID-1 degraded
Rebuilding
Sec ʿPri 32%
Rebuilding
Pri ʿSec 32%
iR8023 User Manual
8
Users can download the GUI software from the website to monitor the status of the product.
1. System Status:
This GUI automatically detects your iR8023 and reveals relative information accordingly.
2. Firmware Upfrade:
You may update the Firmware via this GUI, to just simply click on the “Load” button to locate the
澿
9. GUI Monitoring Software and Firmware Update
