RAID RAIDExpress 133 Manuel utilisateur

RAIDExpress 133 RAID
USER MANUAL
Preliminary Specification 0.3

Notice
Reasonable efforts have been made to ensure that the information in this
manual is accurate. We assume no liability for technical inaccuracies,
typographical, or other errors contain herein.
Backup your important data before using the IDE RAID product, and
use at your own risk. In no event shall we be liable for any loss of
profile, or for direct, indirect, special, incidental or consequential
damages arising from any defect or error in our products or manuals.

Contents
Introduction..............................................................................................................1
Features ...........................................................................................................2
What is the RAIDExpress 133 card..................................................................3
Quick Start................................................................................................................5
Unpack your RAIDExpress 133 Card package.................................................5
Install the RAIDExpress 133 Card....................................................................6
Create Your Disk Array .....................................................................................8
Setup Utility............................................................................................................14
Using the RAIDExpress 133 Card Setup Utility..............................................14
RAIDExpress 133 Card Setup Utility Main Menu............................................15
Auto Configuration..........................................................................................16
Define RAID....................................................................................................21
Delete RAID....................................................................................................27
Rebuild RAID..................................................................................................30
RAID Card Configuration................................................................................35
Driver Installation...................................................................................................37
Windows XP...................................................................................................38
Windows 2000................................................................................................44
Linux...............................................................................................................52
Application .............................................................................................................60
Installation ......................................................................................................60
Functions Description.....................................................................................63
How to Create Disk Array? .............................................................................75
Q&A.........................................................................................................................77
Technology Support ..............................................................................................78

RAIDExpress 133 RAID USER MANUAL
1
Introduction
This manual is mainly to help users setup the RAIDExpress 133 card and solve
problems when they use it.
If it is your first time to use the RAIDExpress 133 card and you are about to install it,
please refer to the “Quick Start” section on page 5. After finishing installing it, you
can get the advantages of enhancing the performance and raising the system’s
reliability.
When you face any difficulties and find anything you don’t understand while using the
RAIDExpress 133 card, please refer to the “Q&A” section on page 93. In this section,
you can refer to the problems users may face and find the correct solutions. You can
follow the instructions to solve your problems and then you will get satisfactory
results.
If there are still any questions you don’t understand, please refer to the “Technology
Support” section on page 94 to look for technical support.

RAIDExpress 133 RAID USER MANUAL
2
Features
Compatible with the ATA/ATAPI-6 specification and supports two IDE channels
with 4 drives.
Supports ANSI ATA proposal PIO modes 0,1,2,3,4 with flow control, DMA
Modes 0,1,2,3,4,5,6.
512 bytes FIFO for auto transfer per IDE channel to get a high performance
Supports the RAID 0/1/0+1 function.
Supports the JBOD function.
Supports the Scatter/Gather function for the DMA/UDMA function.
Includes one embedded CPU and firmware on the system to handle the RAID
function. It can reduce the driver’s loading of system CPU and improve the
system’s ability.
Supports Hot Swap function and doesn’t need any special HD removable box.
Low CPU utilization based on local processor architecture.
Compatible with PCI Local bus specification v2.2. Our systems can be easily
installed to PCs.
Supports PCI power Management v1.0 to reduce the power consumption.
Supports the drivers for Windows 98SE/ME, Windows NT 4.0, Windows
2000/XP and Linux v2.4.1.0.

RAIDExpress 133 RAID USER MANUAL
3
What is the RAIDExpress 133 card
This RAIDExpress 133 card is an excellent product resulting from Soc concept. It
includes one RAID Chip combining the CPU, firmware, advanced PCI controller and
IDE controller. Its architecture can provide users a RAID system with low CPU
utilization. When a PC is in the high CPU operation or PCI traffic, users won’t have
any penalties for installing the RAID system. This is because this system embeds a
local CPU to deal with the RAID function and it’s unnecessary to share CPU’s
performance. It is entirely different from the traditional software RAID system.
Similarly, it also provides users more system stability. It provides users high speed
and integration and a low price PC RAID system. Additionally, it also provides PCI
33MHz interface and is compatible with PCI spec. v2.2. It can be easily installed into
the PC system nowadays. Besides, we provide each OS a corresponding driver so
that users don’t have to worry that their systems and the IDE RAID system have any
compatibility issue.
This RAIDExpress 133 card can support IDE drivers ranging from the lowest speed of
PIO mode drive to the highest speed of ATA/133 drive. Thus, users can use this
characteristic to combine RAID system without any limitations. Users can use
ATA/133 drive and RAID function to achieve the best performance and get the merit
of system’s stability.
The RAIDExpress 133 card can support the RAID0 (striping), RAID1 (mirroring),
RAID0+1 (striping and mirroring) or JBOD (spanning) mode. When a system is
programmed to the RAID0 mode, it can read or write two drivers at the same time to
enhance the performance. When a system is programmed to the RAID1 mode, two
drivers have the same data and it will prevent data from being damaged. Once data
are damaged, the system will start the rebuild function automatically and save data
back to another new drive. Similarly, this system can use this data-copying

RAIDExpress 133 RAID USER MANUAL
4
characteristic to let two drivers transmit at the same time and balance the
performance to raise the throughput. The RAID0+1 mode uses four drivers to get the
merits of RAID0 and RAID1. As for the JBOD mode, it combines more than two
drives into a drive with a large capacity. This mode does not have the RAID function
and its merits.

RAIDExpress 133 RAID USER MANUAL
5
Quick Start
This section leads you to quickly establish your RAID system with default settings.
The default settings can meet most people’s requirements. If you need more
advanced optimal, please refer to Setup Utility on page 14 to achieve your goal.
Unpack your RAIDExpress 133 Card package
When you unpack your RAIDExpress 133 card package, you can see the following
items.
RAIDExpress 133 card.
RAIDExpress 133 manual.
RAIDExpress 133 card software CD.
Two 80-wire/40-pin Ultra ATA/133 hard drive cables.
I f you lack anything mentioned above, please contact your distributor to ask for
remedy.
Warning: In order to prevent any data loss resulting from
inappropriate operation, please backup data before you start to
install your system.
!

RAIDExpress 133 RAID USER MANUAL
6
Install the RAIDExpress 133 Card
This RAIDExpress 133 card meets the PCI v2.2 standard and can be easily installed
under 32-bit PCI slots of different PC systems. Please follow the following procedures
to install it.
1. Remove the case of the PC system.
2. Remove the inside slot cover of any available 32-bit PCI slot.
3. Install the RAIDExpress 133 card in this open slot.
4. Attach Ultra ATA/133 hard drives to the RAIDExpress 133 card.

RAIDExpress 133 RAID USER MANUAL
7
The hard drives which are required for the installation
The hard drives, which are connected on the RAIDExpress 133 card, can support
Ultra ATA/133, Ultra ATA/100, Ultra ATA/66, Ultra ATA/33, EIDE or Fast ATA-2 drives.
Nevertheless, for the best performance, it is suggested that you had better use the
hard drives of the same type and capacity to establish your own RAID system. After
getting ready for the hard drives, you can follow the procedures below to install the
system.
1. Exactly set up every hard drive’s master and slave setting to assure that the
hard drives can surely action and unnecessarily incorrect action of data access
won’t occur.
2. Exactly insert the hard drive’s cables into the connectors on the hard drive and
check if it’s really firmly inserted.
3. Insert every power cable connector into the corresponding hard drive and
check if it’s firmly inserted in a correct direction.
Warning: Because this system can support the hard drives of
Ultra ATA/133, it is suggested that you can use the 80-wire,
40-pin cable included in the package to connect the
RAIDExpress 133 card and hard drives in order to assure the
system’s ability and efficiency. If the cable is damaged after a period of time, it
is also suggested to buy the cable with the same specification.
!
