RADWAG AS R2 PLUS Guide de l'utilisateur

Start up Guide

Analytical balances:

• AS R2 PLUS

Precision balances:

• PS R1

• PS R1.M

• PS R2

• PS R2.M

• PS R2.H

• PS R2.M.H

Analytical

and Precision Balances

IMMB-03-02-11-21-EN

To view a complete User Manual go to the website or scan QR code:

radwag.com/en/manuals/198

1. CONTENT

AS R2 PLUS (d=0,01mg)

AS R2 PLUS (d=0,1mg)

Balance

×1

Balance

×1

Weighing pan

×1

Weighing pan

×1

Draft shield

×1

Draft shield

×1

Centring ring

×1

Bottom insert

×1

Bottom insert

×1

Power adapter*

×1

Power adapter*

×1

Models: PS R1 (d=1mg) |PS R2 (d=1mg)

Balance

×1

Weighing pan

×1

Draft shield

×1

Grounding foot

×1

Foot

×3

Power adapter*

×1

Power adapter*

×1

Models: PS R1.M |PS R2.M

Balance

×1

Weighing pan

×1

Draft shield

×1

*The plug type may vary by country.

fabric dust

cover

×1

Power adapter*

×1

Power adapter*

×1

Models: PS R2.H

Models: PS R2.M.H

Balance

×1

Balance

×1

Weighing pan

×1

Weighing pan

×1

Draft shield

×1

Draft shield

×1

*The plug type may vary by country.

2. UNPACKING

1 2 3

Keep the packaging should a

warranty claim or service be required.

TOP

3. RECOMMENDATIONS AND WARNINGS

+40 °C

+104°F

+10 °C

+50 °F

Operate the device in a room where the temperature ranges between 10–40 °C

(50–104 °F) and where the relative humidity is below 80%.

Place the balance on a solid surface to ensure stability. To obtain stable and

repeatable weighing results, an anti-vibration table is recommended.

Place the balance away from heat

sources. Avoid exposing the balance

to the sunlight.

Avoid air drafts and air movements

at the workstation.

Avoid exposing the balance to amag-

netic ﬁeld. Do not weigh magnetic

substances.

Make sure that the balance is placed

on an even surface.

Do not place the balance in a hazard-

ous area. Do not weigh explosive

materials.

Do not place the balance on an

unstable ground exposed to shocks

and vibrations.

4. ACTIVITIES TO BE DONE PRIOR TO OPERATION

Keep the transport

lock should a warranty

claim or service be

required.

Keep the transport

lock should a warranty

claim or service be

required.

4.1. Transport lock removal

4.2. Grounding spring check

Models: AS R2 Series

Models: PS R2 series | PS R1 series

1 2

Check whether the grounding

spring takes its intended

location.

Make sure that the grounding

spring juts slightly out of the

hole.

Check whether the grounding

spring takes its intended

location.

Make sure that the grounding

spring juts slightly out of the

hole.

Install the

grounding foot

in a freely

selected opening.

Models: AS R2 (d=0,1 mg)

Models: PS R1 (d=0,01 mg) |PS R2 (d=0,01 mg)

5. COMPONENTS ASSEMBLY

1 2 3 4

Models: AS R2 (d=0,01 mg)

Models: PS R1.M |PS R2.M

Models: PS R2.H

Models: PS R2.M.H

6. PREPARING FOR WORK

6.1. Temperature stabilization

6.2. Leveling

Prior to switching the device on, let it

reach room temperature (estimated

stabilisation time: 1-8 hours).

Connect the power adapter

to DC connector.

Connect the power

adapter to the mains.

USB 1 USB 2

1 2 3

6.3. Switch the balance on

To switch the device on, press ON / OFF key.

Your balance is ready to use!

To level the balance, turn its

feet and keep turning the feet

until an air bubble takes the

central position.

7. PANEL AND SCREEN

7.1. Panel keys

7.2. Home screen

Select working

mode Switching ON/OFF

Start adjustment Databases

Enter setup Working mode

functions

Taring Zeroing

PRINT/ENTER

Unit selection / ESC

Navigation keys

Measurement result

Stable indication

pictogram

Pictogram of active

working mode

Messages

and information

Zeroing pictogram
