OWNER’S MANUAL

Please read before using this equipment.

BTX-128

CTCSS•VHF

Business Band Transceiver

19-1217.fm Page 1 Tuesday, August 3, 1999 1:18 PM

Features

Your RadioShack BTX-128 CTC-

SS•VHF Business Band Trans-

ceiver is a portable, two-way

business radio service transceiver

that you can carry almost any-

where. The transceiver is com-

pact and light, making it an ideal

choice for your business needs.

Your transceiver has these fea-

tures:

38-Tone CTCSS (Continuous

Tone Control Squelch System) —

helps reduce interference from

other transceivers which are oper-

ating on the same frequency and

in the same area.

Built-in VOX — allows hands-free

operation of your transceiver us-

ing an optional headset and mi-

crophone.

Programmable Frequencies —

you can program the transceiver

to any VHF business band fre-

quency you have a license to use

— no crystals to buy!

Rechargeable Battery Pack and

Battery Charger — the supplied

battery charger lets you conve-

niently recharge your transceiv-

er’s battery pack while it is on the

transceiver.

Earphone/Speaker and External

Microphone Jacks — let you con-

nect an external earphone or

speaker and an external micro-

phone for clearer communica-

tions in noisy areas.

Battery Low Indication — the

transceiver beeps when the bat-

tery pack is low.

Flexible Antenna — provides ex-

cellent reception.

Belt Clip — lets you attach the

transceiver to your belt or waist-

band.

19-1217.fm Page 2 Tuesday, August 3, 1999 1:18 PM

The transceiver’s preset frequen-

cies are:

• 151.625 MHz (red dot)

• 151.700 MHz

• 151.760 MHz

• 151.820 MHz

• 151.880 MHz

• 151.940 MHz

• 151.955 MHz (purple dot)

• 154.570 MHz (blue dot)

• 154.600 MHz (green dot)

Note: Some manufacturers identi-

fy some business band frequen-

cies by color. These “dot”

frequencies are shown above.

We recommend you record your

transceiver’s serial number here.

The number is on the back of the

transceiver.

Serial Number ____________

This symbol is intend-

ed to alert you to the

presence of uninsulat-

ed dangerous voltage

within the product’s

enclosure that might

be of sufficient magni-

tude to constitute a

risk of electric shock.

Do not open the prod-

uct’s case.

This symbol is intend-

ed to inform you that

important operating

and maintenance in-

structions are included

in the literature accom-

panying this product.

CAUTION

RISK OF ELEC-

TRIC SHOCK.

DO NOT OPEN.

CAUTION: TO REDUCE THE

RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER

OR BACK. NO USER-SER-

VICEABLE PARTS INSIDE.

REFER SERVICING TO

QUALIFIED PERSONNEL.

WARNING: To reduce the risk

of fire or shock hazard, do not

expose this product to rain or

moisture.

19-1217.fm Page 3 Tuesday, August 3, 1999 1:18 PM

CONTENTS

FCC Regulations ................................................................................. 5

FCC License Required .................................................................. 5

FCC Part 90 Rules ........................................................................ 5

Additional FCC Regulations .......................................................... 7

Exposure to Radio Frequency Energy .......................................... 7

Electromagnetic Interference/Compatibility ................................... 8

Potentially Explosive Atmospheres ............................................... 9

Blasting Caps and Areas ............................................................... 9

For Vehicles With an Air Bag ........................................................ 9

Antennas ..................................................................................... 10

Batteries ...................................................................................... 10

Chargers and Power Cord .......................................................... 10

Preparation ........................................................................................ 12

Installing the Battery Pack ........................................................... 12

Charging the Battery Pack .......................................................... 13

Connecting the Antenna .............................................................. 14

Using the Belt Clip ....................................................................... 15

Using an External Speaker/Microphone ...................................... 15

Listening Safely ................................................................... 16

Traffic Safety ....................................................................... 16

Setting Frequency Options ................................................................ 17

About CTCSS ............................................................................. 17

Selecting a Business Band Frequency ...................................... 18

Using a CTCSS Frequency ........................................................ 18

Operation ........................................................................................... 20

Operational Hints ....................................................................... 20

Care and Maintenance ...................................................................... 21

Specifications .................................................................................... 22

19-1217.fm Page 4 Tuesday, August 3, 1999 1:18 PM

FCC Regulations

FCC License Required

This transceiver is intended for

use in the operation of commer-

cial activities, educational, philan-

thropic, or ecclesiastical

institutions, and hospitals, clinics,

or medical associations.

The Federal Communications

Commission (FCC) requires you

to have a license before you oper-

ate this transceiver. Unless you

are already licensed to operate on

one of the preset frequencies, you

must apply for a frequency

through the PCIA (Personal Com-

munication Industry Association),

a non-profit organization that as-

signs frequencies nationwide to

help prevent conflicts between dif-

ferent businesses using transceiv-

ers in the same area. For more

information about getting a li-

cense, contact the PCIA at 800-

759-0300, extension 3068 (in Vir-

ginia 703-739-0300, extension

3068).

For other questions concerning

the license application, contact

the FCC at 717-337-1212, or

write:

FCC

P.O. Box 1040

Gettysburg, PA 17325

For the latest FCC application

form and instructions, call the

FCC’s fax-on-demand service at

1-202-418-0177 from a fax ma-

chine and request one or more of

the following documents:

• To receive all forms and

instructions, enter 000600

• To receive Form 600 instruc-

tions only, enter 006001

• To receive Main Form 600

only, enter 006002

• To receive Form 600 sched-

ules only, enter 006003

If you do not have a fax machine,

you can call the Government

Forms Distribution Center at 1-

800-418-FORM and request that

the form and instructions be

mailed to you.

FCC Part 90 Rules

You must be familiar with Part 90

of FCC Rules before you operate

your transceiver. The operation

instructions in this manual con-

form to Part 90, but do not cover

all items in Part 90.

19-1217.fm Page 5 Tuesday, August 3, 1999 1:18 PM

Overall, Part 90 states that:

• You must have a valid license

before you use the trans-

ceiver.

• As licensee, you are respon-

sible for proper operation of

all transceivers operating

under your license authority.

• You can let unlicensed per-

sons operate this transmitter,

as long as you take precau-

tions to prevent unauthorized

transmissions.

• You must use this transceiver

only for the commercial use

of your business, and only

when other commercial chan-

nels (such as the telephone)

are either not available or not

practical.

• You must always yield the

operating frequency to com-

munications that involve the

safety of life or property.

• You must take reasonable

precautions to prevent harm-

ful interference to other ser-

vices operating on the same

frequency.

• You must not transmit pro-

gram material of any kind

used in connection with com-

mercial broadcasting.

• You must not provide a ser-

vice that is normally handled

by telephone or telegraph

unless such broadcasts

involve the safety of life or

property or in emergencies

such as an earthquake, hur-

ricane, flood or a similar

disaster where normal com-

munication channels are dis-

rupted.

• During each transmission or

exchange of transmissions,

you must identify your sta-

tion with the call sign issued

to you by the FCC, or once

each 15 minutes during peri-

ods of continuous operation.

• You must keep a written

record of any maintenance

or modification made to the

transceiver, and you must

make this record available

for inspection upon demand

by the FCC.

Violating any of the provisions of

Part 90 can result in fines and/or

confiscation of equipment.

19-1217.fm Page 6 Tuesday, August 3, 1999 1:18 PM

Your transceiver might cause TV

or radio interference even when it

is operating properly. To deter-

mine whether your transceiver is

causing the interference, turn off

your transceiver. If the interfer-

ence goes away, your transceiver

is causing it. Try to eliminate the

interference by:

• moving your transceiver

away from the receiver

• contacting your local

RadioShack store for help

If you cannot eliminate the inter-

ference, the FCC requires that

you stop using your transceiver.

Additional FCC Regulations

The Business Radio Service is

under the jurisdiction of the

(FCC). Any adjustments or alter-

ations that would alter the perfor-

mance of the transceiver so it no

longer meets the original FCC

type acceptance or would change

the frequency-determining meth-

od are strictly prohibited.

Replacement or substitution of

crystals, transistors, ICs, regulator

diodes, or any other component

that is of a unique nature with

components other than those rec-

ommended can violate the techni-

cal regulations of the FCC rules or

violate type acceptance require-

ments of the rules.

Before you operate the transceiv-

er, you must obtain your license. It

is illegal to transmit without the

appropriate license, which you

can get by submitting a complet-

ed FCC Form 600 to the FCC (or

through the PCIA). Furthermore,

you are required to understand

Part 90 of the FCC Rules and

Regulations prior to operating

your transceiver. It is the user’s

responsibility to see that this unit

is operating at all times in accor-

dance with the FCC Rules and

Regulations.

Exposure to Radio Frequency

Energy

The design of your radio, which

generates radio frequency (RF)

electromagnetic energy, complies

with the following national and in-

ternational standards and guide-

lines:

19-1217.fm Page 7 Tuesday, August 3, 1999 1:18 PM

• FCC Report and Order FCC

96-326 (August 1996)

• American National Stan-

dards Institute (C95-1-1992)

• National Council on Radia-

tion Protection and Measure-

ments (NCRP-1986)

• International Commission on

Non-Ionizing Radiation Pro-

tection (ICNRP-1866)

• CENELEC

— Env. 50166-1 1995E - Hu-

man Exposure to Electromag-

netic Fields Low Frequency

(0 Hz to 10 KHz)

— Env. 50166-2 1995E - Hu-

man Exposure to Electromag-

netic Fields High Frequency

(10 KHz to 300 GHz)

— Proceedings of SC211/8

1996 - Safety Considerations

for Human Exposure to EMEs

from Mobile Telecommunica-

tions Equipment (MTE) in the

Frequency Range 30 MHz–6

GHz (EME - Electromagnetic

Fields)

To assure optimal radio perfor-

mance and to ensure that expo-

sure to RF energy is within the

guidelines in these standards, the

following operating procedures

should be observed:

For hand-held operation: The ra-

dio should be held in a vertical

position with the microphone one

to two inches away from the

mouth, and the antenna should

be kept one to two inches from

the head or body when transmit-

ting.

For body-worn operation: The an-

tenna should be kept at least one

inch from the body when trans-

mitting.

ElectromagneticInterference/

Compatibility

Nearly every electronic device is

susceptible to electromagnetic in-

terference (EMI) if inadequately

shielded, de-signed, or other-

wise configured for electromag-

netic compatibility.

Turn your radio off in any facilities

where posted notices instruct you

to do so. Hospitals or health care

facilities

19-1217.fm Page 8 Tuesday, August 3, 1999 1:18 PM

may be using equipment that is

sensitive to external RF energy.

Turn your radio off when on board

aircraft when instructed to do so.

Any use of the radio must be in

accordance with airline regula-

tions or crew instructions.

WARNING

Potentially Explosive

Atmospheres

Turn your radio off when in any

area with a potentially explosive

atmosphere, unless it is a type es-

pecially qualified for such use (for

example, FMRC Approved).

Sparks in such areas could cause

an explosion or fire resulting in

bodily injury or even death.

Do not replace or charge batteries

in a hazardous atmosphere. Con-

tact sparking may occur while in-

stalling or removing batteries and

cause an explosion.

Areas with potentially explosive

atmospheres are often, but not al-

ways, clearly marked. They in-

clude fueling areas such as below

deck on boats, fuel or chemical

transfer or storage facilities, areas

where the air contains chemicals

or particles such as grain, dust, or

metal powders, and any other

area where you would normally

be advised to turn off your vehi-

cle’s engine.

Blasting Caps and Areas

To avoid possible interference

with blasting operations, turn

your radio off near electrical

blasting caps or in a ‘blasting ar-

ea’ or in areas posted “Turn Off

Two-Way Radio.” Obey all signs

and instructions.

For Vehicles With an Air Bag

An air bag inflates with great

force. Do not place objects, in-

cluding portable or mobile two-

way radios, in the area over the

air bag or in the air bag deploy-

ment area. If improperly installed

or placed wireless equipment is

in the air bag deployment area

and the air bag inflates, serious

injury could result.

19-1217.fm Page 9 Tuesday, August 3, 1999 1:18 PM

Antennas

Do not use a radio with a dam-

aged antenna. If a damaged an-

tenna comes into contact with the

skin, a minor burn might result.

Batteries

All batteries can cause property

damage, injury, or burns if a con-

ductive material such as jewelry,

keys, or a beaded chain touches

exposed terminals. The material

may complete an electrical circuit

(short circuit) and become quite

hot. Exercise care in handling any

charged battery, particularly when

placing it inside a pocket, purse,

or other container with metal ob-

jects.

CAUTION

Chargers and Power Cord

To reduce risk of damage to the

supplied battery charger when

disconnecting it from AC power,

pull by the plug rather than the

power cord.

Make sure the power cord is lo-

cated so that it will not be stepped

on, tripped over, or otherwise sub-

jected to damage or stress.

Do not operate the charger with a

damaged cord or plug; replace

them immediately. Do not operate

the charger if it has received a

sharp blow, been dropped, or oth-

erwise damaged in any way; con-

tact your local RadioShack store.

Do not expose chargers to rain or

snow.

An extension cord should not be

used unless absolutely neces-

sary. Use of an improper exten-

sion cord may result in a fire or

electric shock. However, if an ex-

tension cord is used, make sure

that:

• The pins and plug of the

extension cord are the same

number, size, and shape as

those on the plug of the

charger.

• The extension cord is prop-

erly wired and in good condi-

tion.

• The cord size is 18 AWG for

lengths of up to 100 feet,

and 15 AWG for lengths up

to 150 feet.

19-1217.fm Page 10 Tuesday, August 3, 1999 1:18 PM

Autres manuels pour BTX-128

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Radio Shack Émetteur-récepteur

Radio Shack

Radio Shack HTX-202 Manuel utilisateur

Radio Shack

Radio Shack HTX-202 Manuel utilisateur

Radio Shack

Radio Shack BTX-124 Manuel utilisateur

Radio Shack

Radio Shack HTX-245 Manuel utilisateur

Radio Shack

Radio Shack HTX-252 Manuel utilisateur

Radio Shack

Radio Shack TRC-485 Manuel utilisateur

Radio Shack

Radio Shack HTX-10 Manuel utilisateur

Radio Shack

Radio Shack BTX-123 Manuel utilisateur

Radio Shack

Radio Shack MTX-103 Manuel utilisateur

Radio Shack

Radio Shack HTX-10 Manuel utilisateur

Radio Shack

Radio Shack HTX-202 Manuel utilisateur

Radio Shack

Radio Shack PRO-74 20-513 Manuel utilisateur

Radio Shack

Radio Shack TRC-510 Manuel utilisateur

Radio Shack

Radio Shack HTX-420 Manuel utilisateur

Radio Shack

Radio Shack 19-902 Manuel utilisateur

Radio Shack

Radio Shack PRS-102 UHF 19-902 Manuel utilisateur

Radio Shack

Radio Shack BTX-127 Manuel utilisateur

Radio Shack

Radio Shack HTX-242 Manuel utilisateur

Radio Shack

Radio Shack HTX-242 Manuel utilisateur

Radio Shack

Radio Shack HTX-404 Manuel utilisateur

Radio Shack

Radio Shack TRC-485 Manuel utilisateur

Radio Shack

Radio Shack BTX-128 Manuel utilisateur

Radio Shack

Radio Shack TRC-495 Manuel utilisateur

Radio Shack

Radio Shack HTX-400 Manuel utilisateur

Manuels Émetteur-récepteur populaires d'autres marques

Yaesu

Yaesu FT-7B Manuel utilisateur

Kenwood

Kenwood ProTalk TK-3201 Manuel utilisateur

Texas Instruments

Texas Instruments TLK10232 Manuel utilisateur

Mizuho

Mizuho MX-2 Guide produit

Kenwood

Kenwood TK-3180 Manuel d'utilisation et d'entretien

Blitz

Blitz MJ-398U Manuel utilisateur

Utilicom

Utilicom LongRanger 2050 Manuel utilisateur

Standart

Standart HX290UKA Manuel utilisateur

Altronix

Altronix Pace1PTM Manuel utilisateur

Kirisun

Kirisun PT2208 Manuel utilisateur

ELECRAFT

ELECRAFT KX2 Manuel utilisateur

Zodiac

Zodiac K3 Manuel utilisateur

Assa Abloy

Assa Abloy SecureComm HKC GSM-WIFI U Manuel utilisateur

Kenwood

Kenwood TK-2217 Manuel utilisateur

Siemens

Siemens PSO 4000 Manuel utilisateur

Kenwood

Kenwood TS-590SG Manuel utilisateur

Midland

Midland G8E-BT Manuel

ComNav

ComNav Mariner X2 Manuel utilisateur
