Please read this user’s guide before
installing, setting up and using your new product
www.radioshack.com
truck transmitter antenna tube wheels (4)
mattracks (4) box wrench plastic washer (1)
what’s included
in the truck
You will need a 7.2V rechargeable battery
pack and a battery charger (neither supplied)
to power your truck.
1. Remove the battery
compartment cover.
2. Insert the battery pack
with it’s connector on
the same side as the
truck’s connector.
3. Attach the battery
pack and truck
connectors. They fit
together only one way. Do
not force them.
4. Replace the cover.
in the transmitter
1. Remove the battery
compartment cover.
2. Place one 9V battery in the
compartment.
3. Replace the cover and snap
it shut.
installing batteries
60-4386
Ford F-350
Featuring Mattracks
1. Route the antenna wire’s loose end through
the supplied antenna tube.
2. Insert the antenna tube securely into the
hole at the top of the vehicle.
attaching the antenna
Your Ford F-350 Featuring Mattracks is the
fastest vehicle on the road! Drive it off-road,
too. It has excellent climbing ability for steep
hills, smooth handling on rough terrain, and
headlights for driving at night. Switch out the
tires or mattracks, depending on your driving
conditions at any time.
transmitter
wheels
mattracks
box wrench
• Use only fresh batteries of the required size and
recommended type.
• Do not mix old and new batteries, or different types
of batteries.
• If you do not plan to use your truck for a week
or more, remove the batteries. Batteries can leak
chemicals that may destroy electronic parts.
• Be sure the battery pack’s connectors and wires do
not touch any of truck’s moving parts.
• After charging the battery pack, disconnect it from
the charger. Overcharging could damage it.
• When you disconnect the battery pack from the
charger, do not pull on the connector’s wires. You
might damage the battery pack.
• Dispose of batteries promptly and properly. Do not
burn or bury them.
• Driving your truck for long periods of time generates
heat, and causes wear and tear on the motor. To
keep heat levels down, let your truck cool for 10
minutes before installing a new battery pack.
• To drive for extended periods, buy an extra battery
pack, and charge it while using the other one.
• If the truck moves slowly or not at all, and you
have installed a fresh battery pack, check the wheel
mechanisms for lint, hair, dust or thread.
Important: The EPA certified RBRC® Battery Recycling Seal on the nickel-cadmium (Ni-Cd) battery
indicates RadioShack is voluntarily participating in an industry program to collect and recycle these
batteries at the end of their useful life, when taken out of service in the United States or Canada.
The RBRC program provides a convenient alternative to placing used Ni-Cd batteries into the trash
or the municipal waste stream, which may be illegal in your area. Please call 1-800-THE-SHACK (1-
800-843-7422) for information on Ni-Cd battery recycling and disposal bans/restrictions in your area.
RadioShack’s involvement in this program is part of the company’s commitment to preserving our
environment and conserving our natural resources.
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Consult your local RadioShack store or an experienced radio/
TV technician for help.
• If you cannot eliminate the interference, the FCC requires that
you stop using your truck.
Changes or modifications not expressly approved by
RadioShack may cause interference and void the user’s
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
©2004. RadioShack Corporation.
All rights reserved. RadioShack and
RadioShack.com are trademarks
used by RadioShack Corporation.
60-4386
06A04
Printed in China
The FCC Wants You to Know
This product is warranted by RadioShack against manufacturing defects in
material and workmanship under normal use for ninety (90) days from the date
of purchase from RadioShack company-owned stores and authorized RadioShack
franchisees and dealers. For complete warranty details and exclusions, check
with your local RadioShack store.
RadioShack Customer Relations
200 Taylor Street, 6th Floor, Fort Worth, TX 76102
04/04
limited 90-day warranty
• Your truck comes in three frequencies so you and
your friends can play together. If you race other
cars, set your truck and transmitter to a different
frequency than your friend’s.
• If someone uses a CB nearby, it might interfere
with control of your Mattrack. If this happens,
move your Mattrack away from the CB.
hints
Use the supplied box wrench to remove and
replace the mattracks and wheels. When
driving on wheels, use the supplied plastic
washer and wrench to apply the wheels to the
truck.
1. Extend the transmitter’s antenna.
2. Turn on your transmitter and truck. The
headlights and taillights illuminate.
3. Pick a frequency by setting BAND ABC on
the transmitter and the truck to the same
setting.
driving
Do not touch the tires or the steering control
during adjustment.
1. Turn the truck on its side so its tires do not
touch the ground.
2. Turn on the transmitter and truck. If the tires
move, turn Trim I until the tires stop.
3. If the front tires look angled to the left
or right, adjust Trim II until the tires look
straight.
Trim I — adjust so the truck stops completely
when you release the trigger. If Trim I is set
too far right, your truck may continue to drive
forward after you release the trigger.
Trim II — adjust your alignment to drive in a
straight line. If set too far to the left or right, the
truck may veer left or right while driving.
If the truck does not drive in a straight line,
adjust the wheel alignment. If it pulls to the
right, slide the control toward L. If it pulls to the
left, slide the control toward R.
trim adjustment
Use the steering wheel to
steer the truck left and right.
Release it to drive straight.
BAND ABC
Trim I
Trim II
Pull the trigger towards
the handle to drive
forward.
Push the trigger away
from the handle to
drive backward.
Release to stop.
