QUANTACHROME INSTRUMENTS MULTIPYCNOMETER Manuel utilisateur

MULTIPYCNOMETER

QUALITY ASSURANCE

AND

SERVICE

MANUAL

REVISION: K

MANUAL NUMBER: 05300-114

DATE OF LATEST REVISION: 03/24/14

ISSUE DATE: 7/18/16

TABLE OF CONTENTS

MULTIPYCNOMETER ................................................................................................ 1

1.0.

PURPOSE ....................................................................................................... 3

2.0.

SCOPE............................................................................................................ 3

3.0.

DEFINITIONS ................................................................................................. 3

4.0.

RESPONSIBILITIES ....................................................................................... 4

5.0.

REQUIREMENTS ........................................................................................... 5

5.1.

ELECTRICAL AND MECHANICAL INSPECTION ......................................... 5

5.2.

POWER CHECKS .......................................................................................... 7

5.3.

ALIGNMENTS ............................................................................................... 8

5.4.

LEAK TEST .................................................................................................. 12

5.5.

CALIBRATION .............................................................................................. 16

6.0.

REFERENCES .............................................................................................. 26

APPENDIX A ............................................................................................................ 27

APPENDIX B ........................................................................................................... 28

APPENDIX B ........................................................................................................... 29

B.2. INSTRUMENT CALIBRATION SHEET FOR THE LARGE CELL .................... 29

B.3. INSTRUMENT CALIBRATION SHEET FOR THE SMALL CELL..................... 30

B.4. INSTRUMENT CALIBRATION SHEET FOR THE MICRO CELL ..................... 32

APPENDIX C ........................................................................................................... 34

C.1 SPHERE RUNS’ DATA SHEETS ...................................................................... 34

APPENDIX D ............................................................................................................ 35

D.1.

SPARE PARTS LIST .................................................................................... 35

D.2.

ACCESSORY LIST ...................................................................................... 36

1.0. PURPOSE

1.1.

THE REQUIREMENTS SPECIFIED HEREIN ARE INTENDED TO ASSURE

THAT MULTIPYCNOMETERS WITH MODEL NUMBER MVP-3 MEET OR

EXCEED THE REQUIRED MANUFACTURING AND QUALITY ASSURANCE

STANDARDS AS SPECIFIED IN THE COMPANY QUALITY MANUAL.

2.0. SCOPE

2.1. THIS PROCEDURE IS TO BE FOLLOWED BY ALL QUALITY

ASSURANCE PERSONNEL INVOLVED WITH MULTIPYCNOMETER TEST AND

CALIBRATION PROCEDURES.

2.2. THIS PROCEDURE CONTAINS CALIBRATION GUIDELINES THAT CAN

ALSO BE FOLLOWED BY QUALIFIED TECHNICIANS, INCLUDING

QUANTACHROME CUSTOMERS, AGENTS AND SALES PEOPLE.

2.3. THESE REQUIREMENTS APPLY TO OTHER MULTIPYCNOMETER MODELS WITH

MODIFICATIONS OUTLINED IN APPENDIX A.

3.0. DEFINITIONS

3.1. MULTIPYCNOMETER: APPARATUS DESIGNED TO MEASURE TRUE

SOLID VOLUMES BY A GAS EXPANSION TECHNIQUE KNOWN AS HELIUM

PYCNOMETRY [ 1 , 2 ].

3.2. QUALITY ASSURANCE: FULL COMPLIANCE WITH PROCEDURES AND

STANDARDS ITEMIZED IN THE COMPANY QUALITY MANUAL.

3.3. SERVICE: GUIDELINES PROVIDED TO ENABLE SERVICE

TECHNICIANS TO HANDLE INSTRUMENT TROUBLESHOOTING.

3.4. MVP - i : MULTIPLE VOLUME PYCNOMETER, MODEL -i .

3.5. VR : KNOWN MANIFOLD REFERENCE VOLUME IN CC’S [ 2 ].

3.6. VC : CELL VOLUME IN CC’S.

3.7. VP: SPHERE OR SAMPLE VOLUME IN CC’S.

3.8. PRESSURE: ALL PRESSURE READINGS ARE DISPLAYED ON THE

DIGITAL PANEL METER AND ARE GIVEN IN PSIG (POUNDS PER SQUARE

INCH GAUGE PRESSURE).

3.9. SPHERES: STAINLESS STEEL BALLS OF VARIOUS SIZES ARE USED FOR

VOLUME CALIBRATIONS. ALL SPHERE VOLUMES ARE GIVEN IN CUBIC

CENTIMETERS (CC`S).

3.10. TOGGLE VALVE: TOGGLE VALVES ARE ON / OFF VALVES LABELED I, II,

GAS IN AND GAS OUT ON THE INSTRUMENT PANEL FACE. VALVES ARE

CLOSED WHEN THEIR HANDLES ARE PARALLEL TO THE CABINET FACE AND

OPEN WHEN PERPENDICULAR TO THE CABINET FACE.

3.11. NEEDLE VALVE: TWO ADJUSTABLE NEEDLE VALVES PERMIT FLOW

RATE CONTROL THROUGH GAS IN AND GAS OUT. TURNING THEIR KNOB

CLOCKWISE REDUCES THEIR RESPECTIVE FLOW RATES.

3.12. CORCOM: FUSED ELECTRICAL RECEPTACLE USED TO CONFIGURE THE

INPUT POWER FOR 100,120, 220, OR 240VAC. THE RECEPTACLE IS LOCATED ON

THE INSTRUMENT’S BACK PANEL.

3.13. SELECTOR VALVE: TWO - POSITION BALL VALVE LOCATED ON THE

MULTIPYCNOMETER’S CABINET FACE FOR SWITCHING BETWEEN POSITIONS

LABELED CELL AND REFERENCE.

4.0. RESPONSIBILITIES

4.1.

THE FOLLOWING PROCEDURE SHALL BE PERFORMED ONLY BY

INDIVIDUALS TRAINED AS ELECTRICAL AND MECHANICAL TECHNICIANS.

4.2. QUANTACHROME TECHNICIANS SHALL BE FULLY TRAINED ON

ELECTRICAL PROCEDURES, MECHANICAL ASSEMBLY, AND GAS HANDLING

OPERATIONS AS OUTLINED IN THE COMPANY QUALITY MANUAL.

4.3. TECHNICIANS WILL HAVE AVAILABLE THE FOLLOWING

EQUIPMENT REQUIRED FOR TESTING.

4.3.1. CALIBRATED 4 1/2 DIGITAL VOLTMETER WITH OHMS, AC-

250VAC AND DC 24VDC.

4.3.2. ULTRA HIGH PURITY (99.999%) HELIUM WITH A TWO STAGE

REGULATOR SET TO DELIVER AT LEAST 25 PSIG OF PRESSURE.

4.3.3. 5/16 HEX ALLEN WRENCH.

4.3.4. STANDARD HAND TOOLS.

4.3.5. JEWELER’S SCREWDRIVER.

4.3.6. CALIBRATED PRESSURE GAUGE TO READ 25 +/- 0.25 PSIG.

4.3.7. BEAKER HALF FULL OF WATER.

4.3.8. TORQUE SEAL.

4.4. THE QUALITY ASSURANCE MANAGER WILL CONFIRM THAT

QUANTACHROME TECHNICIANS FOLLOW ALL PROCEDURES IN

COMPLIANCE WITH THE GUIDELINES STATED IN THE COMPANY QUALITY

MANUAL.

4.5. THE PRODUCT MANAGER WILL EVALUATE ALL REVISIONS TO THIS

DOCUMENT TO ENSURE COMPLIANCE WITH ENGINEERING DESIGN

REQUIREMENTS.

5.0. REQUIREMENTS

5.1. ELECTRICAL AND MECHANICAL INSPECTION

5.1.1 ELECTRICAL

5.1.1.1 WIRING - VERIFY THAT ALL WIRING CONTINUITY CONFORMS TO THE

LATEST REVISION DRAWING

5.1.1.2. VISUALLY INSPECT THE DIGITAL PANEL METER CONNECTOR FOR

CORRECT WIRING AND ALL SOLDERING FOR COLD JOINTS.

5.1.1.3. VERIFY THAT TWO 2 AMP FUSES ARE INSTALLED IN THE CORCOM.

REMOVE THE FUSE BY SLIDING THE BLACK HANDLE IN THE CORCOM TO THE

LEFT. REINSTALL THE FUSES IF THE AMPERAGE IS CORRECT.

5.1.1.4. RECONFIGURE THE CORCOM TO MATCH THE VOLTGE REQUIRED FOR

THE CUSTOMER ORDER (FUSED ELECTRICAL RECEPTACLE) FOR 120 VAC.

PUSH THE PLASTIC SHIELD TO THE LEFT,

5.1.1.5.

THE NEW CORCOM HAS A BARREL TYPE VOLTAGE ADJUSTMENT. DO

NOT SPIN THE BARREL OR YOU MAY DAMAGE THE CONTACTS. PULL OUT THE

BARREL AND ROTATE THE BARREL TO THE SPECIFIED CUSTOMER VOLTAGE

REQUIREMENT.

5.1.2. MECHANICAL

5.1.2.1. VERIFY THAT ALL FRONT PANEL KNOBS ROTATE FREELY AND

THAT THE ZERO KNOB HAS A NYLON WASHER PLACED BEHIND IT.

5.1.2.2. VERIFY THAT THE SAMPLE CELL HOLDER COVER AND ITS RECEPTOR

IN THE INSTRUMENT’S COVER PANEL HAVE CLEARLY VISIBLE WHITE

ALIGNMENT LINES (FIDUCIARY MARKS). ALSO VERIFY THAT THE COVER

SCREWS FREELY ONTO THE RECEPTOR, AND THAT WHEN FULLY TIGHTENED

IT IS NOT IN CONTACT WITH THE BLACK BULKHEAD RETAINER.

5.1.2.3. REMOVE THE 2-INCH O-RING (PART NUMBER 51000-032) FROM

UNDER THE SAMPLE CELL HOLDER COVER. CLEAN THE COVER AND THE

BRASS CELL HOLDER SEAT. APPLY A VERY LIGHT COAT OF VACUUM

GREASE TO THE O-RING AND REINSTALL IT IN THE CELL COVER.

5.1.2.4. INSPECT THE SAMPLE CELL HOLDER TO MAKE SURE THAT IT HAS NO

SCRATCHES AND VERIFY THAT THE GAS INLET GROOVE IS CLEAN, FREE OF

DIRT AND THAT ITS FLOW PATH IS UNRESTRICTED.

5.1.2.5 VERIFY THAT ALL FITTINGS ARE SET ON TIGHTLY AND THAT ALL

SOLDER JOINTS ARE CLEAN, NOT COLD AND HAVE SHRINKABLE CLEAR

TUBING OVER THEM.

5.1.2.6. VERIFY THAT TWO PLASTIC TIES ARE WRAPPED AROUND BOTH THE

BIMBA BRAND AIR CHAMBER AND THE BRASS CELL HOLDER IN ORDER TO TIE

BOTH TOGETHER.

5.1.2.7. CLEAN ALL SPHERES, SAMPLE CELL CUPS AND SLEEVES WITH

ISOPROPYL AND A LINT-FREE TISSUE.

5.1.2.8. VERIFY THAT ALL THE SAMPLE CELL CUPS FIT SNUGLY INTO THEIR

SLEEVES AND THAT ALL SLEEVES FIT INTO THE BRASS SAMPLE CELL

HOLDER.

5.2. POWER CHECKS

5.2.1. AC CHECKS

5.2.1.1. CAUTION -THESE CHECKS MUST BE PERFORMED WITH THE POWER

SWITCH TURNED OFF AND WITH THE POWER CORD UNPLUGGED. THESE

INSTRUCTIONS SHOULD ONLY BE PERFORMED BY TRAINED PERSONNEL AND

THEN ONLY AFTER TAKING ALL PERTINENT SAFETY PRECAUTIONS.

5.2.1.2. SET THE POWER SWITCH TO THE OFF POSITION AND CONFIGURE THE

CORCOM FOR 120 VAC OR TO THE SPECIFIED CUSTOMER VOLTAGE

REQUIREMENT. THE CORCOM CARD IS LOCATED BEHIND THE CLEAR PLASTIC

SLIDE DOOR NEXT TO THE POWER SOCKET. TO CHANGE THE VOLTAGE

SETTINGS, SLIDE THE DOOR AND REMOVE THE CARD USING PLIERS. HOLD

THE CARD SO THAT THE VOLTAGE YOU ARE CONFIGURING THE UNIT FOR

FACES YOU, AND SLIDE THE CARD BACK IN THE SLOT.

5.2.1.3. USING AN OHM METER, TEST FOR CONTINUITY ACROSS THE LINE

INPUT TERMINALS. THE READING SHOULD BE INFINITY (OPEN CIRCUIT).

5.2.1.4. USING AN OHM METER, TEST FOR CONTINUITY BETWEEN THE INPUT

LINE TERMINALS AND THE CHASSIS GROUND. THE READING SHOULD BE

INFINITY (OPEN CIRCUIT).

5.2.1.5. USING AN OHM METER, TEST FOR CONTINUITY BETWEEN THE INPUT

GROUND TERMINALS AND THE CHASSIS GROUND. VERIFY A READING OF

CONTINUITY INDICATING A SHORT CIRCUIT.

5.2.1.6. SET THE POWER SWITCH TO ON. USING AN OHM METER, TEST ACROSS

THE LINE INPUT TERMINALS. THE READING SHOULD BE AROUND 17 OHMS. IF

A SHORT IS READ THE SWITCH MAY BE WIRED INCORRECTLY.

THE READING SHOULD BE AROUND 68 OHMS IF THE VOLTAGE IS 220V-240V.

5.3.2.2. DC POWER -ON CHECKS

5.2.2.1. REMOVE THE PRESSURE TRANSDUCER CONNECTOR FROM THE SMALL

PRINTED CIRCUIT BOARD (PART NUMBER 00003) LOCATED INSIDE ON THE

LEFT BULKHEAD.

5.2.2.2. CONNECT THE INSTRUMENT TO THE 120 VAC SUPPLY OUTLET (OR TO

THE CUSTOMER REQUIRED VOLTAGE) AND TURN THE POWER SWITCH TO THE

“ON” POSITION.

5.2.2.3. USING A CALIBRATED DIGITAL VOLT METER, CHECK AND ADJUST THE

POWER SUPPLY FOR DC OUTPUT VOLTAGE SUPPLIED TO THE CIRCUIT CARD.

THE READINGS ARE TAKEN AT THE POWER SUPPLY TERMINALS AND ARE

REFERENCED TO THE NEUTRAL POST. THESE READINGS SHOULD BE +24.00 

0.01VDC AT THE POST RED & YELLOW AND + 5.00  0.01VDC AT THE POST

COM. & ORG.

5.2.2.4. CONNECT THE VOLTMETER LEADS TO THE PRESSURE TRANSDUCER

PLUG ON THE SMALL PRINTED CIRCUIT BOARD AND VERIFY THAT +24 

0.01VDC ARE MEASURED ACROSS PINS 4 AND 6.

5.2.2.5. TURN THE POWER SWITCH TO OFF AND THEN RECONNECT THE

PRESSURE TRANSDUCER CONNECTOR TO THE SMALL PRINTED CIRCUIT

BOARD.

5.3. ALIGNMENTS

5.3.1. DIGITAL PANEL METER

5.3.1.1. TURN THE INSTRUMENT’S POWER SWITCH TO ON. VERIFY THAT THE

DIGITAL PANEL DISPLAYS NUMBERS THAT ARE BRIGHT AND CLEAR.

5.3.1.2. TURN THE ZERO ADJUSTMENT KNOB ON THE FRONT PANEL FROM

STOP TO STOP SLOWLY AND VERIFY THAT SMOOTH DIGITAL CHANGES OCCUR

AND THAT ALL SEGMENTS OF EACH DIGIT ILLUMINATE.

5.3.1.3. TURN THE ZERO ADJUSTMENT KNOB ON THE FRONT PANEL TO THE

MID-RANGE POSITION (5 TURNS FROM THE STOP FOR A TYPICAL 10 TURN

POTENTIOMETER).

5.3.1.4. TURN THE SELECTOR VALVE TO THE CELL POSITION AND OPEN THE

GAS OUT TOGGLE VALVE TO VENT THE CELL. AFTER 5 MINUTES OF WARM UP

TIME ADJUST RESISTOR R1 LOCATED ON THE SMALL PRINTED CIRCUIT

BOARD FOR A READING OF 0.000 PSIG ON THE DIGITAL PANEL METER. THIS IS

PERFORMED BY PLACING A JEWELER’S SCREWDRIVER THROUGH THE HOLE IN

THE BACK PANEL AND TURNING THE POTENTIOMETER UNTIL THE DIGITAL

PANEL METER READING DISPLAYS 0.000 PSIG.

5.3.1.5. PLACE A SMALL AMOUNT OF TORQUE SEAL BETWEEN THE

ADJUSTMENT KNOB AND THE BODY OF THE POTENTIOMETER R1 TO INSURE

THAT IT REMAINS UNCHANGED DURING SHIPMENT.

5.3.2 Texmate DI-50E Panel Meter Setup

STEP A CODE SETUP: Instrument Model No. MVP-DI50E (Multi- Pycnometer)

5.3.2.1 Press Program and Up-arrow at the same time:

This enters the main programming mode. Display toggles between [bri]

and [5].

Press Program to set bri to 5. If bri is not set to 5 then use up/ down arrow

and

set bri to 5.

5.3.2.2 Press Program button

Display toggles between [CAL] and [000].

5.3.2.3 Press Program button again

Display toggles between [Cod_1] and [000].

Change Cod_1 to 001 for model#24000-2-0-D. Enter 061 for

model#20033-1

5.3.2.4 Press Program button

Display toggles between [DiSP] and [003].

Change DiSP to 004. (This will move the decimal)

5.3.2.5 Press Program button

Display toggles between [Cod_1] and [061]

Change Cod_1 to 000.

5.3.2.6 Press Program button

Display toggles between [Cod_2] and [XXX]

Change Cod_2 to 001.

5.3.2.7 Press Program button

Display toggles between [Cod_3] and [XXX]

Change Cod_3 to 000.

5.3.2.8 Press Program button

Display toggles between [Cod_4] and [XXX] Note: Set Cod_4 to 000 for

60 Hz

Change Cod_4 to 000. Set Cod_4 to 001 for

50 Hz

5.3.2.9 Press Program button

Display toggles between [Cod_5] and [XXX]

Change Cod_5 to 000.

5.3.2.10 Press Program button until you have reached Cod_8.

Display toggles between [Cod_8] and [XXX]

Change Cod_8 to 002.

5.3.2.11 Press Program button

Display toggles between [Cod_9] and [XXX]

Change Cod_9 to 000.

5.3.2.12 Press Program button

Display will indicate instrument’s current pressure.

Verify the decimal is set as XX.XXX

5.3.2.13 Press Program and Down-arrow at the same time:

This enters the setpoint-programming mode.

Display toggles between [SP_1] and [50000]. 18.xxx for the new model

5.3.2.14 Press the Program button repeatedly until the

Display toggles between [SP_5] and [30000],10000 for the new model.

Change SP_5 to 1.000

Note: If SP_5 is unavailable, perform the next step (SPC_5) then come back

to this step; Ensure SPC_5 is set to [000].

You should now be able to set up SP_5 to 1.000. Continue and perform the

next step before locking the meter.

5.3.2.15 Press Program button repeatedly until the

Display toggles between [SPC_5] and [000].

Change SPC_5 to 46.

5.3.2.16 Check all the setting before lock

STEP B LOCK CODE SETUP:

5.3.2.17 Loosen the meter from cabinet.

5.3.2.18 Remove black face meter bezel.

5.3.2.18 Set both DIP Switches from OFF to ON position.

5.3.2.20 Reinstall the bezel and secure the meter.

Table des matières

Autres manuels QUANTACHROME INSTRUMENTS Instrument de mesure

QUANTACHROME INSTRUMENTS

QUANTACHROME INSTRUMENTS MVP-6DC Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
