qpcom QP-G1008P Manuel utilisateur
User’s Manual
QP-G1008P
8-Port 10/100/1000 Gigabit Switch
www.qpcom.com
www.qpcom.com
QP-G1008P
2
POWER 8 7 6 5 4 3 2 1
1 2 3 4 5 6 7 8
www.qpcom.com
QP-G1008P
3
LED Color Status Description
Power
Green O N This indicator lights when the
Switch turns on.
— OFF
If this indicator is not lighting,
please check the DC power
connector to ensure proper
connectivity of the power cable
and the Switch.
Link/Act
Green
ON Indicates the Switch is connected
at 1000Mbps.
Blinking
Indicates the Switch is
transmitting/receiving data
packets at 1000Mbps.
Orange
ON Indicates the Switch is connected
at 10/100Mbps.
Blinking
Indicates the Switch is
transmitting/receiving data
packets at 10/100Mbps.
— OFF Indicates the connection fails.
1 2 3 4 5 6 7 8
RJ-45 CONECTOR
1 2 3 4 5 6 7 8
Router or Switch SERVER
PC1
PC2 PC3
www.qpcom.com
QP-G1008P
4
Standards
IEEE802.3 10Base-T Ethernet
IEEE802.3u 100 Base-TX Fast
Ethernet
IEEE802.3ab Gigabit Ethernet
Protocol
CSMA/CD
Topology S tar
Network Cables
10 Base-T: Cat.3UTP or above
100 Base-TX: Cat.5 UTP /STP
1000Base-T: Cat.5, Cat.5e or Cat.6
UTP/STP
Speed 1 0/100/1000Mbps
Transmission Method s tore-and-forward
MAC Address Table4 K/8K entries
Packet Filtering/
Forwarding Rate
14880pps(10Mbps)per port
148800pps(100Mbps)
per port
1488000pps(1000Mbps)
per port
MAC Address Learning
Self-learning, auto-aging
Power E xternal universal power supply
DC Input D C 9V 600mA
Power Consumption 3.7W/4.5W
Operating Temperature
0OC ~40OC
Storage Temperature -40OC ~70OC
Operating Humidity
10%~90% RH no condensing
Storage Humidity 5%~90% RH no condensing
