QNAP TBS-464 Manuel utilisateur
TBS-464
TBS-464
User Guide
Document Version: 1
05/10/2021
Contents
1. Preface
About This Guide........................................................................................................................................................3
Audience..................................................................................................................................................................... 3
Document Conventions.............................................................................................................................................3
2. Product Overview
About TBS-464............................................................................................................................................................ 4
Hardware Specication............................................................................................................................................. 4
Components............................................................................................................................................................... 5
Front Panel.............................................................................................................................................................6
Right Panel.............................................................................................................................................................6
Rear Panel.............................................................................................................................................................. 7
Drive Numbering...................................................................................................................................................8
Package Contents...................................................................................................................................................... 8
Safety Information.....................................................................................................................................................8
Installation Requirements...................................................................................................................................... 10
Setting Up the NAS.................................................................................................................................................. 10
3. Installation and Conguration
Hardware Installation..............................................................................................................................................11
Installing M.2 Solid-State Drives........................................................................................................................11
Connecting USB Expansion Units......................................................................................................................16
QTS Installation........................................................................................................................................................18
Installing QTS Using Qnder Pro...................................................................................................................... 19
Installing QTS Using the Cloud Key...................................................................................................................21
Installing QTS Using an HDMI Connection...................................................................................................... 24
4. Basic Operations
Power Button........................................................................................................................................................... 26
Reset Button.............................................................................................................................................................26
USB One Touch Copy Button.................................................................................................................................. 27
LEDs...........................................................................................................................................................................27
Audio Alert................................................................................................................................................................28
5. NAS Migration
NAS Migration Requirements.................................................................................................................................29
Status and Setting Changes after NAS Migration................................................................................................29
Migrating a NAS....................................................................................................................................................... 30
Migrating NAS Data Using HBS 3...........................................................................................................................31
Preparing the Destination NAS......................................................................................................................... 31
Creating a One-Way Sync Job.............................................................................................................................32
Importing Local Users or Group Settings to the Destination NAS................................................................33
6. Troubleshooting
Forcing Qnder Pro or myQNAPcloud to Locate the NAS.................................................................................. 35
Recovering Unintentionally Removed Hard Drives............................................................................................. 35
Support and Other Resources................................................................................................................................35
7. Glossary
Cloud Key.................................................................................................................................................................. 37
TBS-464 User Guide
1
myQNAPcloud Link..................................................................................................................................................37
myQNAPcloud.......................................................................................................................................................... 37
Qnder Pro............................................................................................................................................................... 37
QNAP ID.................................................................................................................................................................... 37
QTS.............................................................................................................................................................................37
8. Notices
Limited Warranty..................................................................................................................................................... 38
Disclaimer................................................................................................................................................................. 38
GNU Public License..................................................................................................................................................38
CE Notice...................................................................................................................................................................46
UKCA Notice..............................................................................................................................................................46
FCC Notice.................................................................................................................................................................46
VCCI Notice............................................................................................................................................................... 47
BSMI Notice.............................................................................................................................................................. 47
SJ/T 11364-2006........................................................................................................................................................47
2
1. Preface
About This Guide
This guide provides information about the device and step-by-step instructions on installing the hardware. It
also provides instructions on basic operations and troubleshooting information.
Audience
This document is intended for consumers and storage administrators. This guide assumes that the user has
a basic understanding of storage and backup concepts.
Document Conventions
Symbol Description
Notes provide default conguration settings and other supplementary
information.
Important notes provide information on required conguration settings and
other critical information.
Tips provide recommendations or alternative methods of performing tasks or
conguring settings.
Warnings provide information that, when ignored, may result in potential loss,
injury, or even death.
TBS-464 User Guide
Preface 3
2. Product Overview
This chapter provides basic information about the QNAP device.
About TBS-464
The TBS-464 is a compact NAS powered by an Intel® Celeron® N5105/N5095 4-core processor (up to 2.9 GHz
burst) and supports 8 GB of DDR4 memory. It has two 2.5 Gigabit Ethernet ports for enhanced connectivity,
and provides multimedia support through its HDMI connection. In addition to its four M.2 PCIe NVMe slots,
the TBS-464 features USB One Touch Copy for easy and ecient data transfer.
Hardware Specication
Warning
If your QNAP product has hardware defects, return the product to QNAP or a QNAP-
authorized service center for maintenance or replacement. Any attempt to repair or
perform maintenance procedures on the product by you or an unauthorized third party
invalidates the warranty.
QNAP is not responsible for any damage or data loss caused by unauthorized
modications and installation of unsupported third-party applications.
For details, see the QNAP Warranty Terms and Conditions.
Ordering P/N CPU Memory Power supply
TBS-464-8G Intel® Celeron® N5105/
N5095
8 GB Adapter
Component TBS-464-8G
Processor
CPU Intel® Celeron® N5105/N5095
Frequency 4-core/4-threads up to 2.9 GHz burst
Architecture x86 64-bit
Encryption engine AES-NI
Memory
Pre-installed memory 8 GB RAM DDR4 (not expandable)
Flash memory 4 GB (dual-boot OS protection)
Storage
M.2 SSD slots 4 x PCIe NVMe Gen 3 x2
M.2 SSD form factor 2280
Network
2.5 Gigabit Ethernet ports 2 x 2.5 GbE RJ45
Note
The 2.5 Gigabit Ethernet port supports the following
network connectivity speeds: 2.5 GbE, 1 GbE, 100 Mb, and
10 Mb.
Wake-on-LAN Yes
External I/O Ports & Expansion Slots
TBS-464 User Guide
Product Overview 4
Component TBS-464-8G
USB ports Front:
2 x USB 3.2 Gen 1 Type-A ports
Note
This USB port supports One Touch Copy.
Right:
1 x USB 2.0 Type-A port
Rear:
2 x USB 2.0 Type-A ports
HDMI ports 2 x HDMI 2.0 (up to resolution 3840 x 2160 @ 60 Hz)
Interface
Buttons • Power
• Reset
• USB One Touch Copy
Dimensions
Form factor Compact
Dimensions (H x W x D) 30 x 230 x 165 mm
(1.18 x 9.06 x 6.50 in)
Net weight 0.8 kg
(1.76 lbs)
Others
Power supply unit Power adapter, 65W, 100-240V, DC, 50/60 Hz
Sound level 15.8 dB(A)
Note
The sound level was tested at a bystander position, which
is within one meter of the NAS. The test NAS operated at
low speed with the maximum number of drives installed.
Fans System fan: 1
Operating temperature 0˚C to 40˚C (32˚F to 104˚F)
Relative humidity • Non-condensing relative humidity: 5% to 95%
• Wet-bulb temperature: 27˚C (80.6˚F)
Security slot Kensington security slot
Tip
For the list of compatible drive models and expansion cards, go to https://www.qnap.com/
compatibility.
Components
TBS-464 User Guide
Product Overview 5
Front Panel
No. Component No. Component
1 USB One Touch Copy button 4 M.2 SSD LEDs
2 USB 3.2 Gen 1 One Touch Copy Type-A port 5 Power button
3 USB 3.2 Gen 1 Type-A port - -
Right Panel
No. Component No. Component
1 USB 2.0 Type-A port - -
TBS-464 User Guide
Product Overview 6
Rear Panel
Note
The 2.5 Gigabit Ethernet ports are multi-speed Gigabit Ethernet ports.
No. Component No. Component
1 Kensington security slot 6 2.5 Gigabit Ethernet speed LED
2 Reset button 7 Ethernet port 1 (2.5 GbE RJ45)
3 USB 2.0 Type-A ports 8 HDMI 2.0 ports
4 2.5 Gigabit Ethernet activity LED 9 Power input
5 Ethernet port 2 (2.5 GbE RJ45) - -
TBS-464 User Guide
Product Overview 7
Drive Numbering
Note
This image shows the device with the cover removed.
No. Component No. Component
1 M.2 SSD slot 1 3 M.2 SSD slot 3
2 M.2 SSD slot 2 4 M.2 SSD slot 4
Package Contents
Item Quantity
TBS-464 1
AC power adapter 1
Power cord 1
Ethernet cables 1 x Cat 5e
Heatsinks for M.2 SSDs 4
Thermal pads for M.2 SSDs 12
Quick Installation Guide (QIG) 1
Safety Information
The following instructions help ensure personal safety and environmental safety. Read these instructions
carefully before performing any operation.
General Instructions
• The device should be stored in a secure location with restricted access, controlled through the use of a
tool, lock and key, or any means of security.
TBS-464 User Guide
Product Overview 8
• Only qualied, skilled, and authorized persons with knowledge of all restrictions, safety precautions,
and installation and maintenance procedures should have physical access to the device.
• To avoid potential injury or damage to components, ensure that the drives and other internal system
components have cooled before touching them.
• Observe electrostatic discharge (ESD) procedures to avoid potential injury or damage to components.
Power
• To reduce the risk of re or electric shock, ensure that you only connect the power cord to a properly
grounded electrical outlet.
•
Devices with redundant power supply may have one or more power supply unit (PSU) cords. To avoid
serious injuries, a trained service technician must disconnect all PSU cords from the device before
installing or replacing system components.
System Battery
• To avoid potential battery explosion, causing injury or damage to components, ensure that you replace
the existing battery with a battery of the same type.
• Dispose of used batteries properly according to local regulations or the instructions of the battery
manufacturer.
Moving Parts
•
Moving fan blades: Keep your body parts away from moving fan blades while the device is connected
to a power source.
•
Moving components: Keep your body parts away from other moving components.
TBS-464 User Guide
Product Overview 9
