QUICK START GUIDE
z
FIBRE CHANNEL SWITCH INSTALLATION
SANbox®9000 Series
for Windows®Operating Systems
Purchasers of OEM products should consult with the OEM for support.
Support Headquarters QLogic Corporation
12984 Valley View Road
Eden Prairie, Minnesota 55344-3657
USA
QLogic Web Site www.qlogic.com
Technical Support Web Site support.qlogic.com
North American Region
Email [email protected]
Phone +1-952-932-4040
Fax +1 952-974-4910
Europe, Middle East, and Africa Region
Email [email protected]
Phone Numbers by Language +353 1 6924960 - English
+353 1 6924961 - Français
+353 1 6924962 - Deutsch
+353 1 6924963 - Español
+353 1 6924964 - Português
+353 1 6924965 - Italiano
Asia Pacific Region
Email [email protected]
Phone Numbers by Language +63-2-885-6712 - English
+63-2-885-6713 - (Mandarin)
+63-2-885-6714 - (Japanese)
+63-2-885-6715 - (Korean)
Latin and South America Region
Email [email protected]
Phone Numbers by Language +52 55 5278 7016 - English
+52 55 5278 7017 - Español
+52 55 5278 7015 - Português
3
Quick Start Guide
Installation Instructions
Congratulations on your purchase of the SANbox®9000 Series Fibre Channel Switch. This guide describes the steps to
install and activate your new switch using a Windows® workstation. For advanced options and instructions (including
Solaris®, Linux®, and Mac OS X®installations), refer to the SANbox 9000 Series Stackable Chassis Switch Installation
Guide on the product CD.
NOTE: Do not apply power to the switch until instructed in Step 4.
Step 1. Verify the Package Contents
The SANbox 9000 Series Fibre Channel Switch is shipped with the following items:
1 SANbox 9000 Series Fibre Channel Switch
2 AC Power cords
1 Rail kit
1 RJ-45/RS-232 console adapter
1 Enterprise Fabric Suite 2007 CD
NOTE: Transceivers and stacking cables, if you ordered them, are packaged separately.
Step 2. Mount the Switch
WARNING!! Two people are required to safely lift and install the switch into a rack. To avoid personal injury or damage
to the switch, arrange for assistance.
You can mount the SANbox 9000 Series switch on a flat surface or in a rack. Allow minimum clearances of 2 inches in
front and 8 inches in the rear for cabling.
❑For a rack mount, install the SANbox 9000 Series rail kit in a standard 19" rack as described in the SANbox 9000
Series Stackable Chassis Switch Rack Mounting Guide that is packaged with the switch.
Step 3. Install Transceivers
An SFP transceiver is required for each switch port that will be connected to a device.
❑To install an SFP transceiver, insert the transceiver into the switch port and gently press until it snaps in place. The
transceiver will fit only one way. If the transceiver does not install under gentle pressure, flip it over and try again.
4
Step 4. Apply Power to the Switch
The maximum current requirements are 10 amps at 100 VAC or 4.2 amps at 240 VAC.
❑Attach the AC power cords to the Power Supply blades
and wall outlets or power strips. Secure the strain
relief bales to the plugs. Place the On/Off switches in
the On position.
❑The switch runs its self tests and begins normal
operation – this may take a few minutes. Observe the
Maintenance Panel and verify that the CPU0 blade
Heartbeat LED is blinking about once per second and
the Chassis Fault LED is NOT illuminated.
Step 5. Verify Workstation Requirements
❑Verify that your workstation can support the Enterprise Fabric Suite 2007™ application with the following minimum
requirements:
Windows® 2003 SP1/SP2/R2 and XP
256 MB memory minimum; 512 MB recommended
150 MB disk space
1 GHz processor
Video card with 256 colors
CD ROM drive, RJ-45 Ethernet port
Internet Browser: Microsoft®Internet Explorer®5.0, Netscape Navigator®6.0, Firefox®1.0, or Mozilla™ 1.5
Java®2 Standard Edition Runtime Environment 1.4.2
❑The default IP address of a new switch is 10.0.0.1. Ensure that your workstation is configured to communicate
with the 10.0.0 subnet.
CHASSIS
GOOD LED
CPU0
HEARTBEAT
LED
CHASSIS
FAULT LED
5
Step 6. Connect the Workstation to the Switch
❑Connect the CPU0 blade Ethernet port directly to the workstation using an Ethernet cable, or indirectly through a
switch or hub. The Ethernet port automatically discovers straight and cross-over cables. You must have a live
Ethernet connection when the workstation powers up.
NOTE: The Maintenance Panel Ethernet ports on the front of the switch are disabled and should not be used for the
initial installation. You can enable the Maintenance Panel Ethernet ports after the switch is operational.
Step 7. Install Enterprise Fabric Suite 2007
The Enterprise Fabric Suite 2007 application includes the Configuration Wizard. This wizard auto-detects and configures
the switch based on selected options and recommended settings. To install the Enterprise Fabric Suite 2007 application
on a Windows workstation/server, perform the following steps:t
1. Insert the Enterprise Fabric Suite 2007 disk into the CDROM drive.
2. Select the Enterprise Fabric Suite 2007 tab at the top of the screen.
3. Click Agree in response to the End User License Agreement.
4. Select Install for Windows 2003, XP.
5. Double click the Windows_6.08.xx.exe file to begin installation.
6. Enter the serial number and license key provided to activate the Enterprise Fabric Suite 2007
application.
If the product introduction screen does not open, open the CD with Windows Explorer and run the installation program
with the following path:
Switch_Manager\Windows_6.08.xx.exe
Step 8. Obtain Network Configuration
❑Obtain the IP address and subnet mask from your network administrator. Be sure that your workstation is configured
for the same subnet.
CPU0 BLADE
ETHERNET PORT
6
Step 9. Run the Configuration Wizard
❑Double-click the Enterprise Fabric Suite 2007 shortcut, or select Enterprise Fabric Suite 2007 from Start menu,
depending on how you installed it.
❑The Configuration Wizard tool auto-detects and configures the switch based on selected options and recommended
settings. Follow the instructions to set network parameters and the password. The default user name is admin; the
default password is password.
NOTE: If you are using an Ethernet switch and the auto-connect process fails due to a time out, try a direct connection
from your workstation to the switch using an Ethernet cross-over cable.
Step 10. Connect Devices and Switches
❑Connect fiber optic cables between the installed transceivers and their corresponding devices. Each port
auto-negotiates the proper port type with the connected device or switch.
Congratulations
You have successfully installed your QLogic SANbox 9000 Series Switch
© 2007 QLogic Corporation. QLogic, the QLogic logo, SANbox, and Enterprise Fabric Suite 2007 are trademarks or
registered trademarks of QLogic Corporation. Microsoft , Windows, and Internet Explorer are registered trademarks of
the Microsoft Corporation. MacOS X is a registered trademark of Apple Computer, Inc. Linux is a registered trademark
of Linus Torvalds. Mozilla and Firefox are trademarks or registered trademarks of the Mozilla Foundation. Netscape
Navigator is a registered trademarks of Netscape Communications Corporation. Java and Solaris are registered
trademarks of Sun Microsystems, Inc. All other brands and product names are trademarks or registered trademarks of
their respective owners. Information supplied by QLogic is believed to be accurate and reliable. QLogic Corporation
assumes no responsibility for any errors in this brochure. QLogic Corporation reserves the right, without notice, to
makes changes in product design or specifications.
*50688-03 A*
JQLogic Corporation 26650 Aliso Viejo Parkway Aliso Viejo, CA 92656
949.389.6000 www.qlogic.com
50688-03 A
