Q-Tech QSR-3920 Series Feuille d'instructions

CONFIGURATION MANUAL

www.qtech.ru

QSR-3920 Series Router Configuration

Manual

QSR-3920-08


www.qtech.ru

Table of contents
SYSTEM OPERATION BASICS 6
1 Overview 6
2 System Operation Basic Functions 6
2.1 Device Configuration Modes 6
2.2 Command Operating Modes 6
2.3 Command Line Interface 9
SYSTEM LOGIN 15
1 Overview 15
2 System Login Function Configuration 15
2.1 Log in to Device via Console Port 15
2.2 Configure Remote Login via Telnet 18
2.3 Configure Remote Login via SSH 19
2.4 System Login Monitoring and Maintaining 20
3 Typical Configuration Example of System Login 20
3.1 Configure a Local Terminal to Telnet to the Device 20
3.2 Configure a Local Device to Log in to a Remote Device via Telnet 22
3.3 Configure a Local Device to Log in to a Remote Device via SSH 23
SYSTEM CONTROL AND MANAGEMENT 25
1 Overview 25
2 Login Control and Management Function Configuration 25
2.1 Switch Over Between User Levels 26
2.2 Configure the Command Level 28
2.3 Configure the enable Password 28
2.4 Configure Users and the Related Properties 29
2.5 Configure Line Properties 33
2.6 System Control and Management Monitoring and Maintaining 40
FTP, FTPS, TFTP AND SFTP 41
1 Overview 41
2 FTP, FTPS, TFTP, and SFTP Function Configuration 42
2.1 Configure an FTP Server 42
2.2 Configure an FTP Client 43
2.3 Configure a TFTP Client 44
2.4 Configure a TFTP Server 45


www.qtech.ru
2.5 Configure an SFTP Server 46
2.6 Configure a SFTP Client 46
2.7 FTP, TFTP and SFTP Monitoring and Maintaining 47
3 Typical Configuration Example of FTP, TFTP, and SFTP 47
3.1 Configure a Device as an FTP Client 47
3.2 Configure a Device as an FTP Server 48
3.3 Configure a Device as an TFTP Client 52
3.4 Configure a Device as an SFTP Client 54
3.5 Configure a Device as an SFTP Server 55
3.6 Configure a Device as an FTPS Client 57
FILE SYSTEM MANAGEMENT 62
1 Overview 62
2 File System Management Function Configuration 62
2.1 Manage Storage Devices 63
2.2 Manage File Directories 64
2.3 Manage File Operations 66
2.4 Download Files from the FTP 68
2.5 Execute a Configuration File Manually 69
2.6 Configure Startup Parameters 69
2.7 File System Managing, Monitoring, and Maintaining 70
3 Typical Configuration Example of File System Management 70
3.1 Configure Startup Parameters 70
CONFIGURATION FILE MANAGEMENT 72
1 Overview 72
2 Configuration File Management Function Configuration 72
2.1 Save the Current Configuration 73
2.2 Configure the Backup System 73
2.3 Restore the Startup Configuration 75
2.4 Configuration File Managing, Monitoring, and Maintaining 75
SYSTEM MANAGEMENT 77
1 Overview 77
2 System Management Function Configuration 77
2.1 Configure the Device Name 78
2.2 Configure the System Time and Time Zone 78
2.3 Configure the Login Welcome Message 79
2.4 Configure the System Exception Processing Mode 79


www.qtech.ru
2.5 Configure to Restart a Device 80
2.6 Configure the Encryption Service 81
2.7 Configure the History Command Saving Function 81
2.8 Configure the Login Security Service 82
2.9 Configure CPU Monitoring 83
2.10 Configure Display of Properties in Pages 84
2.11 Configure a Serial Number for a Module Part 85
2.12 Delete the Serial Number of a Module Part 85
2.13 System Management Monitoring and Maintaining 86
SYSTEM ALARM 88
1 Overview 88
2 System Alarm Function Configuration 88
2.1 Configure System Temperature Alarms 88
2.2 Configure System Power Supply Alarms 89
2.3 Configure System Fan Alarms 89
2.4 Configure System Alarm Parameters 89
2.5 System Alarm Monitoring and Maintaining 90
SYSTEM LOG MANAGEMENT 91
1 Overview 91
2 System Log Function Configuration 92
2.1 Configure Log Output Functions 93
2.2 Configure the Timestamp for Logs 97
2.3 Configure a Log Task Name 98
2.4 Configure the Log Filtration Function 98
2.5 Configure the Log File Capacity 99
2.6 Configure Log Display Colors 99
2.7 System Log Monitoring and Maintaining 100
SOFTWARE UPGRADE 101
1 Overview 101
2 Software Upgrade Function Configuration 101
2.1 Upgrade the image Program Package 102
2.2 Upgrade the FPGA Program 103
2.3 Upgrade the bootloader Program 105
2.4 Upgrade devinfo File 109
3 Typical Configuration Example of Software Upgrade 111
3.1 Upgrade All Software Versions 111


www.qtech.ru
3.2 Upgrade the bootloader Program via the Console Port 115
BOOTLOADER 117
1 Overview 117
2 Bootloader Function Configuration 117
2.1 Preparation before Configuring the Bootloader Functions 117
2.2 Set the Bootloader Boot Parameters 117
2.3 Upgrade the Bootloader Program 118
2.4 Bootloader Monitoring and Maintaining 119
3 Typical Configuration Example of Bootloader 119
3.1 Configure bootloader to Guide the Image Program from the File System 119
3.2 Configure bootloader to Guide the Image Program from the Network 120






Configuration manual

1. System Operation Basics 6

www.qtech.ru

1SYSTEM OPERATION BASICS

1.1 Overview

System operation basics mainly describe the basic knowledge of device operations, including

device configuration modes, command modes, and command line interface.

1.2 System Operation Basic Functions

Table 1-1 Configuration list of the system operation basic functions

Configuration Task

Device configuration mode

Command operating mode

Command line interface

1.2.1 Device Configuration Modes

Users can log in to the device for configuration and management in different modes. (For

details of the login modes, refer to the chapter "System login" in the configuration guide.) The

device provides four typical configuration modes:

Logging in to the device locally through the Console port. By default, users can configure

the device directly in this mode.

Logging in to the device by remote dial-up through a Modem. The device cannot be

configured directly in this mode, that is, before configuration, some preparations need to

be made.

Logging in to the device remotely through Telnet. The device cannot be configured directly

in this mode, that is, before configuration, some preparations need to be made.

Logging in to the device remotely through SSH. The device cannot be configured directly in

this mode, that is, before configuration, some preparations need to be made.

1.2.2 Command Operating Modes

The device provides a command processing subsystem for management and execution of

system commands. The subsystem shell provides the following main functions:

Registration of system commands

Editing of system configuration commands by users

Parsing of the commands that have been inputted by users

Execution of system commands

If a user configures the device through shell commands, the system provides multiple

operating modes for the execution of the commands. Each command mode supports specific

Configuration manual

1. System Operation Basics 7

www.qtech.ru

configuration commands. In this way, hierarchical protection is provided to the system,

protecting the system from unauthorized access.

The shell subsystem provides multiple modes for the operating of configuration commands.

These modes have different system prompts, prompting the current system mode of the user.

The following lists common configuration modes:

Common user mode (user EXEC)

Privileged user mode (privilege EXEC)

Global configuration mode (global configuration)

Interface configuration mode (interface configuration)

File system configuration mode (file system configuration)

Access list configuration mode (access list configuration)

Other configuration modes (They will be described in the related sections and chapters.)

The following table shows how to enter the common command modes and switch over

between the modes.

Table 1-2 System modes and methods of switching over between the modes

Mode

How to

Enter the

Mode

System

Prompt

How to Exit the

Mode

Functions

Commo

n user

mode

the device.

Hostname>

Run the exit

command to

exit the mode.

Changes the terminal

settings.

Performs basic tests.

Display the system

information.

Privilege

d user

mode

In common

user mode,

run the

enable

command.

Hostname#

Run the disable

or exit

command to

exit to the

common user

mode.

Configure the

operating parameters

of the device.

Display the operating

information of the

device.

Global

configur

ation

mode

privileged

user mode,

run the

configure

terminal

command.

Hostname(con

fig)#

Run the disable

or exit

command to

exit to the

common user

mode

Configures the global

parameters that are

required for the

device operation.

Interface

In global

Hostname(con

Run the exit

In this mode,

Configuration manual

1. System Operation Basics 8

www.qtech.ru

configur

ation

mode

configuratio

n mode,

run the

interface

command

(while

specifying

the

correspondi

ng interface

or interface

group).

fig-if-

xxx[number])#

Hostname(con

fig-if-

group[number

])#

command to

exit to the

global

configuration

mode.

Run the end

command to

exit to the

privileged user

mode.

configures device

interfaces, including:

Interfaces of different

types

Interface groups

File

system

configur

ation

mode

In the

privileged

user mode,

run the

filesystem

command.

Hostname(con

fig-fs)#

Run the exit

command to

exit to the

privileged user

mode.

Manages the file

system of the device.

Access

list

configur

ation

mode

In global

configuratio

n mode,

run the ip

access-list

standard or

ip access-

list

extended

command.

Hostname(con

fig-std-nacl)#

Hostname(con

fig-ext-nacl)#

Run the exit

command to

exit to the

global

configuration

mode.

Run the end

command to

exit to the

privileged user

mode.

Configures the Access

Control List (ACL). The

configuration tasks

include:

Configuring standard

access control lists.

Configuring extended

access control lists.

Hostname is the system name. In global configuration mode, a user can run

the hostname command to modify the system name, and the modification

takes effect immediately.

If a user is not in privileged user mode while the user wants to run a

privileged mode command, the user can use the do command to run the

required command without the need to returning back to the privileged

mode. (For details, refer to the related sections in "System Operation

Basics" of the command manual.) Note that the mode switchover command

Configuration manual

1. System Operation Basics 9

www.qtech.ru

such as do configure terminal is not included.

1.2.3 Command Line Interface

The command line interface is a man-machine interface that is provided by the shell subsystem

to configure and use the device. With the command line interface, users can input and edit

commands to perform the required configuration tasks, and they can also query the system

information and learn the system operation status.

The command line interface provides the following functions for the users:

System help information management

System command inputting and editing

History command management

Terminal display system management

Command Line Online Help

The command line provides the following types of online help:

Help

Full help

Partial help

With the above types of online help, users can obtain various help information. The following

gives some examples.

To obtain a brief description of the online help system, run the help command in any

command mode.

Hostname#help

Help may be requested at any point in a command by entering

a question mark '?'. If nothing matches, the help list will

be empty and you must backup until entering a '?' shows the

available options.

Two styles of help for command are provided:

1. Full help is available when you are ready to enter a

command argument (e.g. 'show ?') and describes each possible

argument.

2. Partial help is provided when an abbreviated argument is entered

and you want to know what arguments match the input

(e.g. 'show pr?'.)

And "Edit key" usage is the following:

CTRL+A -- go to home of current line

CTRL+E -- go to end of current line

CTRL+U -- erase all character from home to current cursor

CTRL+K -- erase all character from current cursor to end

Configuration manual

1. System Operation Basics 10

www.qtech.ru

CTRL+W -- erase a word on the left of current cursor

CTRL+R -- erase a word on the right of current cursor

CTRL+D,DEL -- erase a character on current cursor

BACKSPACE -- erase a character on the left of current cursor

CTRL+B,LEFT -- current cursor backward a character

CTRL+F,RIGHT -- current cursor forward a character

To list all commands and their brief description in any command mode, type "?" in the

command mode.

Hostname#configure terminal

Hostname(config)# ?

3g-modem 3g modem reset by sms configure

aaa Authentication, Authorization and Accounting

access-list Access list

alarm Set the utilization factor alarm of the cpu or

memory

apply Command apply

arp Set a static ARP entry

banner Define a login banner

bgp BGP information

bridge Bridge Group

cam Config cam global parameters

cardreset-exception Cardreset exception handling for Modem card

cellular Cellular

..................................................... ......... ......

Type a command followed by "?", and all sub-commands that can be executed in the

current mode are displayed.

Hostname#show ?

3g-modem-reset 3g modem reset correlative information

about Print the copyright information

access-list Access List

access-list-reflexive List reflexive access lists

access-lists Show acl lists

acl-log-count Display the number of access list log

acl-object Show acl object

arp Command arp

bfd BFD Protocol information

bgp BGP information

bridge Bridge Forwarding/Filtering Database [verbose]

cam Command cam

card_list Show information of hardware modules

Autres manuels pour QSR-3920 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels q-Tech Routeur réseau

q-Tech

q-Tech QSR-2830 Manuel utilisateur

q-Tech

q-Tech QSR-2920 Series Feuille d'instructions

q-Tech

q-Tech SMS Lite 4G Manuel utilisateur

q-Tech

q-Tech QSW-3900 Manuel utilisateur

q-Tech

q-Tech QSR-3920 Series Manuel utilisateur

q-Tech

q-Tech QSW-2900 Manuel utilisateur

q-Tech

q-Tech QSW-9010 Manuel utilisateur

q-Tech

q-Tech QSR-2920 Series Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité

q-Tech QSR-3920 Series Feuille d'instructions

Manuels Routeur réseau populaires d'autres marques
