PRODUCT OVERVIEW

01

Page 4

Contact SegenSolar (PTY) Ltd | e: info@segensolar.co.za | t: 08780 20663

Figure UP5000 product parameters[2]

*Double single string module quantity

*95% DoD

*Double installation altitude

*Pre-charge: smooth inrush current

*Dual-active protection: enhanced safety

*Flexible current steps: enable 50%

more power during critical temperature

condition.

*Dry contact wake up: available for Dry

contact wake up.

Page 5

Contact SegenSolar (PTY) Ltd | e: info@segensolar.co.za | t: 08780 20663

*Double single string module quantity

*95% DoD

*Double installation altitude

*Pre-charge: smooth inrush current

*Dual-active protection: enhanced safety

*Flexible current steps: enable 50% more

power during critical temperature

condition.

*Dry contact wake up: available for dry

contact wake up.

Figure 1 US3000C product parameters[1]

Product parameter feature

@60s

Page 6

Contact SegenSolar (PTY) Ltd | e: info@segensolar.co.za | t: 08780 20663

Ascendancy

Lithium-ion Battery Testing Report from ITP renewable Australia shows the estimated state of

health (SOH) against cycles completed for each Phase 2 battery pack still cycling. SOH is

estimated by dividing the energy delivered at each capacity test by the energy delivered in the

first capacity test.

Figure 3: Capacity fade of Phase 2 battery packs based on monthly capacity tests[3]

Page 7

Contact SegenSolar (PTY) Ltd | e: info@segensolar.co.za | t: 08780 20663

Compared with most types of LV batteries in the

market,

Pylon batteries posses:

A. DoD –95%

B. Weight –40kG for a 5kWh module

C. Power strength –Available for max. 1C rate

operation, peak up to 200 Amps @15 sec

per single module

D. Safety –IEC/CE/UL/UN38.3 proved

E. Expansion -Max. 70kWh per single string,

expandable to 350 kWh per system

F. Life span –more than 6000 cycles

G. Operation environment –4000m altitude, 0

–50 ℃

Ascendancy

Page 8

Contact SegenSolar (PTY) Ltd | e: info@segensolar.co.za | t: 08780 20663

APPLICATION & CONFIGURATION

02

Page 9

Contact SegenSolar (PTY) Ltd | e: info@segensolar.co.za | t: 08780 20663

Application

Page 10

Contact SegenSolar (PTY) Ltd | e: info@segensolar.co.za | t: 08780 20663

•Back-up

•Peak Shaving

•PV ESS

Inverter

Hybrid

Residential
