Pyle PMP59IR Manuel utilisateur
PMP59IR
MegaphonewithRechargeableBattery
Handheld Microphone,Aux (3.5mm) Input,
Voice Record & Replay Mode
www.PyleUSA.com
PMP59IR
Megaphone with Rechargeable Battery
Handheld Microphone, Aux (3.5mm) Input, Voice Record & Replay Mode
This user manual contains important information for safe operation and
optimal megaphone performance. Please carefully read and follow safety
notes and instructions. Save this manual for future reference. Make sure that
it is available to all persons using this device.
PRECAUTIONS
• Ensure correct polarity of Batteries used. Insert the batteries in the correct
direction by aligning the (-) marks on the batteries with the spring in the
back cover.
• Charge the lithium battery for 3 – 4 hours before rst use.
After the lithium battery is fully charged, the indicator light will change
from red into green.
• For best quality, when the megaphone has not been in use for a long
period of time, replace the batteries.
• Drained or weakened batteries will not give sucient sound volume.
• Replace batteries or charge the lithium battery at regular intervals (usually
three month periods), for optimal performance.
2
*Important Note*: Before operating the
megaphone, ensure you hit the correct
switch to the proper position when
CHARGING/OPERATING Mode.
DC-12V Power
Supply Socket
Grip
Press-to-talk switch
Press this switch to talk
while holding the grip
Sound Volume Control
To increase volume,
turn it counter-clockwise
Shoulder Strap
Adjuster
Shoulder Pad Battery Compartment cover
Remove cover to replace batteries
Mic Fixing
Hanger
www.PyleUSA.com
OPERATING INSTRUCTIONS
• Open the back cover and remove the plastic battery
sleeve to insert 8 “D” Batteries in the correct
orientation, insert the sleeve into the battery according
to the instructions within the compartment.
OR
You can insert the included rechargeable battery.
Be sure to insert the black and double-orice plug into
the jack in the battery compartment. Then close the
back cover until it locks.
Now the megaphone is ready to be used.
• To activate the mic of the megaphone, press the button
on the grip after xing the hanger inlet to the mic xing
hanger or switch to‘TALK’ when carrying it on the
shoulder.
• When using the megaphone, place your mouth as close
as possible to the megaphone on the hanger inlet.
Adjust the volume accordingly without causing any
howling or interference feedback.
• Switch the button to ‘TALK’ and press the‘SIREN’ button
to activate the emergency siren. To turn o the siren,
switch back the same button to ’OFF’or press the
‘SIREN’ button again.
• Before recording, switch the button to ‘TALK’ and press
the ‘REC’ button, then the ‘REC’ indicator light will be
ON. Now the recording function is ready. Speak into the
microphone on the hanger inlet to record. To nish or
stop the recording, simply press the ‘REC’ button again.
The MAX recording time is 10 seconds.
• To play what you recorded in a loop, press the‘PLAY’
button. To stop, press the ‘PLAY’ button again.
TO REPLACE BATTERIES
Loosen the locking screw of the batttery compartment cover on back of the
body in order to remove the cover. Insert 8 x type ‘D’ batteries in the battery
case, making sure they’re in the correct position. Then, insert the battery
case with batteries into the battery compartment of the megaphone
observing correct polarity.
3
www.PyleUSA.com
BATTERY CHARGING
1. The megaphone features a removable rechargeable battery, that plugs-in
directly into the USB wall power outlet for charging. Once connected to
the wall power outlet, the battery will begin charging automatically, after
you set the battery to "Charge Mode" (average time for full-charge: 8.5
hours). A Red light will be lit while charging and turns Green when fully
charged.
2. *Important Note*: Before charging the battery, ensure you hit the switch
to "DC CHARGING" -- as located on the battery, to enable Charge Mode.
3. Once fully charged, insert the battery into the megaphone by opening the
end cap in the rear of the megaphone. Be sure to slide the battery into the
compartment properly, ensuring the power connection cable is exposed.
4. Once the battery is inserted, connect the battery power cable connector
into the megaphone power input -- ensure you set the battery to "Power
Output" Mode.
5. *Important Note*: Before operating the megaphone, ensure you hit the
switch to "DC OUTPUT" -- as located on the battery, to enable Power
Output Mode.
4
www.PyleUSA.com
PMP59IR
Megaphone with Rechargeable Battery
Handheld Microphone, Aux (3.5mm) Input, Voice Record & Replay Mode
Features:
• (3) Megaphone Modes: Talk + Siren + Record
• Recording Function with 10 Second Audio Memory
• Built-in Rechargeable Battery for Wireless PA Speaker Portability
• Battery Charges via Included USB Wall Power Adapter
*or Optional Battery Powered: Requires (8) x‘D’ Batteries, Not Included
• Aux (3.5mm) Input Connector Jack
• Ability to Connect & Stream Audio from External Devices
• Simple Button Control Operation
• High-Powered Audio Reproduction
• Convenient Wired Handheld Microphone
• Wide Bell Diameter for Extended Projection
• Ergonomic Pistol Grip & Lightweight Chassis
• Perfect for Outdoor Events and Crowd Control
• Used by U.S. Service Personnel & Armed Forces
• *Can be Optionally Powered via 12V Power Adapter
What's in the Box:
• Megaphone Speaker
• Rechargeable Battery
• USB Wall Adapter
Technical Specs:
• MAX Power Output: 50 Watt
• Audio Projection Range: Over 3,600’ ft.
• Sound Processor: Dynamic Piezo Driver
• Rechargeable Battery: 11.1V Lithium-iOn, 1500mAh (16.6Wh, 166g)
• Power: 110/240V
• Sold as: Unit
5
