Pyle PDRMKIT72N Manuel utilisateur
13''3-PieceKids/JuniorDrumSet
Metallic Drum Set with Throne, Cymbal, Pedal,
Bass Drum, Tom and Drumsticks
www.PyleUSA.com
2
CONTENTS CHECKLIST
First, check the contents of the package
and make sure you have everything you need.
ASSEMBLY INSTRUCTIONS
1. Take out all the parts from the package and remove the packing bags.
1. Bass Drum Head
2. Drum Mute Mat
3. Cymbal
4. Snare drum
5. Tom Tom
6. Bass drum
7. Accessory Box
8. Pedal
9. Bass Drum Bolts
10. Bass Drum Spur
11. Cymbal Holder
12. Drum Tuning Keys
13. Pedal Heads
14. Throne Pedestal
15. Tom / Snare Drum Holder
16. Drumstick
17. Throne seat
1
2
5
6
4
7
3
www.PyleUSA.com
3
2. Take all the accessories from the accessories box 7.
3. Set up the seat from 14 and 17.
8
9
12
13 14
15
11
16
17
10
Seat
Wing bolt
www.PyleUSA.com
4
4. Set up the pedal from 8 and 13.
5. Set up the bass drum: take out the bass drum no. 6, remove one side bolt
and hoop
www.PyleUSA.com
5
Put the washers on the bass drum boles and put the drum head on.
Please pay attention the logo position when you put the drum head on.
Using the tuning key to make the drum head tight. Please pay attention that,
don’t tighten one screw too tight without tightening other screws. The correct
way is tighten one screw a little, and then tighten the opposite screw a little,
then tighten the besides screw a little, then tighten the left screw a little. Then
tighten again by this turn.
www.PyleUSA.com
6
6. Set up the bass drum spur 10. Insert it inside the slot of the bass drum in both
side.
7. Put the bass drum on the oor and adjust the length of the bass drum spur.
www.PyleUSA.com
7
8. Set up the cymbal holder 11 and tom/snare drum holder 15 on the bass drum.
9. Set up the cymbal.
10. Set up the tom drum on the right, snare drum on the left. Put the logo on
drum head in the correct position as picture.
Set up the pedal on the bass drum hoop by using the screw as below picture.
11. Finish
12. If you are afraid it is too loud to annoy your neighborhood, you could put the
drum mute mat no. 2on the drum head.
www.PyleUSA.com
8
www.PyleUSA.com
9
Setting drum mute mat method as below:
1. For snare drum and tom drum, you could just put the mute mat on the drum
head.
2. For cymbal, you need to take the screw and upper felt out, and put the mute
mat instead.
3. Set up the bass drum mute mat. At rst, tear the
adhesive tape and stick it on the bass drum.
4. Finish
Take this upper
felt out
