PureTools PT-SW-HD3 Manuel utilisateur

User Manual

PT-SW-HD3

User Manual

HDMI 2.0 Bi-directional Switcher 4K (60Hz 4:4:4) HDR

Model PT-SW-HD3

Designed in Germany

User Manual

PT-SW-HD3

Preface

Read this user manual carefully before using this product. Pictures shown in this

manual are for reference only. Different model layouts and specifications are subject

to the physical product.

This manual is for operation instructions only, not for any maintenance usage.

In the constant effort to improve our product, we reserve the right to make changes in

functions or parameters without prior notice or obligation.

Trademarks

Product model and logo are trademarks. Any other trademarks mentioned in this

manual are acknowledged as the properties of the trademark owner. No part of this

publication may be copied or reproduced without the prior written consent.

FCC Statement

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful

interference to radio communications. It has been tested and found to comply with

the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful interference in

a commercial installation.

Operation of this equipment in a residential area is likely to cause interference, in

which case the user at their own expense will be required to take whatever measures

may be necessary to correct the interference.

Any changes or modifications not expressly approved by the manufacture would void

the user’s authority to operate the equipment.

User Manual

PT-SW-HD3

REACH | 1907/2006/EU

ROHS | 2011/65/EU

PureLink hereby declares that this product PureTools PT-SW-HD3 complies with

Directives 1907/2006/EU und 2011/65/EU.

EMC / LVD (Electro Magnetic Compatibility / Low Voltage Directive)

PureLink GmbH hereby declares that this product PureTools PT-SW-HD3 complies

with Directives 2014/30/EU and 2014/35/EU. The full text of the EU Declaration

of Conformity is available at the following Internet address:

http://www.purelink.de/ce/4251364706961_CE.pdf

User Manual

PT-SW-HD3

SAFETY PRECAUTIONS

To insure the best from the product, please read all instructions carefully before

using the device. Save this manual for further reference.

Unpack the equipment carefully and save the original box and packing

material for possible future shipment

Follow basic safety precautions to reduce the risk of fire, electrical shock and

injury to persons.

Do not dismantle the housing or modify the module. It may result in electrical

shock or burn.

Using supplies or parts not meeting the products’ specifications may cause

damage, deterioration or malfunction.

Refer all servicing to qualified service personnel.

To prevent fire or shock hazard, do not expose the unit to rain, moisture or

install this product near water.

Do not put any heavy items on the extension cable in case of extrusion.

Do not remove the housing of the device as opening or removing housing may

expose you to dangerous voltage or other hazards.

Install the device in a place with fine ventilation to avoid damage caused by

overheat.

Keep the module away from liquids.

Spillage into the housing may result in fire, electrical shock, or equipment

damage. If an object or liquid falls or spills on to the housing, unplug the

module immediately.

Do not twist or pull by force ends of the optical cable. It can cause

malfunction.

Do not use liquid or aerosol cleaners to clean this unit. Always unplug the

power to the device before cleaning.

Unplug the power cord when left unused for a long period of time.

Information on disposal for scrapped devices: do not burn or mix with general

household waste, please treat them as normal electrical wastes.

User Manual

PT-SW-HD3

Introduction to PT-SW-HD3

The PT-SW-HD3 is an ultra-thin bidirectional 3x1/1x3 HDMI2.0 switcher with 4 HDMI

ports. The switcher supports HDMI resolutions up to 4K@60Hz 4:4:4.

Feature

Supports HDMI2.0 4k@60Hz 4:4:4.

HDCP2.2 compliant.

Supports bi-directional switching.

Supports HDR.

Supports Hot-Plug detection.

No need of external power supply.

Supports smart EDID management.

Package Content

Please take an inventory of the package contents to ensure you have all the items

listed below. If anything is missing or damaged, please contact your distributor for a

replacement.

1 x PT-SW-HD3

1 x Velcro Tape

1 x User Manual

User Manual

PT-SW-HD3

Panel Description

①SWITCH: Press this button to switch 1-HDMI, 2-HDMI, or 3-HDMI as input or

output.

②IIN/OUT: Press this button to select the HDMI(③) as input or output.

③HDMI: Connect with HDMI source or display.

④IN: Illuminates blue when the HDMI port(③) is selected as input.

⑤OUT: Illuminates blue when the HDMI port(③) is selected as output.

⑥1/2/3-Signal LED: Illuminates blue when the corresponding source or display is

selected.

⑦1/2/3-HDMI: 3 HDMI ports, connect with sources or displays.

1-HDMI 2-HDMI 3-HDMI

1234567

User Manual

PT-SW-HD3

Specification

Video

Input & Output

(4) HDMI

Connector

(4) 19-pin type-A female HDMI

General

Max Resolution

4Kx2K@60Hz 4:4:4

HDMI Standard

HDMI2.0

HDCP Compliance

HDCP2.2 pass-through

EDID Management

Built-in EDID

Power Consumption

4W (Max)

Operation Temperature

-10~40℃

Storage Temperature

-15~55℃

Relative Humility

10%-90%

Dimensions (W*H*D)

80mm x 16mm x55mm

Net Weight

131g

User Manual

PT-SW-HD3

System Diagram

1-HDMI 2-HDMI 3-HDMI 1-HDMI 2-HDMI 3-HDMI

HDMI IN:

HDMI OUT:

Blu-Ray

Projector HDTV WhiteBoard

HDTV

Blu-Ray Laptop Game Console

User Manual

PT-SW-HD3

After-Sales Service

If there appear some problems when running the product, please check and deal with

the problems referring to this user manual. Any transport costs are borne by the users

during the warranty.

1) Product Limited Warranty: This product will be free from defects in materials and

workmanship for two years (The purchase invoice shall prevail).

Proof of purchase in the form of a bill of sale or receipted invoice which is

evidence that the unit is within the Warranty period must be presented to obtain

warranty service.

2) What the warranty does not cover (servicing available for a fee):

Warranty expiration.

Factory applied serial number has been altered or removed from the product.

Damage, deterioration or malfunction caused by:

Normal wear and tear.

Use of supplies or parts not meeting our specifications.

No certificate or invoice as the proof of warranty.

The product model showed on the warranty card does not match with the

model of the product for repairing or had been altered.

Damage caused by force majeure.

Servicing not authorized by distributor.

Any other causes which does not relate to a product defect.

Delivery, installation or labor charges for installation or setup of the product.

3) Technical Support: For any questions or problems, contact your distributor or

reseller and tell them the respective product name and version, the detailed

failure situation as well as the formation of the cases.

User Manual

PT-SW-HD3
