E P L U TO ®O W N ER M A N UA L
PURENERGY PVT LTD
Dear Customer,
Greetings on purchasing the PURE EPLUTO, India’s premium electric Scooter that is manufactured by PuREnergy Pvt Ltd.
Before you begin riding, please go through this manual to familiarize yourself with the mechanism and controls of the EPluto,
and with its proper care and maintenance to ensure a long trouble-free ride.
Keeping the batteries in good health is vital for the economy and reliability of the EPluto.
Enjoy the PURE ride!
COPYRIGHTS
© Copyright PuREnergy Pvt Ltd. All rights reserved.
This material provided by PuREnergy Pvt Ltd isthe property of PuREnergy Pvt Ltd and is protected bycopyright, trademark and other intellectual property
laws. You may view this material and print this material only for personal use, provided that you maintain all copyright, trademark and other proprietary
rights or notices. You may not otherwise use, reproduce, store, post, broadcast, transmit, modify, sell or make available to others or the public, content
from this material without the prior written approval of PuREnergy Pvt Ltd. Version March 2020
Address:
H.No: 10-38/2, Survey No-424/AA3, Beside Arya College
of Pharmacy, Near IIT Hyderabad, Kandi Village,
Telangana.
Website: www.pureev.in
Follow Us at: @pureevindia
PURE Electric Vehicle
PuR Energy Pvt Ltd
DISCLAIMER
PuREnergy Pvt Ltd, here in after called as PURE EV TM. In this publication the specifications, information,
illustrations used, and performance of the EPluto and other products manufactured by or sold under the
license granted by PURE EV is based on the latest information available at the time of printing. PURE EV
reserves the right to make changes at any time without prior notice. The use of this information or products
and the conditions under which the products are used are the sole responsibility of the buyer and/or the rider.
It is the buyer’s and/or rider’s responsibility to determine the correct and safe selection of settings and
conditions of use of the products and to periodically check the products for secure and proper operation. To
the extent that the law permits, any liability which may be incurred as a result of the use of a product
manufactured by or sold under license granted by PURE EV is limited to the cost of repairing or replacing the
failed product or component at the discretion of PURE EV either within or outside of warranty periods, and
does not extend to any loss or damage which may be caused as a consequence of misuse or failure of the
products. Damages to the product, other property or any persons are the responsibility of the buyer and/or
rider. By using this product manufactured by or sold under license granted by PURE EV, you are stating that
you have read this disclaimer and agree to hold PURE EV, its owner/s and any of its employees or Directors
free from all liabilities, that you agree you are using and operating the product at your own risk, and that no
warranties or guarantees are made by PURE EV, expressed or implied, on performance or operation.
PURE Electric Vehicle
PuR Energy Pvt Ltd
Contents
1About EPLUTO ......................................1
Specifications & Features.....................1
EPluto Kit.............................................1
Smart Lock...........................................5
2PURE Lithium Battery ...........................9
Critical..................................................9
Important............................................10
Battery Health Tips.............................11
3EPluto Charger....................................12
Quick Trouble Shooting................Error!
Bookmark not defined.
Charging your Li-ion Battery...............13
Precautions while charging the battery13
Steps to Charge the Battery Away from
the Vehicle.........................................15
Important Safety Information.............. 16
4Service Policy...................................... 17
5Warranty Policy: Scope of Warranty.. 18
6Mandatory Road Signs ....................... 22
7Trouble Shooting ................................ 23
PURE Electric Vehicle
PuR Energy Pvt Ltd |1
1 About EPLUTO
Specifications & Features
Alloy Rim
25 Kmph Top Speed
60 V Vector Looped Controller
Motor: 250 Watt
67.2V, 6 A Charger
1.8 KWh Patented High Performance PURE Lithium Battery
Comfortable Seat for 2 PAX
LED Display
Tyre - Front: 90/100-10, Rear: 3.00—10
Front Disc and Rear Drum Brakes
Twist Throttle
Active Balance BMS 35A
120 Kgs Load Capacity
69 Kgs Kerb Weight
Regenerative Braking
4 Hrs Charging Time
Portable Battery Pack
Smart Anti-Theft Locking
EPluto Kit
•EPluto Battery
•1 Owner’s Manual
•2 Keys and 2 Remotes
•1 First Aid Kit
•1 Tool Kit
•1 Charger
•(Optional) Other accessories: Side Guards, Helmet Lock, Foot Mat, Seat Cover, Mud Guard Flap
PURE Electric Vehicle
PuR Energy Pvt Ltd |2
1. Rear View Mirrors
2. Head Light
3. Left Brake Lever
4. Front Number Plate
5. Front Storage Box
6. Smart Keys
7. Front Luggage Hook
8. Side Stand
9. External Charging Port
10. Middle Stand
11. Ladies Footrest (Side Foot Rest)
12. Back Number Plate
13. Back Grip (Back Rail)
14. Boot Space Lock
15. LED Display
A. Battery
B. MCB Switch
PURE Electric Vehicle
PuR Energy Pvt Ltd |3
Left-Side Handle Controls
Right Side Handle Controls
1. Side Indicator Switch
1. Headlight / Back Light (Off/No) Switch
2. Horn Switch
2. Horn Switch
3. High / Low Beam Switch
3. Speed Mode Selection Switch
4. Rear Brake Lever
4. Parking Switch
5. Twist Throttle (Accelerator)
6. Front Brake Lever
PURE Electric Vehicle
PuR Energy Pvt Ltd |4
LED Display
Parking Mode On
PURE EV Has integrated additional safety feature of
parking mode. The vehicle remains in “Parking Mode”
when switched on with the metal key or smart key and the
LED status is as show in the figure to the left side. This
keeps the vehicle immobile and avoid any unintentional
acceleration unless the Parking button is pressed.
1. Speedometer
2. High Beam / Low Beam Indicator
3. Right Side Indicator
4. Error Indicators
5. Odometer
6. Speed Mode Indicator
7. Battery Level Indicator
8. Left Side Indicator
PURE Electric Vehicle
PuR Energy Pvt Ltd |5
Smart Lock Feel modish with the smart locking system for the EPluto. The device allows
you to ride your EPluto without any key and is loaded with anti-theft abilities.
The transponder that is built into the ignition key carries a unique
identification code. The vehicle unlocks when the code on the key matches
with the code of the receiver inside the vehicle.
1. Panic Button
2. Lock Button
3. LED Signal Indicator
4. Unlock Button
5. Ignition Button
6. Key Holder
PURE Electric Vehicle
PuR Energy Pvt Ltd |6
Features
Force Panic ON Operation and Automatic Activation of Immobilisation
If the vehicle is in running condition and the lock button is pressed, it overrides the key operation and turns
the vehicle off (immobilise) triggering an alarm until it is unlocked using the Smart Key.
Vehicle Search
If lock button of the ignition button is pressed the vehicle gives a sound output, also flashing its side indicators.
This helps in finding your vehicle in complex and big parking areas
Note:
•Do not attach any heavy or large objects to the Smart Key.
•Keep the Smart Key away from strong magnetic fields. Otherwise, the remote-control function
could be affected.
•The transmitter operation may face interference in case of the Smart Key being close to radio
transmitter such as radio stations.
•Don’t playfully operate Unlock button/ Ignition Button of remote in the vicinity of your vehicle,
as it could lead to an unintentional unlocking your vehicle.
•It is always advisable to carry the key and Smart Key together.
