PTZOptics Studio Pro Manuel utilisateur
Rev 2.0 2023-10-23
Share Your Vision
PTZOptics
Studio Pro
User Manual
MODEL No.
PT-STUDIOPRO
Rev 2.0 2023-10-23
™
1
Preface ............................................... 1
Precautions ........................................... 2
Warning............................................... 2
Packing List ........................................... 3
Warranty ............................................. 3
FCC Statement ....................................... 4
Copyright Notice ...................................... 4
Features............................................... 5
Camera Features ...................................... 6
Technical Specications............................... 8
Powering the LED Light .......................... 10
Dimensions ...................................... 11
Connection Guide ..................................... 12
IR Remote Controller Guide ........................... 13
Shortcut Functions ............................... 16
Resetting Your Camera’s IP Address .............. 16
On-Screen Display .................................... 17
Network Connection .................................. 21
NDI ®| HX3 Connection................................ 24
Setting & Calling Presets .............................. 24
Achieving the Bokeh Eect ............................ 29
Web UI ................................................ 31
Serial & IP Command List.............................. 52
Troubleshooting....................................... 65
ptzoptics.com II 1-800-486-5276
2
™
534 Trestle Place Downingtown, PA, 19335 USA · Tel: +1(484)593-2247 · Email: support@ptzoptics.com
Rev 2.0 2023-10-23
Preface
Before installation and usage, please read the manual thoroughly. If you have any
questions or issues with this process, please contact our Support Team.
Precautions
▪Do not subject the camera to rain or moisture.
▪Do not remove the cover. Removal of the cover will void the camera’s warranty and may
cause an electric shock. For any abnormal operation, please contact support@ptzoptics.
com.
▪Never operate outside of the specied operating temperature range or humidity.
▪The power supply included in the box is the only power supply to be used with this cam-
era. To purchase a replacement, please visit ptzoptics.com/where-to-buy/.
▪Please use a soft cloth to clean the unit. If the unit is very dirty, clean it with diluted neutral
detergent; do not use solvents which may damage the surface.
Warning
▪Electrical safety
Installation must be in accordance with national and local electric safety
standards.
▪Polarity of Power Supply
The power supply output for this product is 12V DC with a maximum current
supply of 2A. The polarity of the power supply plug is critical and is as follows:
▪Handling
ŜAvoid subjecting the camera to stress, vibration, or moisture during
transportation, storage, installation, and operation.
ŜDo not lift or move the camera by grasping the camera head. To avoid
mechanical damage, do not turn the camera head by hand.
ŜDo not expose the camera to any corrosive solid, liquid, or gas.
ŜPlease make sure that there are no obstacles in the pan or tilt ranges of the
camera lens.
ŜAfter installation is complete, power on the camera.
ŜDo not dismantle the camera - PTZOptics is not responsible for any
unauthorized modication or dismantling.
3
™
Rev 2.0 2023-10-23
▪This is an FCC Class-A product. In a domestic environemt, this camera may cause radio
interference. In the event of radio interference, the user may be required to adequately
mitigate it.
▪Remote Control Battery Safety Information:
▪Store batteries in a cool and dry place.
▪Do not throw away used batteries in the trash. Properly dispose of used batteries through
specially approved disposal methods.
▪Remove the batteries if they are not in use for long periods. Battery leakage and corrosion
can damage the remote control.
▪Do not use old batteries with new batteries.
▪Do not mix and use dierent types of batteries: alkaline, standard (carbon-zinc), or re-
chargeable (nickel-cadmium).
▪Do not dispose of batteries in a re. Do not attempt to short-circuit the battery terminals.
Packing List
Please make sure the items below are included in your camera box:
ŜCamera
ŜAC Power Supply
ŜUSB A-C Cable
ŜLED Panel Light
ŜQuick Start Guide
ŜIR Remote
Ŝ2 AAA Batteries
Warranty
PTZOptics includes a limited parts & labor warranty for all PTZOptics manufactured
cameras. The warranty is valid only if PTZOptics receives proper notice of such
defects during the warranty period. PTZOptics, at its option, will repair or replace
products that prove to be defective. PTZOptics manufactures its hardware products
from parts and components that are new or equivalent to new in accordance with
industry-standard practices.
Here is the link to the PTZOptics Hardware Warranty Documentation. This product
has a 5-year warranty.
Covered by one or more claims of
the HEVC patents listed at
patentlist.accessadvance.com.
4
™
534 Trestle Place Downingtown, PA, 19335 USA · Tel: +1(484)593-2247 · Email: support@ptzoptics.com
Rev 2.0 2023-10-23
™
FCC Statement
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
FCC Caution: Any changes or modications not expressly approved by the
party responsible for compliance could void the user’s authority to operate this
equipment. Operation is subject to the following two conditions: This device may
not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Copyright Notice
The entire contents of this manual / guide, whose copyright belongs to PTZOptics,
may not be cloned, copied, or translated in any way without the explicit permission
of the company. The product specications referred to in this document are for
reference only and as such are subject to updating at any time without prior notice.
5
™
Rev 2.0 2023-10-23
Features
• Full-featured USB Interface
Full-featured USB Type-C interface, compatible with USB 3.0 and USB 2.0, supports
audio, encoding output, and UVC 1.5.
• Precise Focus
Equipped with TOF close-range assisted focusing, combined with advanced focusing
algorithms, it can quickly and stably focus regardless of distance.
• 1080P HD Image
Adopts a new generation of Panasonic 1/2.8-inch, 2.07 million eective pixel high-quality
HD CMOS sensor, which can achieve high-quality images with a maximum resolution of
1920x1080.
• Easy to Use
Supports Portrait and Landscape screen switching. Suitable for horizontal and vertical
screen display screens. USB plug-and-play, simple and fast. The cold shoe mount al-
lows the panel light or an external microphone to be integrated to enrich the scene.
• HDMI 1.4b
Supports HDMI 1.4b, can directly output uncompressed 1080P60 original video.
• 72.5° Wide Lens + 12x Optical Zoom
Adopts 72.5° high quality ultra wide-angle lens, optical zoom up to 12x, and supports 16x
digital zoom.
• LED Panel Light
Color adjustment with warm/natural light and dimming range. Can be charged by Studio
Pro USB 2.0 port.
• Supports PoE
Supports PoE power control, video and audio only needs one network cable to complete.
• Network Encoding Output
Supports dual network video stream output (rst stream, second stream).
• Multiple Interfaces
Supports HDMI, USB 3.0 and network interface, can output 1080P60 video at the same
time.
• Three Power Supply Methods
Supports USB 5V, DC 12V power adapter and PoE power supply.
6
™
534 Trestle Place Downingtown, PA, 19335 USA · Tel: +1(484)593-2247 · Email: support@ptzoptics.com
Rev 2.0 2023-10-23
Camera Features
• Camera Control
Video Templates: The PTZOptics team is making it easy to select the best
performance IP video streams for your project by providing easily selectable
video templates for NDI and IP streaming.
White Balance Modes: This feature helps in adjusting the color balance
in your images, specically focusing on the color white. Dierent lighting
conditions can change the color of white, which may alter other colors in the
image. White balance modes can help correct for dierent types of light like
sunlight, shade, tungsten, uorescent, etc. so that the white in your image
remains true and other colors are displayed correctly.
Exposure Modes: This refers to the dierent methods the camera uses
to decide the correct combination of aperture, shutter speed, and ISO to
achieve the perfect exposure. Dierent modes could include manual (where
you control everything), auto (the camera decides), or other modes that
allow control over one aspect (like shutter priority, where you control the
shutter speed and the camera adjusts the other settings)
• Additional Updates
On-Camera Firmware Updates: This feature allows you to update the
camera’s rmware directly from the camera itself. Firmware is the low-level
software that controls the hardware of your camera. Being able to update
it directly on the camera simplies the process and ensures you can easily
have the latest features and bug xes.
Proles: PTZOptics cameras now feature multiple proles that allow you to
quickly set up your camera for dierent shooting situations. For example,
you might have one prole for indoor shooting, another for outdoor shooting,
and another for low light situations. Each prole would have dierent
settings for things like white balance, exposure, frame rate, etc.
7
™
Rev 2.0 2023-10-23
• Networking
Simple Network Discovery: This is a feature that allows the camera to be
easily discovered and connected to a network. PTZOptics cameras can now
be found by simply entering http://ptzoptics.local/ into any web-browser.
The IP address can then easily be changed through the user interface.
NTP for NDI sync: Network Time Protocol (NTP) is a networking protocol
for clock synchronization between computer systems over packet-
switched, variable-latency data networks. This can be used to ensure that
the timestamps on the Network Device Interface (NDI) streams from your
cameras are accurate and synchronized, ensuring that your video streams
are in sync with each other and with any other networked devices.
Multicast/Unicast: This feature refers to the method of data transmission
over a network. In multicast, data is sent to multiple recipients at the same
time. In unicast, data is sent from one sender to one receiver. Depending on
your network setup and the requirements of your video stream, you might
want to use one or the other.
8
™
534 Trestle Place Downingtown, PA, 19335 USA · Tel: +1(484)593-2247 · Email: support@ptzoptics.com
Rev 2.0 2023-10-23
Camera & Lens
Resolution & Frame Rate HDMI & USB Type C: 1080P@60 / 50 / 30, 1080I@60 /
50, 720P@60 / 50
Sensor 1/2.8”, CMOS, Eective Pixels 2.07M
Scanning Mode Progressive
Lens 12X Optical Zoom f=3.5mm ~ 42.3mm, F1.8 ~ F2.8
Digital Zoom 16X Digital Zoom
Horizontal Field of View 6.9° ~ 72.5°
Veritical Field of View 3.9° ~ 44.8°
Minimum Illumination 0.5 Lux @ (F1.8, AGC ON)
Shutter 1/30s ~ 1/190s
White Balance Auto, Indoor, Outdoor, One Push, Manual, VAR
Backlight Compensation Supported
Digital Noise Reduction 3D & 2D Digital Noise Reduction
Video Signal Noise Reduction ≥55dB
Horizantal & Vertical Flip Supported
Image Freeze Supported
Number of Presets 255
Technical Specications
9
™
Rev 2.0 2023-10-23
USB Specications
Operating System Windows 7 / 8.1 / 10 / 11 / Mac OS, Linux, Android
Color System/Compression YUY2 / MJPEG / H.264
Video Format ▪YUY2: Max resolution: 1920x1080p@30
▪MJPEG: Max resolution: 1920x1080p@60
▪H.264 AVC: Max resolution: 1920x1080p@30
▪H.265: Max resolition: 1920x1080p@30
USB Audio Supported
UVC PTZ Supported
UVC Version UVC 1.1 ~ 1.5
UVC Control Supported
IP Video Specications
Video Compression H.264 / HEVC/H.265* / MJPEG
Video Stream First Stream, Second Stream
First Stream Resolution 1920x1080, 1280x720, 640x480, 640x360
Second Stream Resolution 1280x720, 1024x576, 720x576(50Hz support),
720x480(60Hz support), 720x408, 640x360, 480x270,
320x240, 320x180
Video Bit Rate First Stream: 32Kbps ~ 102400Kbps
Second Stream: 32kbps ~ 20480kbps
Bit Rate Control Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Frame Rate 50Hz: 1fps ~ 50fps
60Hz: 1fps ~ 60fps
Audio Compression AAC
Audio Bit Rate 96Kbps, 128Kbps, 256Kbps
Support Protocols TCP/IP, HTTP, RTSP, RTMP, ONVIF, DHCP, and Multicast.
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels PTZOptics Appareil photo numérique
PTZOptics
PTZOptics 12X NDI|HX ZCAM Manuel utilisateur
PTZOptics
PTZOptics Move 4K Manuel utilisateur
PTZOptics
PTZOptics VL NDI HX ZCAM Manuel utilisateur
PTZOptics
PTZOptics 20X-ZCAM Manuel utilisateur
PTZOptics
PTZOptics PTEPTZ-ZCAM-G2 Manuel utilisateur
PTZOptics
PTZOptics PT30X-4K-WH-G3 Manuel utilisateur
PTZOptics
PTZOptics PT20X-NDI-ZCAM Manuel utilisateur
PTZOptics
PTZOptics NDI HX PT20X-NDI-ZCAM Manuel utilisateur
PTZOptics
PTZOptics PT20X-NDI-GY Manuel utilisateur
PTZOptics
PTZOptics VL-ZCAM Manuel utilisateur
