Product Specifications
Model Name: Mobile Reader Pro
Device Type: RFID reader, 13.56MHz (HF) / 125 KHz (LF) /
Mobile Credential: Bluetooth Low Energy (BLE)
Physical Access control Reader (accessory equipment)
Type of Equipment: Sealed Reader. Suitable for Indoor and Outdoor use.
Interface Type: Pigtail Cable (11 Core + Drain)
Input Voltage: 6V - 16V DC (12V recommended)
Current Draw (WiFi Off): 250 mA @ 12V
Max Current Draw (WiFI On): 500 mA @ 12V
Power Consumption: 6W (Max)
Communication Protocol: Wiegand, RS485 (2wire - Half Duplex), Bluetooth Low Energy,
WiFi IEEE 802.11b/g/n**
Credential Type: 125kHz proximity cards:
- HID® Proximity, Indala®, CasiRusco®, AWID, Farpointe®, Others
13.56MHz smart cards:
- uTrust, PIV, PIV-I, CAC, TWIC,
- MIFARE Classic, DESFire EV1, PLAID [AS 5185-2010],
- ISO15693 UID, ISO14443A/B UID,
- HID® iClass Card Serial Number (CSN)
Bluetooth Low Energy:
Any bit format (standard or custom) up to 120 bits
Transmission Technology: Wiegand
Operating Temperature: -35° to 66°C (-31° to 149°F)
Operating Humidity: 5 to 95% relative humidity (non-condensing)
** Communication via Wiegand was evaluated by UL and serves as the interface between the reader
and panel. Communication via RS485 was not evaluated by UL. WiFi IEEE802.11b/g/n communications
are used for non-critical operations (OTA, backhaul, etc.).
RF Exposure Information
This device has been tested and meets applicable limits for Radio Frequency (RF) exposure.
