Proware Mini-EPICa Manuel utilisateur
Mini-EPICa
USB/IEEE 1394-to-SATA II
RAID SUBSYSTEM
User Manual
Revision 1.2
USB/IEEE 1394-to-SATA II RAID Subsystem
2 User Manual
Contents
Preface ................................................................................................................................ 3
Before You Begin ............................................................................................................. 4
Chapter 1 Introduction ................................................................................................. 6
1.1 Technical Specification .......................................................................................................................................... 7
1.2 Identifying Parts of the RAID Subsystem ...................................................................................................... 8
1.2.1 Front View ......................................................................................................................................................... 8
1.2.1.1 Disk Drive Carrier .................................................................................................................................. 9
1.2.1.2 LED Indicators ......................................................................................................................................... 9
1.2.2 Rear View ........................................................................................................................................................ 10
1.3 RAID Concepts ...................................................................................................................................................... 11
1.3.1 Definition of RAID Levels ......................................................................................................................... 11
1.3.2 RAID Levels Summary ............................................................................................................................... 14
Chapter 2 Getting Started ......................................................................................... 15
2.1 Installing Hard Drives ......................................................................................................................................... 15
2.1.1 Installing the Rubber Feet ....................................................................................................................... 17
2.2 Using the Key Token (Optional) .................................................................................................................... 18
2.3 Preparing the Subsystem and Powering On ............................................................................................ 19
Chapter 3 Configuration Utility ................................................................................ 20
3.1 Installing the AP in Microsoft Windows ..................................................................................................... 22
3.2 Starting the AP in Linux ..................................................................................................................................... 24
3.3 Starting the AP in Mac OS ................................................................................................................................. 25
3.4 Mini-EPICa Management GUI ......................................................................................................................... 26
3.4.1 Other Buttons of the mini-EPICa Management GUI .................................................................... 27
Chapter 4 RAID Management ................................................................................. 30
4.1 Basic Mode ............................................................................................................................................................. 30
4.1.1 RAID and Disk Information ..................................................................................................................... 30
4.1.2 Event Log Viewer ......................................................................................................................................... 33
4.1.3 Basic Raid Configuration .......................................................................................................................... 34
4.2 Advanced Mode ................................................................................................................................................... 38
4.2.1 Email Notification and Event Settings ................................................................................................ 38
4.2.2 Advanced Raid Configuration ................................................................................................................ 39
4.2.3 Firmware Information ................................................................................................................................ 43
4.2.4 RAID Settings ................................................................................................................................................ 45
Chapter 5 Additional Information .......................................................................... 46
5.1 How to Change the USB/1394 IO Interface Board to eSATA IO Interface Board .................... 46
5.2 How to Change the USB/1394 IO Interface Board to USB 3.0 IO Interface Board .................. 49
USB/IEEE 1394-to-SATA II RAID Subsystem
User Manual 3
Preface
About this manual
his manual provides information regarding the quick installation and hardware
features of the mini-EPICa USB/IEEE 1394-to-SATA II RAID subsystem.
This document also describes how to use the storage management software.
Information contained in the manual has been reviewed for accuracy, but not
for product warranty because of the various environment/OS/settings.
Information and specifications will be changed without further notice.
This manual uses section numbering for every topic being discussed for easy and
convenient way of finding information in accordance with the user’s needs. The following
icons are being used for some details and information to be considered in going through
with this manual:
Copyright
No part of this publication may be reproduced, stored in a retrieval system, or
transmitted in any form or by any means, electronic, mechanical, photocopying,
recording or otherwise, without the prior written consent.
Trademarks
All products and trade names used in this document are trademarks or registered
trademarks of their respective holders.
Changes
The material in this document is for information only and is subject to change without
notice.
IMPORTANT!
These are the important information that the user must
remember.
WARNING!
These are the warnings that the user must follow to avoid
unnecessary errors and bodily injury during hardware and
software operation of the subsystem.
CAUTION:
These are the cautions that user must be aware of to
prevent damage to the equipment and its components.
NOTES:
These are notes that contain useful information and tips
that the user must give attention to in going through
with the subsystem operation.
USB/IEEE 1394-to-SATA II RAID Subsystem
4 User Manual
Before You Begin
efore going through with this manual, you should read and focus on the
following safety guidelines. Notes about the subsystem’s controller
configuration and the product packaging and delivery are also included. To
provide reasonable protection against any harm on the part of the user and
to obtain maximum performance, user is advised to be aware of the
following safety guidelines particularly in handling hardware components:
Upon receiving of the product:
Place the product in its proper location.
It should be handled with care to avoid dropping that may cause damage to the
product. Always use the correct lifting procedures.
Upon installing of the product:
Ambient temperature is very important for the installation site. It must not
exceed 30◦C. Due to seasonal climate changes; regulate the installation site
temperature making it not to exceed the allowed ambient temperature.
Before plugging-in any power cords, cables and connectors, make sure that the
power switches are turned off. Disconnect first any power connection if the power
supply module is being removed from the enclosure.
Outlets must be accessible to the equipment.
All external connections should be made using shielded cables and as much as
possible should not be performed by bare hand. Using anti-static hand gloves is
recommended.
In installing each component, secure all the mounting screws and locks. Make
sure that all screws are fully tightened. Follow correctly all the listed procedures
in this manual for reliable performance.
Controller Configurations
This RAID subsystem supports single controller configuration.
Packaging, Shipment and Delivery
Before removing the subsystem from the shipping carton, you should visually
inspect the physical condition of the shipping carton.
Unpack and verify that the contents of the shipping carton are complete and in
good condition.
Exterior damage to the shipping carton may indicate that the contents of the
carton are damaged.
If any damage is found, do not remove the components; contact the dealer where
you purchased the subsystem for further instructions.
USB/IEEE 1394-to-SATA II RAID Subsystem
User Manual 5
Unpacking the Subsystem
The package contains the following items:
RAID subsystem unit
One (1) power cord
One (1) USB cable
Two (2) IEEE 1394b cables
Key Token (Optional)
Two (2) screw handle
Four (4) Rubber Feet
Installation Reference Guide / CD
USB/IEEE 1394-to-SATA II RAID Subsystem
6 User Manual
Chapter 1 Introduction
The RAID Subsystem
Unsurpassed Value
- Most cost-effective SATA II RAID subsystem.
- Compact Desktop size with stylish design.
Application Flexibility
- Extends useful life by adapting to future IT/SOHO requirements.
Easy Installation & Maintenance
- Provide a fast and easy way to install and manage the storage.
Low Power Consumption
- Cable-less backplane with integrated RAID processor. No more unnecessary
components inside.
Features
- USB 2.0/IEEE 1394b host interface
- Supports RAID over 2TB
- Supports hot spare and automatic hot rebuild
- Local event notification
- Easy management via In-Band data bus
- Transparent data protection for all popular operating systems
RAID Management
- Real time drive activity and status indicators
- Graphical User Interface (GUI) management utility
USB/IEEE 1394-to-SATA II RAID Subsystem
User Manual 7
1.1 Technical Specification
Model EP-D501-CA
Form Factor Compact Tower
RAID Processor Integrated Micro-processor
RAID Levels 0, 1, 3, 5, 10, CLONE, and JBOD
Host Interface USB 2.0 or IEEE 1394b
Number of Host Channel 1
Data Transfer Rate Up to 480Mbit/s (USB 2.0)/800Mbit/s (1394b)
Disk Interface SATAII (3Gb/s)
Number of Hot-swap Disk Trays Five (5) 3.5-inch Disk trays
Cooling Fans 1
Failed Drive Indicators Yes
Failed Drive Auto Rebuild Yes
Environment Monitor Yes
Data Encryption Option
Auto Spare Support Yes
Power Supply 180W (full range)
Environmental Relative Humidity:
Operating Temperature:
10% ~ 85% Non-condensing
10°C ~ 40°C (50°F ~ 104°F)
Dimension 221(H) x 156(W) x 260(D)mm
Weight 7Kg (without disks)
Specification is subject to change without notice.
USB/IEEE 1394-to-SATA II RAID Subsystem
8 User Manual
1.2 Identifying Parts of the RAID Subsystem
The illustrations below identify the various parts of the subsystem.
1.2.1 Front View
USB/IEEE 1394-to-SATA II RAID Subsystem
User Manual 9
1.2.1.1 Disk Drive Carrier
HDD Status Indicator
Part Function
HDD Access LED This LED will blink blue when the hard drive is being accessed.
HDD Fault LED
Green LED means HDD is detected/good.
Red LED indicates hard drive has failed.
No LED light means no hard drive in the slot.
1.2.1.2 LED Indicators
Part Function
Fan Fail LED
LED is off means Fan is good.
Red LED means Fan has failed.
Over Temp LED
LED is off means Temperature is normal.
Red LED means Temperature exceeded normal range.
Power On LED
White LED means RAID subsystem is powered on.
USB/IEEE 1394-to-SATA II RAID Subsystem
10 User Manual
1.2.2 Rear View
USB 2.0 Port
The subsystem has one USB 2.0 port for connecting to Host/Server.
IEEE 1394b Port
The subsystem has one IEEE 1394b port for connecting to Host/Server.
Fan
The fan provides proper ventilation for the RAID subsystem.
Power On/Off Switch
Use the Power On/Off Switch to turn on or off the RAID subsystem.
Power Input Socket
Use the Power Input Socket for connecting the power cable.
NOTE: USB and IEEE 1394 ports use same channel. Only one host
connection will work at a time. You cannot use both USB and
IEEE 1394 ports at the same time.
Key Token Port
The subsystem has one key token port for inserting the key token.
NOTE: For more information about using the key token, refer to
Section 2.2 Using the Key Token.
