QUICK START GUIDE
VAV CONTROLLERS & WALL SENSORS
www.proloncontrols.com |info@proloncontrols.com
17 510 rue Charles, Suite 100, Mirabel, QC, J7J 1X9
REV 1.0
PL-QCK-WSENSOR/VC2000-EN
© Copyright 2018 Prolon. All rights reserved.
No part of this document may be photocopied or reproduced by any means, or translated to
another language without prior written consent of Prolon. All specications are nominal and
may change as design improvements are introduced. Prolon shall not be liable for damages
resulting from misapplication or misuse of its products. All trademarks are the property of their
respective owners.
REV 1.0 / PL-QCK-WSENSOR/VC2000-EN 3
Analog Sensor (PL-RS) .................................................................................................4
Dimensions and Wiring.....................................................................................4
Digital Sensor (PL-T200) ...............................................................................................6
Dimensions and Wiring.....................................................................................6
Digital Sensor (PL-T500) ...............................................................................................8
Dimensions and Wiring.....................................................................................8
Digital Sensor (PL-T1000)........................................................................................... 10
Installation .......................................................................................................... 10
Auxiliary Analog Input.................................................................................... 12
Operation............................................................................................................ 12
Changing the Setpoint................................................................................... 13
Schedule Override ........................................................................................... 13
VAV Zone Controller (PL-C1000-VAV)....................................................................... 14
VAV Zone Controller (PL-VC2000)............................................................................ 16
Compliance............................................................................................................... 18
Technical Specications....................................................................................... 18
Table of Contents
REV 1.0 / PL-QCK-WSENSOR/VC2000-EN4
Analog Sensor (PL-RS)
COM
THERM
COM
POT
4.96”
(126 mm)
1.30”
(33 mm)
3.23”
(82 mm)
Schedule override
Room temperature
Setpoint (10K)
Dimensions and Wiring
REV 1.0 / PL-QCK-WSENSOR/VC2000-EN 5
COM
THERM
COM
POT
4.96”
(126 mm)
1.30”
(33 mm)
3.23”
(82 mm)
Schedule override
Room temperature
Setpoint (10K)
Temperature table (thermistor: 10K Type 3)
Fahrenheit 41 50 59 68 77 86 95 104
Celsius 5 10 15 20 25 30 35 40
Ohms 25395 19903 15714 12493 10000 8056 6530 5324
REV 1.0 / PL-QCK-WSENSOR/VC2000-EN6
Digital Sensor (PL-T200)
Dimensions and Wiring
INT A (+)
INT B (-)
24VAC
COM
4.96”
(126 mm)
1.30”
(33 mm)
3.23”
(82 mm)
Schedule override
(hold for 3 second)
Communication (RS485)
Power (2 VA max)
RJ45 connection
(to C1000)
REV 1.0 / PL-QCK-WSENSOR/VC2000-EN 7
INT A (+)
INT B (-)
24VAC
COM
4.96”
(126 mm)
1.30”
(33 mm)
3.23”
(82 mm)
Schedule override
(hold for 3 second)
Communication (RS485)
Power (2 VA max)
RJ45 connection
(to C1000)
REV 1.0 / PL-QCK-WSENSOR/VC2000-EN8
Digital Sensor (PL-T500)
Dimensions and Wiring
INT A (+)
INT B (-)
24VAC
COM
4.96”
(126 mm)
1.30”
(33 mm)
3.23”
(82 mm)
Communication (RS485)
Power (2 VA max)
RJ45 connection
(to C1000)
Schedule override:
Hold 3 seconds
Change unit °F/°C:
Double-click
REV 1.0 / PL-QCK-WSENSOR/VC2000-EN 9
INT A (+)
INT B (-)
24VAC
COM
4.96”
(126 mm)
1.30”
(33 mm)
3.23”
(82 mm)
Communication (RS485)
Power (2 VA max)
RJ45 connection
(to C1000)
Schedule override:
Hold 3 seconds
Change unit °F/°C:
Double-click
REV 1.0 / PL-QCK-WSENSOR/VC2000-EN10
Digital Sensor (PL-T1000)
Installation
1. Open casing to remove back cover by pushing on the tab located
underneath the thermostat. (See Figure 1)
2. Pull wire(s) throught central hole of back cover.
3. Screw in the back cover to the wall.
4. Connect wires:
• If using twisted pair wires:
- Pull out screw terminal block.
- Remove 1 cm insulation from each wire.
- Connect the wires to the terminal blocks and reconnect
the terminal blocks. (See Figure 2)
•If using CAT5 cable:
- Plug the cable into the RJ45 jack of the T1000 (if CAT5 cable
is opened at the controller, refer to Figure 3 for pinout of the
T1000’s RJ45 jack).
5. Reconnect top cover.
IMPORTANT! Do not install the thermostat under the following
conditions:
•Any location exposed to direct sunlight.
•On an outside wall.
•Near an air dischatge grill.
•In a location where vertical sir circulation is retricted.
•Near a dimmer switch.
