Prolon PL-C1000-BLR Manuel utilisateur
REV. 1.0
PL-QCK-C1000-EN
QUICK START GUIDE
C1000 SERIES
www.proloncontrols.com |info@proloncontrols.com
17 510 rue Charles, Suite 100, Mirabel, QC, J7J 1X9
© Copyright 2018 Prolon. All rights reserved.
No part of this document may be photocopied or reproduced by any means, or translated to
another language without prior written consent of Prolon. All specications are nominal and
may change as design improvements are introduced. Prolon shall not be liable for damages
resulting from misapplication or misuse of its products. All trademarks are the property of their
respective owners.
REV 1.0 / PL-QCK-C1000-EN 3
Table of Contents
Boiler Controller (PL-C1000-BLR)..................................................................................4
FlexIO Controller (PL-C1000-FLX).................................................................................6
Heatpump Controller (PL-C1000-HP & PL-C1000-HPS) .................................................8
Humidity Controller (PL-C1000-HU) ........................................................................ 10
Rooftop Controller (PL-C1000-RTU & PL-C1000-RTUS)................................................ 12
Water Loop Controller (PL-C1000-WLC) .................................................................. 14
Compliance............................................................................................................... 16
Technical Specications....................................................................................... 16
REV 1.0 / PL-QCK-C1000-EN4
Boiler Controller (PL-C1000-BLR)
INT Port: Incoming RS485 network communication (Modbus)
NET Port: Incoming RS485 network communication (Modbus)
External dry contact for proof of pump
Supply water temperature sensor (10K thermistor)
Common for all the inputs
Return water temperature sensor (10K thermistor)
Outside air temperature sensor (10K thermistor)
Output 5 - Valve / Modulating boiler (analog 0-10 / 2-10 / 0-5 DVC)
Output 4 - Boiler 2 action (digital - ON/OFF)
Output 3 - Boiler 1 action (digital - ON/OFF)
Output 2 - Pump 2 action (digital - ON/OFF)
Output 1 - Pump 1 action (digital - ON/OFF)
Power source of the controller (24 VAC)
32-122 °F (0-50 °C) Non-condensing
REV 1.0 / PL-QCK-C1000-EN 5
INT Port: Incoming RS485 network communication (Modbus)
NET Port: Incoming RS485 network communication (Modbus)
External dry contact for proof of pump
Supply water temperature sensor (10K thermistor)
Common for all the inputs
Return water temperature sensor (10K thermistor)
Outside air temperature sensor (10K thermistor)
Output 5 - Valve / Modulating boiler (analog 0-10 / 2-10 / 0-5 DVC)
Output 4 - Boiler 2 action (digital - ON/OFF)
Output 3 - Boiler 1 action (digital - ON/OFF)
Output 2 - Pump 2 action (digital - ON/OFF)
Output 1 - Pump 1 action (digital - ON/OFF)
Power source of the controller (24 VAC)
cULus Listed; UL 916 Energy Management Equipment, File E364757, Vol.1
REV 1.0 / PL-QCK-C1000-EN6
FlexIO Controller (PL-C1000-FLX)
INT Port: Incoming RS485 network communication (Modbus)
NET Port: Incoming RS485 network communication (Modbus)
Digital input
Analog input 3
Common for all the inputs
Analog input 2
Analog input 1
Analog output (0-10 / 2-10 / 0-5 VDC)
Digital output 4 (ON/OFF, PWM)
Digital output 3 (ON/OFF, PWM)
Digital output 2 (ON/OFF, PWM)
Digital output 1 (ON/OFF, PWM)
Power source of the controller (24 VAC)
32-122 °F (0-50 °C) Non-condensing
REV 1.0 / PL-QCK-C1000-EN 7
INT Port: Incoming RS485 network communication (Modbus)
NET Port: Incoming RS485 network communication (Modbus)
Digital input
Analog input 3
Common for all the inputs
Analog input 2
Analog input 1
Analog output (0-10 / 2-10 / 0-5 VDC)
Digital output 4 (ON/OFF, PWM)
Digital output 3 (ON/OFF, PWM)
Digital output 2 (ON/OFF, PWM)
Digital output 1 (ON/OFF, PWM)
Power source of the controller (24 VAC)
cULus Listed; UL 916 Energy Management Equipment, File E364757, Vol.1
REV 1.0 / PL-QCK-C1000-EN8
Heatpump Controller (PL-C1000-HP & PL-C1000-HPS)
INT Port: ProLon digital temperature
sensor - OR - Incoming RS485
network communication (Modbus)
INT Port: Incoming RS485
network communication
(Modbus)
NET Port: ProLon digital temperature
Sensor - OR - Incoming RS485
network communication (Modbus)
NET Port: Outgoing RS485
network communication
to zones (Modbus)
Output 5 - Preheating /
Aux Heat / Econo
Output 4 - Aux Heat
Output 3 - Rev Valve
Output 2 - Compressor 1
Output 1 - Fan (G)
Controller’s power source
Unit’s R&C terminal (24VAC)
Output 5 - Aux Heat
Output 4 - Rev Valve
Output 3 - Compressor 2
Output 2 - Compressor 1
Output 1 - Fan (G)
Controller’s power source
Unit’s R&C terminal (24VAC)
1 Compressor 2 Compressors
External dry contact for night setback or proof of fan
Outside temp (10K therm), water intake temp (10K therm)
or dry contact for alarm
Supply temperature sensor (10K thermistor)
Common for all the inputs
Return temperature sensor (10K thermistor)
PL-C1000-HP PL-C1000-HPS
32-122 °F (0-50 °C) Non-condensing
REV 1.0 / PL-QCK-C1000-EN 9
INT Port: ProLon digital temperature
sensor - OR - Incoming RS485
network communication (Modbus)
INT Port: Incoming RS485
network communication
(Modbus)
NET Port: ProLon digital temperature
Sensor - OR - Incoming RS485
network communication (Modbus)
NET Port: Outgoing RS485
network communication
to zones (Modbus)
Output 5 - Preheating /
Aux Heat / Econo
Output 4 - Aux Heat
Output 3 - Rev Valve
Output 2 - Compressor 1
Output 1 - Fan (G)
Controller’s power source
Unit’s R&C terminal (24VAC)
Output 5 - Aux Heat
Output 4 - Rev Valve
Output 3 - Compressor 2
Output 2 - Compressor 1
Output 1 - Fan (G)
Controller’s power source
Unit’s R&C terminal (24VAC)
1 Compressor 2 Compressors
External dry contact for night setback or proof of fan
Outside temp (10K therm), water intake temp (10K therm)
or dry contact for alarm
Supply temperature sensor (10K thermistor)
Common for all the inputs
Return temperature sensor (10K thermistor)
PL-C1000-HP PL-C1000-HPS
cULus Listed; UL 916 Energy Management Equipment, File E364757, Vol.1
REV 1.0 / PL-QCK-C1000-EN10
Humidity Controller (PL-C1000-HU)
INT Port: Incoming RS485 network communication (Modbus)
NET Port: Incoming RS485 network communication (Modbus)
External dry contact for proof of fan
Supply humidity sensor (0-5VDC)
Common for all the inputs
Room / Return humidity sensor (0-5VDC)
Outside temperature sensor (10K thermistor)
Output 5 - Humidifier (analog 0-10 / 2-10 VDC)
Output 4 - Humidifier (digital - ON/OFF)
Output 3 - Dehumidifier (digital - ON/OFF)
Power source of the controller (24VAC)
32-122 °F (0-50 °C) Non-condensing
